Hoshizaki KML-350MAF Final Parts List
  1. Manuals
  2. Brands
  3. Hoshizaki Manuals
  4. Ice Maker
  5. KML-350MAF
  6. Final parts list
Hoshizaki KML-350MAF Final Parts List

Hoshizaki KML-350MAF Final Parts List

Modular crescent cuber
Hide thumbs Also See for KML-350MAF:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual, Instruction Manual
NO.
71159
ISSUED:
MARCH. 31, 2000
JULY 31, 2002
REVISED:
MODEL
(FINAL) PARTS LIST
K-0
JAN., 2000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KML-350MAF and is the answer not in the manual?

Questions and answers

Related Manuals for Hoshizaki KML-350MAF

Summary of Contents for Hoshizaki KML-350MAF

  • Page 1 71159 ISSUED: MARCH. 31, 2000 JULY 31, 2002 REVISED: MODEL (FINAL) PARTS LIST JAN., 2000...

  • Page 2: Auxiliary Code

    ALUMINUM Aluminum COPPER Copper PLASTIC Acrylonitrile -butadiene - styrene Polyacetal Ethylene vinyl acetate Polyamide = Nylon Polycarbonate Polyethylene Polyester PETP Polyethylene terephthalate = Tetlon Polypropylene Polystyrene PIFE Polytetrafluoroethylene = Teflon Polyurethane Polyvinyl chloride RUBBER Vinyl Nitrile EPDM EP rubber Nitrile butadiene rubber Natural rubber Neoprene SI.R...

  • Page 3: Ice Cuber Assembly

    KML-350MAF A. ICE CUBER ASSEMBLY...
  • Page 4 KML-350MAF MODEL INDEX DESCRIPTION REFRIGERATION CIRCUIT WATER CIRCUIT CONT. BOX ASSEMBLY T2 SCREW LABEL LOCATION TOP PANEL ASSEMBLY FRONT PANEL TRUSS HEAD SCREW EVAP. CASE CONT. BOX COVER T2 SCREW SQUARE WASHER SCREW - GROUNDING JUNCTION BOX COVER T2 SCREW...
  • Page 5 KML-350MAF MODEL INDEX DESCRIPTION AIR FILTER (C) GASKET GASKET GASKET A. ICE CUBER ASSEMBLY TITLE MATERIAL OR PART MODEL NUMBER NUMBER 208284G01 L=655 4A0808L02 L=190 4A0808L02 L=762 4A0808L02 REQUIRED NUMBER...
  • Page 6 KML-350MWF A. ICE CUBER ASSEMBLY...
  • Page 7 KML-350MWF MODEL INDEX DESCRIPTION REFRIGERATION CIRCUIT WATER CIRCUIT CONT. BOX ASSEMBLY T2 SCREW LABEL LOCATION TOP PANEL ASSY FRONT PANEL TRUSS HEAD SCREW EVAP. CASE CONT. BOX COVER T2 SCREW SQUARE WASHER SCREW - GROUNDING JUNCTION BOX COVER T2 SCREW THERMOSTAT EXTENSION BRACKET SPACER THUMBSCREW...

  • Page 8: Refrigeration Circuit

    KML-350MAF 5 6 7 8 9 10 11 12 40 41 B. REFRIGERATION CIRCUIT 20 21 4 4a 2 2a 3 3a 1 1a 23 24 DETAIL A 45 46 45 46...
  • Page 9 KML-350MAF MODEL INDEX DESCRIPTION COND. SUPPORT T2 SCREW CONDENSER T2 SCREW BARRIER T2 SCREW SHROUD T2 SCREW COMPRESSOR TERMINAL COVER SPRING CLIP MOTOR PROTECTOR PROTECTOR HOLDER BOLT SPACER GROMMET FAN MOTOR BRACKET HEX HEAD BOLT W/WASHER (LF) FAN MOTOR SELF LOCKING NUT...
  • Page 10 KML-350MAF MODEL INDEX DESCRIPTION BOLT TRUSS HEAD SCREW PRESSURE SWITCH PRESSURE SWITCH BRACKET T2 SCREW ACCESS VALVE COPPER TUBE (A) - HIGH SIDE COPPER TUBE (B) - HIGH SIDE COPPER TUBE (C) - HIGH SIDE COPPER TUBE (D) - HIGH SIDE...
  • Page 11 KML-350MAF MODEL INDEX DESCRIPTION T2 SCREW INSULATION HOLDER T2 SCREW ELBOW ELBOW ENDCAP B. REFRIGERATION CIRCUIT TITLE MATERIAL OR PART MODEL NUMBER NUMBER 7P31-0408 3A1084-01 7P31-0408 COPPER 4A1059-01 COPPER 417395-03 4A1413F01 REQUIRED NUMBER...
  • Page 12 KML-350MWF 2 3 4 5 6 7 8 9 40 41 B. REFRIGERATION CIRCUIT 1 1a 16 17 45 46 19 20 DETAIL A...
  • Page 13 KML-350MWF MODEL INDEX DESCRIPTION REAR PANEL (B) T2 SCREW COMPRESSOR TERMINAL COVER SPRING CLIP PROTECTOR PROTECTOR HOLDER BOLT SPACER GROMMET CONDENSER HEX HEAD BOLT W/WASHER (LF) COND. SUPPORT T2 SCREW DRIER DRIER BRACKET T2 SCREW EXP. VALVE EVAPORATOR ASSEMBLY T2 SCREW VALVE BODY COIL VALVE BOLT...
  • Page 14 KML-350MWF MODEL INDEX DESCRIPTION MALE CONNECTOR COPPER TUBE (A)-HIGH SIDE COPPER TUBE (B)-HIGH SIDE COPPER TUBE (C)-HIGH SIDE COPPER TUBE (D)-HIGH SIDE HEAT EXCHANGER STRAINER COPPER TUBE (A)-HOT GAS COPPER TUBE (B)-HOT GAS COPPER TUBE (A)-ACCESS VALVE COPPER TUBE (A) T2 SCREW COPPER TUBE (B) HOLDER/EXP VALVE-1/2...
  • Page 15 KML-350MWF MODEL INDEX DESCRIPTION T2 SCREW ELBOW ELBOW INSULATION TUBE ENDCAP B. REFRIGERATION CIRCUIT TITLE MATERIAL OR PART MODEL NUMBER NUMBER 7P31-0408 COPPER 4A1059-01 COPPER 417395-03 L=670 7762-1323 4A1413F01 REQUIRED NUMBER...

  • Page 16: Water Circuit

    KML-350MAF, MWF C. WATER CIRCUIT...
  • Page 17 KML-350MAF, MWF MODEL INDEX DESCRIPTION WATER SUPPLY PIPE T2 SCREW RUBBER GASKET WATER VALVE BRACKET T2 SCREW WATER VALVE SPRAY TUBE SPRAY GUIDE (A) WATER SUPPLY TUBE T2 SCREW PLUG WATER SUPPLY TEE FLANGE INSULATION (E) ELBOW CONNECTING PIPE HOSE CLAMP...
  • Page 18 KML-350MAF, MWF MODEL INDEX DESCRIPTION T2 SCREW FLOAT SWITCH COVER T2 SCREW VINYL HOSE VINYL HOSE BUSHING WIRE SADDLE WELL NUT TRUSS HEAD SCREW INSULATION (A) – PUMP BRACKET TOOTH WASHER TRUSS HEAD SCREW INSULATION (B) – PUMP BRACKET HOSE CLAMP HOSE CLAMP INSULATION (A1) –...

  • Page 19: Control Box Assembly

    KML-350MAF D. CONTROL BOX ASSEMBLY...
  • Page 20 KML-350MAF MODEL INDEX DESCRIPTION CONTROL BOX CAPACITOR CAPACITOR - STARTING STRAP T2 SCREW STARTER T2 SCREW RELAY TAPPING SCREW THERMOSTAT TRUSS HEAD SCREW TOGGLE SWITCH TOGGLE SWITCH TRANSFORMER T2 SCREW CONTROLLER BOARD BOARD SUPPORT MAGNETIC CONTACTOR BRACKET T2 SCREW CAPACITOR...
  • Page 21 KML-350MWF D. CONTROL BOX ASSEMBLY...
  • Page 22 KML-350MWF MODEL INDEX DESCRIPTION CONTROL BOX CAPACITOR CAPACITOR - STARTING STRAP T2 SCREW STARTER T2 SCREW RELAY TAPPING SCREW THERMOSTAT TRUSS HEAD SCREW TOGGLE SWITCH TOGGLE SWITCH TRANSFORMER T2 SCREW CONTROLLER BOARD BOARD SUPPORT MAGNETIC CONTACTOR BRACKET T2 SCREW BUSHING BUSHING BUSHING CONTROL LABEL...

  • Page 23: Label Location

    KML-350MAF E. LABEL LOCATION...
  • Page 24 KML-350MAF MODEL INDEX DESCRIPTION EMBLEM MODEL NUMBER LABEL LABEL - PENGUIN - HA (R) MAINTENANCE LABEL WIRING LABEL NAMEPLATE INSTRUCTION SHEET MANUAL LABEL TAG - WARNING: ELECTRICAL CONNECTION LABEL – R404A CAUTION LABEL (F) CAUTION LABEL (K) LABEL - AIR FILTER...
  • Page 25 KML-350MWF E. LABEL LOCATION...
  • Page 26 KML-350MWF MODEL INDEX DESCRIPTION EMBLEM MODEL NUMBER LABEL LABEL - PENGUIN - HA (R) MAINTENANCE LABEL WIRING LABEL NAMEPLATE INSTRUCTION SHEET MANUAL LABEL TAG - WARNING: ELECTRICAL CONNECTION LABEL – R404A CAUTION LABEL (K) INSTRUCTION LABEL RATING LABEL LABEL-CONTROL BOARD E.

  • Page 27: Top Panel Assembly

    KML-350MAF, MWF F. TOP PANEL ASSEMBLY...
  • Page 28 KML-350MAF, MWF MODEL INDEX DESCRIPTION TOP PANEL GASKET GASKET (A) INSULATION F. TOP PANEL ASSEMBLY TITLE MATERIAL OR PART MODEL NUMBER NUMBER 213543-01 427014-04 NORMOUNT V710 324859-03 PE FOAM 438012-01 REQUIRED NUMBER...

  • Page 29: Front Panel Assembly

    KML-350MAF G. FRONT PANEL ASSEMBLY...
  • Page 30 KML-350MAF MODEL INDEX DESCRIPTION FRONT PANEL (A) FOAM SEAL FOAM SEAL FOAM SEAL FOAM SEAL G. FRONT PANEL ASSEMBLY TITLE MATERIAL OR PART MODEL NUMBER NUMBER 2A1455-01 L=370 4A0661L01 L=250 4A0661L01 L=370 4A1163L01 L=190 4A1163L01 REQUIRED NUMBER...
  • Page 31 KML-350MWF G. FRONT PANEL ASSEMBLY...
  • Page 32 KML-350MWF MODEL INDEX DESCRIPTION FRONT PANEL (A) FOAM SEAL FOAM SEAL FOAM SEAL FOAM SEAL G. FRONT PANEL ASSEMBLY TITLE MATERIAL OR PART MODEL NUMBER NUMBER 2A1454-01 L=370 4A0661L01 L=250 4A0661L01 L=370 4A1163L01 L=190 4A1163L01 REQUIRED NUMBER...
  • Page 33 KML-350MAF, MWF H. ACCESSORIES...
  • Page 34 KML-350MAF, MWF MODEL INDEX DESCRIPTION INSTRUCTION MANUAL UNIVERSAL BRACE HEX HEAD BOLT H. ACCESSORIES TITLE MATERIAL OR PART REQUIRED NUMBER MODEL NUMBER NUMBER PAPER 91A1CC10A 4A0363-01 5X12, SS 7B02-0512...
