Trailer Vision Digi-View Mini User Manual page 5

Parking Guideline Position Adjustment
The parking guideline position can be adjusted
up or down, to mark the image area more realistically.
There are 5 levels to choose from.
For detailed operation methods,
please refer to page P8.
Parking guidelines displayed or not displayed:
Short Press DOWN button [DEC] to switch between the Parking Guide
Lines display modes (Displayed or Not Displayed):
While the monitor is showing the image, short press the middle button
[MENU/OK] to enter the main menu interface, and 5 options are available
(Pairing, Image Parameters, Image Mirror, Parking Guideline Position
Adjustment & Software Information).
Pairing Image
Parameter
Pairing
Parameter
To adjust Brightness
Default setting, Set Upwards/Downwards
or Normal/Mirror Image.
no need to Contrast, Colour.
Operation details
operate again. Operation details as
Operation
as Image Parameter Image Mirror contents.
info.
5 levels of adjustment
Image Parking Guideline Software
Mirror Position Adjustment Information
Parking Guideline
Position Adjustment
Mirror Information
The parking guideline can
Select "Software Info",
be adjusted up and down
press [ADD] or [DEC]
as needed. Operation details
key to display software
as Parking Guideline Position version information.
Adjust info.
7
2. Image Parameter
While the monitor is showing an image, short press the middle button
[MENU/OK] to enter the main menu interface. From the 3 options.
Select Image Parameter, long press the [MENU/OK] button again,
3 Images(Brightness/ Contrast/ Color) setting interface are shown bellow:
Brightness Setting
Select the Brightness icon, press
[ADD] or [DEC] button to adjust the
brightness as shown bellow:
Contrast Setting
Select the Contract icon, press
[ADD] or [DEC] button to adjust the
contract as shown bellow:
Colour Setting
Select the Colour icon, press
[ADD] or [DEC] button to adjust
the colour as shown bellow:
3. Parking Guideline Position Adjustment
Select the "Parking Guide Position Adjustment" icon, then long press the middle
button [MENU / OK] to enter the setting interface, short press the [ADD] or [DEC]
button to choose the most suitable one from 5 levels, then short press [MENU / OK]
twice to exit.
Software
A
Brightness
Contrast
B C
8
Color
D E
