Pioneer CX-3287 Service Manual

Pioneer CX-3287 Service Manual

Cd rds receiver
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CD RDS RECEIVER
DEH-X5600BT
DEH-X6600BS
DEH-X3600S
DEH-X3600UI
This service manual should be used together with the following manual(s):
Model No.
Order No.
CRT4759
CX-3287
PIONEER CORPORATION
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2013
Mech. Module
S11.6STD
CD Mech. Module : Circuit Descriptions, Mech. Descriptions, Disassembly
1-1, Shin-ogura, Saiwai-ku, Kawasaki-shi, Kanagawa 212-0031, Japan
DEH-X5600BT/XNEW5
/XNUC
/XNUC
/XNEW5
Remarks
ORDER NO.
CRT5373
/XNEW5
K-ZZZ JULY 2013 Printed in Japan

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CX-3287 and is the answer not in the manual?

Questions and answers

Related Manuals for Pioneer CX-3287

Summary of Contents for Pioneer CX-3287

  • Page 1 PIONEER CORPORATION 1-1, Shin-ogura, Saiwai-ku, Kawasaki-shi, Kanagawa 212-0031, Japan PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A. PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936...

  • Page 2: Safety Information

    SAFETY INFORMATION CAUTION This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair complex products such as those covered by this manual. Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
  • Page 3 CAUTION Danger of explosion if battery is incorrectly replaced. Replaced only with the same or equivalent type recommended by the manufacturer. Discord used batteries according to the manufacturer's instructions. DEH-X5600BT/XNEW5...

  • Page 4: Table Of Contents

    CONTENTS SAFETY INFORMATION............................. 2 1. SERVICE PRECAUTIONS ..........................5 1.1 SERVICE PRECAUTIONS ........................5 1.2 NOTES ON SOLDERING .......................... 5 2. SPECIFICATIONS ............................6 2.1 SPECIFICATIONS ............................. 6 2.2 DISC/CONTENT FORMAT ........................8 3. BASIC ITEMS FOR SERVICE.......................... 9 3.1 CHECK POINTS AFTER SERVICING....................... 9 3.2 PCB LOCATIONS ............................

  • Page 5: Service Precautions

    1. SERVICE PRECAUTIONS 1.1 SERVICE PRECAUTIONS 1. You should conform to the regulations governing the product (safety, radio and noise, and other regulations), and should keep the safety during servicing by following the safety instructions described in this manual. 2. Before disassembling the unit, be sure to turn off the power. Unplugging and plugging the connectors during power-on mode may damage the ICs inside the unit.

  • Page 6: Specifications

    2. SPECIFICATIONS 2.1 SPECIFICATIONS DEH-X5600BT/XNEW5 General Number of channels ....2 (stereo) Power source......14.4 V DC (10.8 V to 15.1 V MP3 decoding format ...MPEG-1 & 2 Audio Layer 3 allowable) WMA decoding format ..Ver. 7, 7.1, 8, 9, 10, 11, 12 Grounding system....Negative type (2 ch audio) Maximum current consumption...
  • Page 7 DEH-X6600BS/XNUC, DEH-X3600S/XNUC General Power source ....14.4 V DC (10.8 V to 15.1 V al- USB standard specification lowable) ........USB 2.0 full speed Grounding system ....Negative type Maximum current supply Maximum current consumption ........1 A ........10.0 A USB Class ....... MSC (Mass Storage Class) Backup current....

  • Page 8: Disc/Content Format

    2.2 DISC/CONTENT FORMAT The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Pioneer Corporation is under license. Other trademarks and trade names are those of their respective owners. DEH-X5600BT/XNEW5...

  • Page 9: Basic Items For Service

    3. BASIC ITEMS FOR SERVICE 3.1 CHECK POINTS AFTER SERVICING To keep the product quality after servicing, please confirm following check points. r i f Confirm whether the customer complain has The customer complain must not be been solved. reappeared. If the customer complain occurs with the Display, audio and operations must be specific media, use it for the operation check.

  • Page 10: Jigs List

    3.3 JIGS LIST - Jigs List Name Jig No. Remarks 16P FFC GGD1310 Tuner Amp Unit - CD Core Unit Test Disc TCD-782 Checking the grating L.P.F. Checking the grating (Two pieces) - Grease List Name Name Grease No. Grease No. Remarks Remarks Grease...
  • Page 11 DEH-X5600BT/XNEW5...

  • Page 12: Block Diagram

    4. BLOCK DIAGRAM SXI TUNER TUNER AMP UNIT FM/AM TUNER IC401 TDA7706 JA401 FMMIXIN1 SXIPW DACOUTL PINDIN LNAIN IC602 TC7SH126FU I2CSCL TUN_SCL I2CSDA TUN_SDA SXIRX RSTN TUN_RST JA891 IC603 KEYAD KEYAD TC7SET08FUS1 KEYD KEYD SXITX SYSTEM MICRO JA892 (2/2) COMPUTER SXMR0 IC601 SXML0...
  • Page 13 JA251 :DEH-X5600BT/XNEW5 :DEH-X6600BS/XNUC :DEH-X3600S/XNUC SXIPW :DEH-X3600UI/XNEW5 IC602 SXIPWSENS C7SH126FU VDD3.3V ELECTRONIC VOLUME/ SOURCE SELECTOR SXIRX IC201 Q251 Q252 Q253 PM9013A IC603 7SET08FUS1 OUTPL SXITX TUNL IN5L SXML0 INAP2L JA901 MCLK EVOL_MCK FUSE 10A B.UP LRCLK EVOL_LRCK EVOL_BRCK BCLK 15 B.UP 13(12) EVOL_DATA OUTRL...

  • Page 14: Diagnosis

    5. DIAGNOSIS 5.1 OPERATIONAL FLOWCHART Power ON Vcc : Pin 15, 26, 51, 93, 104, 130 Vcc = 1.2 V PVcc = 3.3 V PVcc : Pin 3, 11, 22, 34, 44, 58, 81, 89, 100, 119, 126, 135 BSENS Pin 108 BSENS = L ASENS...

  • Page 15: Error Code List

    5.2 ERROR CODE LIST ERROR CODES If a CD memory device is inoperable, or operation of such media is stopped by an error, the error mode is established and a cause of the error is displayed by an error code. Indication of error codes is intended to reduce the number of calls from customers and facilitate failure analysis and repair work in servicing.
  • Page 16 Transfer the audio files to the USB storage device fails to disappear even after the engine is and connect. switched off/on, contact your dealer or an authorized Pioneer Service Station for The connected USB storage device has security en- assistance. abled.
  • Page 17 NO BT DEVICE GO TO BT MENU TO REGISTER If the error message is still displayed after performing the above action, please contact your No Bluetooth device found. dealer or an authorized Pioneer Service Station. Follow the instructions that appear on the screen. Pandora CONN.
  • Page 18 If the message fails to disappear even after the engine is switched off/on, contact your dealer or NO NETWORK an authorized Pioneer Service Station for The connected device is out of area. assistance. Connect the connected device to a network.

  • Page 19: Connector Function Description

    5.3 CONNECTOR FUNCTION DESCRIPTION DEH-X5600BT/XNEW5 DEH-X3600S/XNUC DEH-X3600UI/XNEW5 Sirius XM BUS(Except DEH-X3600UI) ANTENNA INPUT MICROPHONE WIRED FRONT INPUT REMOTE OUTPUT 15 13 11 9 7 5 3 1 (DEH-X5600BT) CONTROL AUX2 INPUT Sirius XM BUS 16 14 12 10 8 6 4 2 (DEH-X3600UI) REAR OUTPUT or SUBWOOFER OUTPUT...

  • Page 20: Service Mode

    6. SERVICE MODE 6.1 DISPLAY TEST MODE 1 [How to enter Test mode] Press and hold "PHONE (DEH-X5600BT, DEH-X6600BS), MIX (DEH-X3600S, DEH-X3600UI)" and "LIST" buttons together, and turn BUP and ACC on. SOURCE LIST PHONE (DEH-X5600BT, DEH-X6600BS) (DEH-X3600S, DEH-X3600UI) BAND ROTARY Grille condition Conf.

  • Page 21: Display Test Mode 2

    6.2 DISPLAY TEST MODE 2 The information such as the system microcomputer version is checked. [How to enter Test mode] Press and hold "1" and "3" buttons together, and turn BUP and ACC on. [Operation key] Operation key Processing Remarks Enter display test mode 1 + 3 Switch to next test mode...

  • Page 22: Software Version Up Method

    6.3 SOFTWARE VERSION UP METHOD Overview This mode is used for upgrading the MCU software of system using USB memory. How to enter in USB rewriting mode Press and hold "1" and "2" buttons together, and turn BUP and ACC on. USB rewriting operation flow Explanatory note Screen display and ON/OFF of illumination...

  • Page 23: Cd Test Mode

    6.4 CD TEST MODE - Flow Chart To enter the test mode: [4] + [6] -> BUP + ACC ON [Key] [CD] or [SOURCE] Source ON Contents Display [BAND] Power On RF AMP (T.Offset is adjusted) Gain switching 00 00 00 [BAND] [>] [<]...

  • Page 24: Disassembly

    7. DISASSEMBLY While the photograph shown is slightly different from this model in shape, the disassembly procedure is the same. - Removing the Panel Assy (Fig.1) Release the two latches. Release the two latches and then remove the Panel Assy. Panel Assy Fig.1 - Removing the CD Mechanism Module (Fig.2)
  • Page 25 - Removing the Tuner Amp Unit and the BT Unit (Fig.3) Tuner Amp Unit Disconnect the connector. Remove the two screws. Remove the screw. (X5600BT/XNEW5,X6600BS/XNUC) Remove the two screws and then remove the Tuner Amp Unit. Remove the screw and then remove the BT Unit.
  • Page 26 Disassembling the Panel Part (Fig.5, 6) 1. Remove the arm while bending the rib of the panel upward. Fig.5 2. Press the upside hook and the bottom side hook of the button at the same time, and pull out the button. Fig.6 Assembling the Panel Part (Fig.7, 8, 9) 1.
  • Page 27 3. Fit the spring in the groove at the position shown in the figure. 4. Fit the boss on the lower side of the arm in the lower hole of the panel, and then warp the rib on the panel in the direction shown in the figure and fit the boss of the arm in the panel.
  • Page 28 How to carry the mecha unit 1. Hold the designated points (shown with dashed lines) of the upper chassis and the front/rear bracket. 2. Be careful not to hold the solid line portions or the CRG mecha part or insert foreign substances, to prevent distortion. 3.
  • Page 29 How to remove the PU unit 1. Create an empty-clamp state according to “How to create empty clamp state (motor drive)”. 2. Hook the feeding screw biasing spring to a tentative hooking portion (Fig 2b). Be careful not to get injured by the spring edge.

  • Page 30: Each Setting And Adjustment

    8. EACH SETTING AND ADJUSTMENT 8.1 CD ADJUSTMENT 1) Cautions on adjustments 2) Test mode This mode is used to adjust the CD mechanism module. In this product the single voltage (3.3 V) is used for the regulator. The reference voltage is the REFO1 (1.65 V) To enter the test mode.

  • Page 31: Checking The Grating After Changing The Pickup Unit

    8.2 CHECKING THE GRATING AFTER CHANGING THE PICKUP UNIT Note : The grating angle of the PU unit cannot be adjusted after the PU unit is changed. The PU unit in the CD mechanism module is adjusted on the production line to match the CD mechanism module and is thus the best adjusted PU unit for the CD mechanism module.
  • Page 32 Grating waveform Ech -> Xch 20 mV/div, AC Fch -> Ych 20 mV/div, AC 0 degrees 30 degrees 45 degrees 60 degrees 75 degrees 90 degrees DEH-X5600BT/XNEW5...

  • Page 33: Pcl Output Confirmation

    8.3 PCL OUTPUT CONFIRMATION - PCL Output In the normal operation mode (with the detachable panel installed, the ACC switched ON, the standby mode cancelled), shift the TESTIN IC601(Pin 117) terminal to H. The clock signal is output from the PCL terminal IC601(Pin139). The frequency of the clock signal is 600 kHz that is divided by 20th of the oscillation frequency of X601 (12MHz).

  • Page 34: Packing

    9.1 PACKING X5600BT/XNEW5 X3600UI/XNEW5 X5600BT/XNEW5 X6600BS/XNUC X3600S/XNUC X5600BT/XNEW5 X3600UI/XNEW5 X5600BT/XNEW5 X6600BS/XNUC X5600BT/XNEW5 X3600UI/XNEW5 X6600BS/XNUC X6600BS/XNUC X3600S/XNUC X3600S/XNUC DEH-X5600BT/XNEW5...
  • Page 35 (1) PACKING SECTION PARTS LIST Mark No. Description Part No. Mark No. Description Part No. 12-2 Quick Start Guide See Contrast table (2) Protector CHP4594 12-3 Installation Manual See Contrast table (2) Microphone Assy See Contrast table (2) 12-4 Caution Card See Contrast table (2) Holder See Contrast table (2)
  • Page 36 * QRB3336 Finnish * QRB3337 Danish * QRB3338 Portuguese * QRB3339 Greek * QRB3340 Turkish All operation manuals are supplied in PDF files by the CD-ROM. Regarding the availability of paper manual, contact Pioneer Service representative in your region. DEH-X5600BT/XNEW5...
  • Page 37 DEH-X5600BT/XNEW5...

  • Page 38: Exterior

    9.2 EXTERIOR X6600BS/XNUC X3600S/XNUC X5600BT/XNEW5 X6600BS/XNUC X3600UI/XNEW5 X6600BS/XNUC X5600BT/XNEW5 X3600S/XNUC X6600BS/XNUC X5600BT/XNEW5 X3600UI/XNEW5 X5600BT/XNEW5 X6600BS/XNUC DEH-X5600BT/XNEW5...
  • Page 39 (1) EXTERIOR SECTION PARTS LIST Mark No. Description Part No. Mark No. Description Part No. Detachable Grille Assy See Contrast table (2) Screw ASZ26P050FTC Screw BPZ20P100FTC Screw BSZ26P060FTC Spring CBH2210 Screw BSZ26P080FTC Button (EJECT) QAC3131 Screw BSZ26P120FTC Button See Contrast table (2) CD Mechanism Module (S11.6VA) CXK5805 Button (DETACH)

  • Page 40: Cd Mechanism Module

    9.3 CD MECHANISM MODULE (A) : GEM1024 (B) : GEM1043 DEH-X5600BT/XNEW5...
  • Page 41 CD MECHANISM MODULE SECTION PARTS LIST Mark No. Description Part No. Mark No. Description Part No. Damper CNW1198 ..Screw BSZ20P040FTC CNW1726 Screw(M2 x 4) CBA1835 Motor Unit(M2)(LOAD/CRG) CXC4026 Washer CBF1038 Screw Unit CXC8894 Spring CBH3010 Arm Assy CXE6232 Washer CBF1037 Spring CBH2855...

  • Page 42: Schematic Diagram

    10. SCHEMATIC DIAGRAM 10.1 TUNER AMP UNIT (GUIDE PAGE) Note: When ordering service parts, be sure to refer to " EXPLODED VIEWS AND PARTS LIST" or "ELECTRICAL PARTS LIST". Large size SCH diagram *only A, D C457 4700p/25 TUNR TUNER C456 4700p/25 FM: -10.6 dBs TUNL...
  • Page 43 CN701 C707 *only A, D *only B, C CN701 FM: -1.7 dBs FM: -5.7 dBs C708 TUNER AMP UNIT AM: -1.4 dBs AM: -5.5 dBs VKN1192- R720 C236 C233 1u/10 C242 AUX:+9.1 dBs AUX:+9.3 dBs C202 1u/10 CD:+9.3 dBs CD:+9.6 dBs C221 USB:+9.3 dBs USB:+9.7 dBs...
  • Page 44 The pin number of left side is a number on the PCB (silk printing). PREOUT The pin number of right side (in the IC frame) means the pin number of IC itself. DEH-X5600BT/XNEW5...
  • Page 45 POWER SUPPLY pin number of IC itself. DEH-X5600BT/XNEW5...
  • Page 46 DEH-X5600BT/XNEW5...
  • Page 47 W.REM DEH-X5600BT/XNEW5...

  • Page 48: Keyboard Unit

    10.2 KEYBOARD UNIT GRILLE uCON KEY MATRIX 1u/10 C1804 S1821 S1822 S1823 S1824 X1801 5MHz CSS1547- CSG1155- CSG1155- CSG1155- CSG1155- DGND LEFT BAND EJECT RIGHT KST0 DGND SEG19 DPDT S1826 S1828 S1832 SEG20 URX/P35 KYDT UTX/P34 SEG21 RMIN/P73/INT/T0IN SEG22 KDT3 CSG1155- CSG1155- CSG1155-...
  • Page 49 KEYBOARD UNIT REFERENEC AREA MAP S1824 GRILLE uCON & LCD :1801-1820 DEH-X5600BT/XNEW5 KEY MATRIX&ROTARY :1821-1850 CSG1155- :1851-1910 DEH-X6600BS/XNUC BAND :1911-1920 :1921-1930 DEH-X3600S/XNUC CONNECTOR :1931-1940 S1832 DEH-X3600UI/XNEW5 REMOTE :1941-1950 SOURCE CSG1155- KYDT BACK DPDT S1837 CSG1155- DGND DGND SWVDD S1830 CN1931 CKS6451 DGND ILMGND...

  • Page 50: Cd Core Unit (S11.6Va)

    10.3 CD CORE UNIT (S11.6VA) PU UNIT(P11)(SERVICE) CXX4754 V3R3 PUEN Q102 Vref LTA123JUB R111 R110 LD_CURRENT Q101 R109 1.5k 2SA1577(QR) ATEST VREF A.Vdd1 C221 V+3A A.GND1 0.1u/10 C216 1500p/50 AGCO RFAGC C220 HOLOGRAM UNIT C219 0.1u/10 AGCI 0.1u/10 FOCUS ACT C228 R229 TRK ACT...
  • Page 51 CD CORE UNIT(S11.6VA) C302 C303 1000p/50 1000p/50 PUEN C304 0.022u/16 C305 0.1u/10 R310 4.7k R311 4.7k R312 4.7k R313 4.7k TEMP TEMP R215 TH201 TESTIN ATEST BSCK0 /WAIT A.Vdd1 A.GND1 C216 R291 1500p/50 LRCK AGCO /WAIT C283 TX/EMPH C219 BCLK AGCI LRCK C281...

  • Page 52: Bt Unit

    10.4 BT UNIT 1u/10 MIC_BIAS MIC1P BT18ON MIC1N BT1.8V 3.3V BOOTS BT1.8V RESET BT1.8V BT3.3V BT3.3V DBG_Tx IC21 DBG_Rx VOUT VSS1 VSS2 ON/OFF S-1172B18-E6 CN21 CKS6346- BT MODULE DEH-X5600BT/XNEW5...
  • Page 53 BT UNIT (only A, B) DEH-X5600BT/XNEW5 DEH-X6600BS/XNUC DEH-X3600S/XNUC DEH-X3600UI/XNEW5 CN23 CKS3857-A BTDATA BTSCK BTRLCK CN971 NRST_CPU SYSTOBT BTTOSYS BT3.3V IC22 S-1206B33-U3 MIC1P MIC1N DEH-X5600BT/XNEW5...

  • Page 54: Waveforms

    10.5 WAVEFORMS - CD CORE UNIT(S11.6VA) Note : 1. The encircled numbers denote measuring points in the circuit diagram. 2. Reference voltage REFO1(1.65 V) 1DSCSNS 1DSCSNS 5 V/div 500 ms/div 5 V/div 500 ms/div 3HOME 5CLCONT 5 V/div 5 V/div 4LOEJ 4LOEJ 5 V/div...
  • Page 55 fRFAGC fRFAGC gLRCK 1 V/div 2 ms/div 1 V/div 200 ms/div 2 V/div 10 us/div hBCLK 500 mV/div 1 V/div 2 V/div 9TIN 8CIN 500 mV/div 500 mV/div DOUT(DATA) 2 V/div 7SIN 2 V/div 32 Tracks Jump waveform Search operation(Outter to Inner) Digital Out waveform (Zoom of 100 Track Jump waveform) Ref.:...

  • Page 56: Pcb Connection Diagram

    11. PCB CONNECTION DIAGRAM 11.1 TUNER AMP UNIT NOTE FOR PCB DIAGRAMS TUNER AMP UNIT 1.The parts mounted on this PCB include all necessary parts for several destination. For further information for respective destinations, be sure W.REM to check with the schematic dia- W.REM, JA891 gram.
  • Page 57 SIDE A JA961 POWER SUPPLY C326 L901 JA901 IC301 VA961 C325 R961 C963 VA962 C333 C334 C332 R962 VA966 R964 C335 C961 C307 C303 C313 C305 D902 D901 R963 C324 C323 R965 D302 C321 FM/AM D301 C314 R304 C310 C901 L951 ANTENNA C312...
  • Page 58 TUNER AMP UNIT TESTIN DEH-X5600BT/XNEW5...
  • Page 59 SIDE B DEH-X5600BT/XNEW5...

  • Page 60: Keyboard Unit

    11.2 KEYBOARD UNIT KEYBOARD UNIT SIDE A KEYBOARD UNIT SIDE B C1941 R1943 D1923 C1923 C1865 C1913 C1867 C1914 C1866 R1922 R1872 R1873 CN1931 CN801 C1803 C1801 C1802 D1801 R1810 C1852 R1851 R1852 C1868 C1869 C1870 C1861 C1915 C1860 C1859 R1857 R1856 C1858...
  • Page 61 DEH-X5600BT/XNEW5...

  • Page 62: Cd Core Unit (S11.6Va)

    11.3 CD CORE UNIT (S11.6VA) CD CORE UNIT(S11.6VA) SIDE A PU UNIT(P11) (SERVICE) TH201 R254 C235 CN101 LOAD/CRG R246 MOTOR R232 HOME S901 C201 CN702 R253 R245 C238 C710 C299 R706 R297 C205 C705 C707 C220 R702 R701 SPDL MOTOR CN701 CN701 C702...
  • Page 63 CD CORE UNIT(S11.6VA) SIDE B C202 R108 Q102 Q101 C104 X201 R109 R294 C203 C209 C233 C101 R237 C224 C210 C223 C211 R110 R111 R240 R282 C204 C284 R281 C222 IC201 C281 C218 C301 C282 R216 R218 R291 C219 R229 C217 C283 C216...

  • Page 64: Bt Unit

    11.4 BT UNIT BT UNIT SIDE A (only A, B) CN971 BT MODULE DEH-X5600BT/XNEW5 DEH-X6600BS/XNUC DEH-X3600S/XNUC DEH-X3600UI/XNEW5 BT UNIT SIDE B (only A, B) DEH-X5600BT/XNEW5...

  • Page 65: Electrical Parts List

    12. ELECTRICAL PARTS LIST NOTE: Parts whose parts numbers are omitted are subject to being not supplied. The part numbers shown below indicate chip components. Chip Resistor RS1/_S___J,RS1/__S___J Chip Capacitor (except for CQS..) CKS.., CCS.., CSZS..The > mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation.
  • Page 66 Circuit Symbol and No. Part No. Circuit Symbol and No. Part No. D 902 (A,134,127) Diode 1SR154-400 R 266 (A,17,129) (B) RS1/16SS0R0J R 267 (A,15,129) (A,C,D) RS1/16SS0R0J D 911 (A,159,66) Diode CRG03 D 912 (A,162,66) Diode CRG03 R 301 (A,68,127) RS1/16SS471J D 941 (A,129,113) Diode(A,D)
  • Page 67 Circuit Symbol and No. Part No. Circuit Symbol and No. Part No. R 633 (A,106,92) RS1/16SS101J R 812 (A,112,21) RS1/10SR222J R 634 (A,103,90) RS1/16SS102J R 813 (A,107,16) RS1/10SR222J R 635 (A,102,89) RS1/16SS102J R 814 (A,101,19) RS1/10SR222J R 636 (A,99,91) RS1/16SS473J R 815 (A,100,19) RS1/16SS822J...
  • Page 68 Circuit Symbol and No. Part No. Circuit Symbol and No. Part No. C 216 (A,88,101) 10 uF CCG1192 C 424 (A,144,101) CKSSYB103K16 C 217 (A,92,100) CKSSYB104K10 C 425 (A,143,99) 10 uF CCG1192 C 218 (A,112,109) XCEVW470M16 C 426 (A,143,97) CKSSYB104K10 C 219 (A,109,103) 10 uF CCG1192...
  • Page 69 Circuit Symbol and No. Part No. Circuit Symbol and No. Part No. MISCELLANEOUS C 625 (A,104,90) CKSSYB104K10 C 626 (A,99,79) CKSSYB104K10 C 627 (A,95,81) CCSSCH220J50 IC 1802 (B,84,22) IC PDC202B C 628 (A,94,81) CCSSCH220J50 IC 1851 (B,47,21) IC BH2228FV IC 1941 (A,155,39) IR RC REC Module(B,C) PNJ4833M C 629...
  • Page 70 Circuit Symbol and No. Part No. Circuit Symbol and No. Part No. R 1864 (B,17,8) RS1/16SS680J R 291 (B,34,35) RS1/16SS560J R 1866 (B,11,20) RS1/16SS680J R 294 (B,28,49) RS1/16SS471J R 1868 (B,115,25) RS1/16SS680J R 303 (A,28,12) RS1/16SS123J R 1870 (B,125,27) RS1/16SS680J R 304 (A,29,11) RS1/16SS123J...
  • Page 71 Circuit Symbol and No. Part No. MISCELLANEOUS IC 21 (A,8,48) Regulator IC S-1172B18-E6 IC 22 (A,21,46) IC S-1206B33-U3 CN21 (A,34,27) Connector CKS6346 CN23 (A,42,44) Connector CKS3857 RESISTORS R 28 (A,42,31) RS1/10SR222J R 29 (A,30,41) RS1/10SR102J R 30 (A,30,37) RS1/10SR102J R 38 (A,42,17) RS1/10SR0R0J R 39...
