HEX Hixon Assembly Manual

Large metal storage shed
Hide thumbs

Advertisement

Quick Links

Download this manual
Hixon
Large Metal Storage Shed Assembly Guide
6 x 6 ft (1.8 x 1.8 m)
IMPORTANT: PLEASE REGISTER YOUR HEX LIVING PRODUCT BEFORE ASSEMBLY
Using the unique serial number, simply register your product at www.hexliving.co.uk
to access and download the HEX Living lifetime warranty and video assembly instructions.
Affix Serial Number
HERE
Doc Ref: 699-0809/B

Advertisement

loading
Need help?

Need help?

Do you have a question about the Hixon and is the answer not in the manual?

Questions and answers

Related Manuals for HEX Hixon

Summary of Contents for HEX Hixon

  • Page 1 6 x 6 ft (1.8 x 1.8 m) IMPORTANT: PLEASE REGISTER YOUR HEX LIVING PRODUCT BEFORE ASSEMBLY Using the unique serial number, simply register your product at www.hexliving.co.uk to access and download the HEX Living lifetime warranty and video assembly instructions. Affix Serial Number HERE...
  • Page 2 CARING FOR YOUR HEX LIVING PRODUCT Your HEX Living product is designed to stand the test of �me, which is why we’re happy to offer a life�me warranty on our products. With zero maintenance required, simply assemble your HEX Living product and enjoy pu�ng it to great use in your garden.
  • Page 3 Hixon: Assembly Guide Part Ref: 0215-01 Part Ref: 0212-03 Qty: x2 Qty: x3 Part Ref: 0212-01 Part Ref: 0205-11 Qty: x2 Qty: x1 Part Ref: 0212-02 Part Ref: 0205-12 (1850 x 625mm) Qty: x3 Qty: x6 Part Ref: 0205-13 (1850 x 425mm)
  • Page 4 Hixon: Assembly Guide Part Ref: 0205-14 (1885mm Long) Part Ref: 0212-04 Qty: x2 Qty: x2 Part Ref: 0212-13 Part Ref: 0205-15 (2100mm Long) Qty: x2 Qty: x2 Part Ref: 0212-14 Qty: x2 Part Ref: 0215-06 Part Ref: 0205-16 (R/H) Qty: x2...
  • Page 5 Hixon: Assembly Guide Part Ref: 0212-07 Qty: x2 Part Ref: 0215-03 Qty: x1 Part Ref: 0215-11 Qty: x1 Part Ref: 0215-05 Qty: x1 Part Ref: 0212-11 Part Ref: 0205-36 (Right-hand) Qty: x1 Qty: x1 Part Ref: 0212-12 Part Ref: 0205-37 (Le�-hand)
  • Page 6 Hixon: Assembly Guide ENSURE ALL ITEMS LISTED ARE PRESENT PRIOR TO STARTING ASSEMBLY PROCEDURE SCALE OF ITEMS WILL VARY TO AID VISUAL IDENTIFICATION Part Ref: 0205-39 Qty: x4 Part Ref: 0215-09 Qty: x2 Part Ref: 0205-38-01 Qty: x2 Part Ref: 0215-10...
  • Page 7 Hixon: Assembly Guide ENSURE ALL ITEMS LISTED ARE PRESENT PRIOR TO STARTING ASSEMBLY PROCEDURE SCALE OF ITEMS WILL VARY TO AID VISUAL IDENTIFICATION Part Ref: 0203-03 Part Ref: 0205-57 Qty: x4 Qty: x4 Part Ref: 0205-63 Qty: x2 Part Ref: 0203-15...
  • Page 8 Hixon: Assembly Guide ASSEMBLY STAGE 1 LOCATE AND SECURE A CORNER BRACE 0203-03 AT EACH LOCATION INDICATED. 0215-01 0212-01 0203-03 (x4) 0205-01 0212-01 0203-03 PLEASE NOTE: SECTION VIEW OF TYPICAL FIXING METHOD SECURE EACH CORNER BRACE 0203-03 AS SHOWN ABOVE.
  • Page 9 Hixon: Assembly Guide ASSEMBLY STAGE 2 LOCATE AND SECURE A FLOOR BRACE 0212-02 AT EACH LOCATION INDICATED. 0212-02 (x3) 0212-02 PLEASE NOTE: ENSURE TOP OF FLOOR BRACE IS LEVEL WITH TOP OF FLOOR RAIL SLOT EACH FLOOR BRACE 0212-02 INTO POSITION AS SHOWN ABOVE.
  • Page 10 Hixon: Assembly Guide ASSEMBLY STAGE 3 LOCATE AND SECURE A FLOOR BRACE 0215-08 AT EACH LOCATION INDICATED. 0215-08 (x2) 0215-08 SLOT EACH FLOOR BRACE 0215-08 INTO POSITION AS SHOWN ABOVE. SLOT EACH FLOOR BRACE 0215-08 INTO POSITION AS SHOWN ABOVE.
  • Page 11 Hixon: Assembly Guide ASSEMBLY STAGE 4 LOCATE AND LOOSELY ATTACH WALL PANEL 0205-12 (1850 x 625mm). 0205-12 0205-12 LOOSELY ATTACH WALL PANEL AT x2 LOCATIONS INDICATED ONLY. LOCATE WALL PANEL 0205-12 INTO POSITION AS SHOWN ABOVE. IMPORTANT: ENSURE PANEL IS IN THE CORRECT ORIENTATION.
  • Page 12 Hixon: Assembly Guide ASSEMBLY STAGE 5 LOCATE AND LOOSELY ATTACH CORNER POST 0205-15 (2100mm). OUTSIDE x3 HOLES AT TOP INSIDE OUTSIDE 0205-15 INSIDE LOCATE FIRST WALL PANEL 0205-12 (1850 x 625mm) AS SHOWN ABOVE. IMPORTANT: ENSURE PANEL IS IN THE CORRECT ORIENTATION.
  • Page 13 Hixon: Assembly Guide ASSEMBLY STAGE 6 LOCATE AND LOOSELY ATTACH MID CENTRE BRACE 0212-03. 0212-03 LOCATE AND LOOSELY ATTACH MID CENTRE BRACE 0212-03 AS SHOWN AT LOOSELY ATTACH AT x3 LOCATIONS INDICATED ONLY. x3 LOCATIONS INDICATED ABOVE. IMPORTANT: DO NOT SECURE AT OUTER FIXING POINT INDICATED.
  • Page 14 Hixon: Assembly Guide ASSEMBLY STAGE 7 LOCATE AND LOOSELY ATTACH WALL PANEL 0205-12 (1850 x 625mm). 0205-12 OUTSIDE INSIDE OUTSIDE INSIDE LOOSELY ATTACH AT x3 LOCATIONS INDICATED ONLY. LOCATE AND LOOSELY ATTACH WALL PANEL AT x3 LOCATIONS INDICATED. IMPORTANT: ENSURE PANEL IS IN THE CORRECT ORIENTATION.
  • Page 15 Hixon: Assembly Guide ASSEMBLY STAGE 8 LOCATE AND LOOSELY ATTACH WALL PANEL 0205-12 (1850 x 625mm). 0205-13 OUTSIDE INSIDE OUTSIDE INSIDE LOOSELY ATTACH AT x2 LOCATIONS INDICATED ONLY. LOCATE AND LOOSELY ATTACH WALL PANEL AT x2 LOCATIONS INDICATED. IMPORTANT: ENSURE PANEL IS IN THE CORRECT ORIENTATION.
  • Page 16 Hixon: Assembly Guide ASSEMBLY STAGE 9 LOCATE AND LOOSELY ATTACH CORNER POST 0205-14 (1885mm). x2 HOLES AT TOP 0205-14 LOCATE CORNER POST 0205-14 (1885mm) AS SHOWN ABOVE. LOOSELY ATTACH CORNER POST AT x2 LOCATIONS INDICATED ONLY. IMPORTANT: DO NOT SECURE AT UPPER FIXING POINT AT THIS STAGE.
  • Page 17 Hixon: Assembly Guide ASSEMBLY STAGE 10 LOCATE AND LOOSELY ATTACH WALL PANEL 0205-13 (1850 x 425mm). 0205-13 OUTSIDE INSIDE OUTSIDE INSIDE LOCATE FIRST WALL PANEL 0205-13 (1850 x 425mm) AS SHOWN ABOVE. LOOSELY ATTACH WALL PANEL AT x2 LOCATIONS INDICATED ONLY.
  • Page 18 Hixon: Assembly Guide ASSEMBLY STAGE 11 LOCATE AND LOOSELY ATTACH WALL PANEL 0205-12 (1850 x 625mm). 0205-12 OUTSIDE INSIDE OUTSIDE INSIDE LOCATE WALL PANEL 0205-12 INTO POSITION AS SHOWN ABOVE. LOOSELY ATTACH BACK WALL PANEL AT x3 LOCATIONS INDICATED ONLY.
  • Page 19 Hixon: Assembly Guide ASSEMBLY STAGE 12 LOCATE AND LOOSELY ATTACH LONG CENTRE BRACE 0212-03. 0212-03 LOCATE AND LOOSELY ATTACH LONG CENTRE BRACE 0212-03 AS SHOWN AT LOOSELY ATTACH AT x5 LOCATIONS INDICATED ONLY. x5 LOCATIONS INDICATED ABOVE. IMPORTANT: DO NOT SECURE AT OUTER FIXING POINT INDICATED.
  • Page 20 Hixon: Assembly Guide ASSEMBLY STAGE 13 LOCATE AND LOOSELY ATTACH WALL PANEL 0205-12 (1850 x 625mm). 0205-12 OUTSIDE INSIDE OUTSIDE INSIDE LOCATE AND LOOSELY ATTACH WALL PANEL AT x3 LOCATIONS INDICATED. LOOSELY ATTACH AT x3 LOCATIONS INDICATED ONLY. IMPORTANT: ENSURE PANEL IS IN THE CORRECT ORIENTATION.
  • Page 21 Hixon: Assembly Guide ASSEMBLY STAGE 14 LOCATE AND LOOSELY ATTACH CORNER POST 0205-14 (1885mm). x2 HOLES AT TOP 0205-14 LOCATE CORNER POST 0205-14 (1885mm) AS SHOWN ABOVE. LOOSELY ATTACH CORNER POST AT x2 LOCATIONS INDICATED ONLY. IMPORTANT: DO NOT SECURE AT UPPER FIXING POINT AT THIS STAGE.
  • Page 22 Hixon: Assembly Guide ASSEMBLY STAGE 15 LOCATE AND LOOSELY ATTACH WALL PANEL 0205-13 (1850 x 425mm). 0205-13 OUTSIDE INSIDE OUTSIDE INSIDE LOCATE FIRST WALL PANEL 0205-13 (1850 x 425mm) AS SHOWN ABOVE. LOOSELY ATTACH WALL PANEL AT x2 LOCATIONS INDICATED ONLY.
  • Page 23 Hixon: Assembly Guide ASSEMBLY STAGE 16 LOCATE AND LOOSELY ATTACH WALL PANEL 0205-12 (1850 x 625mm). 0205-12 OUTSIDE INSIDE OUTSIDE INSIDE LOCATE WALL PANEL 0205-12 INTO POSITION AS SHOWN ABOVE. LOOSELY ATTACH WALL PANEL AT x3 LOCATIONS INDICATED ONLY. IMPORTANT: ENSURE PANEL IS IN THE CORRECT ORIENTATION.
  • Page 24 Hixon: Assembly Guide ASSEMBLY STAGE 17 LOCATE AND LOOSELY ATTACH MID CENTRE BRACE 0212-03. 0212-03 LOCATE AND LOOSELY ATTACH MID CENTRE BRACE 0212-03 AS SHOWN AT LOOSELY ATTACH AT x5 LOCATIONS INDICATED ONLY. x5 LOCATIONS INDICATED ABOVE. IMPORTANT: DO NOT SECURE AT OUTER FIXING POINT INDICATED.
  • Page 25 Hixon: Assembly Guide ASSEMBLY STAGE 18 LOCATE AND LOOSELY ATTACH WALL PANEL 0205-12 (1850 x 625mm). 0205-12 OUTSIDE INSIDE OUTSIDE INSIDE LOCATE AND LOOSELY ATTACH WALL PANEL AT x3 LOCATIONS INDICATED. LOOSELY ATTACH AT x3 LOCATIONS INDICATED ONLY. IMPORTANT: ENSURE PANEL IS IN THE CORRECT ORIENTATION.
  • Page 26 Hixon: Assembly Guide ASSEMBLY STAGE 19 LOCATE AND LOOSELY ATTACH CORNER POST 0205-15 (2100mm). 0205-15 LOCATE CORNER POST 0205-15 (2100mm) AS SHOWN ABOVE. LOOSELY ATTACH CORNER POST AT x2 LOCATIONS INDICATED ONLY. IMPORTANT: DO NOT SECURE AT UPPER FIXING POINT AT THIS STAGE.
  • Page 27 Hixon: Assembly Guide ASSEMBLY STAGE 20 LOCATE AND LOOSELY ATTACH RIGHT-HAND DOOR POST 0205-16. 0205-16 INSIDE OUTSIDE INSIDE OUTSIDE LOCATE RIGHT-HAND DOOR POST 0205-16 AS SHOWN ABOVE. SECURE DOOR POST AT x2 LOCATIONS INDICATED. IMPORTANT: DO NOT SECURE AT UPPER FIXING POINT AT THIS STAGE.
  • Page 28 Hixon: Assembly Guide ASSEMBLY STAGE 21 LOCATE AND LOOSELY ATTACH LEFT-HAND DOOR POST 0205-17. 0205-17 INSIDE OUTSIDE INSIDE OUTSIDE LOCATE RIGHT-HAND DOOR POST 0205-17 AS SHOWN ABOVE. SECURE DOOR POST AT x2 LOCATIONS INDICATED. IMPORTANT: DO NOT SECURE AT UPPER FIXING POINT AT THIS STAGE.
  • Page 29 Hixon: Assembly Guide ASSEMBLY STAGE 22 LOCATE AND LOOSELY ATTACH SHORT ROOF RAIL 0212-04. 0212-04 LOCATE SHORT ROOF RAIL 0212-04 AS SHOWN ABOVE. LOOSELY ATTACH AT x9 LOCATIONS INDICATED.
  • Page 30 Hixon: Assembly Guide ASSEMBLY STAGE 23 LOCATE AND LOOSELY ATTACH SHORT ROOF RAIL 0212-04. 0212-04 LOCATE SHORT ROOF RAIL 0212-04 AS SHOWN ABOVE. LOOSELY ATTACH AT x9 LOCATIONS INDICATED.
  • Page 31 Hixon: Assembly Guide ASSEMBLY STAGE 24 LOCATE AND LOOSELY ATTACH LONG ROOF RAIL 0215-02. 0215-02 LOCATE LONG ROOF RAIL 0215-02 AS SHOWN ABOVE. LOOSELY ATTACH AT x9 LOCATIONS INDICATED.
  • Page 32 Hixon: Assembly Guide ASSEMBLY STAGE 25 LOCATE AND LOOSELY ATTACH LONG ROOF RAIL 0215-02. 0215-02 SLOT INTO DOOR POST LOCATE LONG TOP RAIL 0215-02 AS SHOWN ABOVE. LOOSELY ATTACH AT x2 LOCATIONS INDICATED.
  • Page 33 Hixon: Assembly Guide ASSEMBLY STAGE 26 LOCATE GROUND ANCHOR BRACKETS 0205-57. 0205-57 (x4) THESE BRACKETS SECURED USING GROUND ANCHOR KIT ONCE SHED IS FULLY ASSEMBLED (SEE PAGE ‘i’) PLEASE NOTE: THESE BRACKETS ARE NOT SECURED ONTO THE FRAME, THEY LOCATE x4 GROUND ANCHOR BRACKETS 0205-57 AS SHOWN ABOVE, THESE ALLOW FOR FIXING TO A CONCRETE BASE AT A LATER STAGE IF DESIRED.
  • Page 34 Hixon: Assembly Guide ASSEMBLY STAGE 27 LOCATE FLOOR PANELS 0215-09. 0215-09 (x2) IMPORTANT: ENSURE THE HEXAGON PATTERN IS FACE UP. SLOT FIRST 3 FLOOR PANELS 0215-09 INTO THE BACK HALF OF FLOOR FRAME. IMPORTANT: THESE FLOOR PANELS DO NOT HAVE A CUT-OUT.
  • Page 35 Hixon: Assembly Guide ASSEMBLY STAGE 28 LOCATE FLOOR PANELS 0215-10. 0215-10 IMPORTANT: ENSURE THE HEXAGON PATTERN IS FACE UP. SLOT LEFT-HAND FLOOR PANEL 0215-10 INTO THE FRONT HALF OF FLOOR FRAME.
  • Page 36 Hixon: Assembly Guide ASSEMBLY STAGE 29 LOCATE AND SECURE DOOR STRIP 0205-11. 0205-11 LOCATE DOOR STRIP 0205-11 AS SHOWN. SECURE DOOR STRIP ONTO FLOOR PANELS AT x6 LOCATIONS INDICATED. IMPORTANT: ENSURE DOOR STRIP IS PUSHED AGAINST DOOR POST RETURN. PLEASE NOTE: THE FIXING USED IS A SELF DRILLING COMPONENT.
  • Page 37 Hixon: Assembly Guide ASSEMBLY STAGE 30 LOCATE AND SECURE ROOF SIDE INFILL 0212-11. 0212-11 LOCATE ROOF SIDE INFILL 0212-11 AS SHOWN ABOVE. SECURE ROOF SIDE INFILL AT LOCATIONS INDICATED AS SHOWN ABOVE.
  • Page 38 Hixon: Assembly Guide ASSEMBLY STAGE 31 LOCATE AND SECURE ROOF SIDE INFILL 0212-12. 0212-12 LOCATE ROOF SIDE INFILL 0212-11 AS SHOWN ABOVE. SECURE ROOF SIDE INFILL AT LOCATIONS INDICATED AS SHOWN ABOVE.
  • Page 39 Hixon: Assembly Guide ASSEMBLY STAGE 32 LOCATE AND SECURE ROOF REAR INFILL 0215-11. 0215-11 LOCATE ROOF REAR INFILLS 0215-11 AS SHOWN ABOVE. SECURE ROOF REAR INFILL AT x9 LOCATIONS INDICATED AS SHOWN ABOVE.
  • Page 40 Hixon: Assembly Guide ASSEMBLY STAGE 33 ROOF FRONT INFILL 0215-12 AND 0215-13 ASSEMBLY. 0215-13 REMOVE BACKING FROM WINDOW PANEL ADHESIVE FOAM TAPE. 0215-13 0215-12 ALIGN WINDOW PANEL CENTRALLY AND STICK ONTO FRONT INFILL. IMPORTANT: ENSURE THE WINDOW PANEL IS CENTRAL.
  • Page 41 Hixon: Assembly Guide ASSEMBLY STAGE 33 CONTINUED ROOF FRONT INFILL 0215-12 AND 0215-13 ASSEMBLY. 0205-44 LOCATE AND SECURE WINDOW SUPPORT 0205-44. 0215-15 (x4) LOCATE AND SECURE x4 WINDOW CLAMP 0215-15 USING FIXING METHOD ABOVE. 0215-12 REPEAT 33A - 33E TO ASSEMBLE REMAINING ROOF FRONT INFILL...
  • Page 42 Hixon: Assembly Guide ASSEMBLY STAGE 34 LOCATE AND SECURE ROOF FRONT INFILLS 0215-12. 0215-12 LOCATE ROOF FRONT INFILLS 0215-12 AS SHOWN ABOVE. SECURE ROOF FRONT INFILL AT x10 LOCATIONS INDICATED AS SHOWN ABOVE.
  • Page 43 Hixon: Assembly Guide ASSEMBLY STAGE 35 LOCATE AND SECURE TOP RAIL CORNER BRACKETS 0203-15. 0203-15 (x4) LOCATE AND SECURE TOP RAIL CORNER BRACKETS 0203-15 IN EACH CORNER OF SECURE EACH CORNER BRACKET AND ROOF INFILL AS SHOWN ABOVE. THE SHED USING THE TYPICAL FIXING METHOD SHOWN ABOVE.
  • Page 44 Hixon: Assembly Guide ASSEMBLY STAGE 36 LOCATE AND SECURE ROOF SUPPORTS 0212-13 AND 0212-14. 0212-13 (x2) 0212-14 (x2) LOCATE AND SECURE SHORT ROOF SUPPORT 0212-13 AS SHOWN ABOVE. LOCATE AND SECURE LONG ROOF SUPPORT 0212-14 AS SHOWN ABOVE.
  • Page 45 Hixon: Assembly Guide ASSEMBLY STAGE 37 LOCATE AND SECURE ROOF CHANNEL ASSEMBLY 0215-06. 0215-06 0215-06 SLOT EACH ROOF CHANNEL ASSEMBLY 0215-06 INTO ROOF SUPPORT. SECURE ROOF CHANNEL ASSEMBLY AT EACH FIXING POINT (x3 EACH SIDE) USING FASTENERS DETAILED ABOVE.
  • Page 46 Hixon: Assembly Guide ASSEMBLY STAGE 38 PUSH ROOF REAR AND FRONT INFILL AIR BEND TABS UPWARDS. BEND ROOF FRONT INFILL AIR BEND TABS UPWARDS. BEND ROOF REAR INFILL AIR BEND TABS UPWARDS...
  • Page 47 Hixon: Assembly Guide ASSEMBLY STAGE 39 LOCATE AND SECURE ROOF PANEL 0212-05. 0212-05 LOCATE A ROOF PANEL SIDE 0212-05 ALIGN WITH AIR BEND TABS AS INDICATED. SECURE ROOF PANELS AT x8 LOCATIONS INDICATED USING TYPICAL FIXING METHOD. IMPORTANT: ENSURE RUBBER WASHER FK4 IS LOCATED AS SHOWN.
  • Page 48 Hixon: Assembly Guide ASSEMBLY STAGE 40 LOCATE x1 ROOF PANEL SIDE 0212-07 ONTO LEFT-HAND SIDE OF SHED. 0212-07 OUTSIDE INSIDE OUTSIDE INSIDE ALIGN AND OVERLAP ROOF PANEL 0205-07 WITH ROOF PANEL SIDE AS SHOWN. SECURE ROOF PANELS AT x 4 LOCATIONS INDICATED USING TYPICAL FIXING METHOD.
  • Page 49 Hixon: Assembly Guide ASSEMBLY STAGE 41 LOCATE AND SECURE ROOF PANELS 0212-05. 0212-05 OUTSIDE INSIDE OUTSIDE INSIDE ALIGN AND OVERLAP ROOF PANEL 0212-05 WITH PREVIOUS ROOF PANEL. SECURE ROOF PANEL AT x12 LOCATIONS INDICATED USING TYPICAL FIXING METHOD. IMPORTANT: ENSURE PANELS ALWAYS OVERLAP AS SHOWN.
  • Page 50 Hixon: Assembly Guide ASSEMBLY STAGE 42 LOCATE ROOF PANEL SIDE 0212-07 ONTO RIGHT-HAND SIDE OF SHED. 0212-07 LOCATE A ROOF PANEL SIDE 0212-07 ONTO RIGHT-HAND SIDE OF SHED AND ALIGN WITH AIR BEND TABS AS INDICATED.
  • Page 51 Hixon: Assembly Guide ASSEMBLY STAGE 43 LOCATE AND SECURE SMALL ROOF PANEL 0212-06. 0212-06 UPON COMPLETION OF THIS PROCEDURE ENSURE STRUCTURE IS ALIGNED CORRECTLY AND TIGHTEN ALL FASTENERS ALIGN AND OVERLAP SMALL ROOF PANEL 0212-06 WITH PREVIOUS ROOF PANEL SECURE ROOF PANEL AT x8 LOCATIONS INDICATED USING TYPICAL FIXING METHOD.
  • Page 52 Hixon: Assembly Guide ASSEMBLY STAGE 44 LOCATE AND SECURE ROOF CAP 0215-03. 0215-03 LOCATE ROOF CAP 0215-03 ONTO FRONT OF ROOF. SECURE ROOF CAP AT x10 LOCATIONS INDICATED USING TYPICAL FIXING METHOD. PLEASE NOTE: THE FIXING USED IS A SELF DRILLING COMPONENT.
  • Page 53 Hixon: Assembly Guide ASSEMBLY STAGE 45 LOCATE AND SECURE ROOF GUTTER 0215-05. 0215-05 0215-05 SLIDE ROOF GUTTER 0215-05 INTO POSITION AT THE REAR OF THE SHED ROOF. SECURE ROOF GUTTER AT x8 LOCATIONS INDICATED USING TYPICAL FIXING METHOD.
  • Page 54 Hixon: Assembly Guide ASSEMBLY STAGE 46 LOCATE AND SECURE REAR ROOF CAP 0215-04. 0215-04 0215-04 LOCATE REAR ROOF CAP 0215-04 ONTO REAR OF ROOF. SECURE REAR ROOF CAP AT x8 LOCATIONS INDICATED USING TYPICAL FIXING METHOD. PLEASE NOTE: THE FIXING USED IS A SELF DRILLING COMPONENT.
  • Page 55 Hixon: Assembly Guide ASSEMBLY STAGE 47 DETERMINE WHICH SIDE DRAIN PIPE 0205-51 WILL BE LOCATED. 47B 47C 0205-51 IMPORTANT: THE DRAIN PIPE IS NOT SECURED ONTO THE SHED AT THIS STAGE, SIMPLY DETERMINE BEST LOCATION 0205-52 OPPOSITE SIDE TO 0205-53...
  • Page 56 Hixon: Assembly Guide ASSEMBLY STAGE 48 LOCATE AND SECURE DRAIN PIPE 0205-51. 0205-51 ALIGN DRAIN PIPE 0205-51 WITH OPEN GROMMET WITHIN ROOF GUTTER. SECURE DRAIN PIPE AT x6 LOCATIONS INDICATED USING TYPICAL FIXING METHOD. IMPORTANT: DRAIN PIPE BRACKET IS LOCATED WITHIN SIDE PANEL RECESS.
  • Page 57 Hixon: Assembly Guide ASSEMBLY STAGE 49 LOCATE AND SECURE RIGHT-HAND DOOR ASSEMBLY 0205-36 FURNITURE. 0205-36 0203-32 LOCATE EURO MORTICE LOCK 0203-32 RIGHT-HAND DOOR APERTURE AS SHOWN. SECURE EURO MORTICE LOCK 0203-32 AT x2 LOCATIONS INDICATED ABOVE. SEE FOLLOWING DATA SHEET FOR COMPLETION OF MORTICE LOCK INSTALLATION...
  • Page 58 Hixon: Assembly Guide ASSEMBLY STAGE 49 CONTINUED LOCATE AND SECURE RIGHT-HAND DOOR ASSEMBLY 0205-36 FURNITURE. 0203-34 LOCATE AND SECURE EURO ESCUTCHEON 0203-34 AS SHOWN. LOCATE EURO ESCUTCHEON COVER 0203-34 ONTO EURO ESCUTCHEON AS SHOWN. PLEASE NOTE: THESE ARE PUSHED ON AND WILL CLICK INTO PLACE.
  • Page 59 Hixon: Assembly Guide ASSEMBLY STAGE 50 LOCATE AND SECURE LEFT-HAND DOOR ASSEMBLY 0205-37 FURNITURE. 0203-35 0203-32 0203-41 0203-35 0203-40 0203-35 LOCATED AS SHOWN 0203-40 ENSURE THE PLUNGER INDICATED IS FACING THE BOTTOM OF THE DOOR, LOCATE SECURE EACH FLUSH DOOR BOLT ENSURING PLATE PACKER 0203-40 IS LOCATED AS SHOWN ABOVE AND SECURE USING ADJACENT FIXING METHOD.
  • Page 60 Hixon: Assembly Guide ASSEMBLY STAGE 50 CONTINUED LOCATE AND SECURE LEFT-HAND DOOR ASSEMBLY 0205-37 FURNITURE. 0203-35 FLUSH DOOR BOLT OPEN / CLOSE 0203-35 DOOR BOLT ATTACH DOOR BOLT ONTO FLUSH DOOR BOLT. ENSURE FLUSH DOOR BOLT OPENS AND CLOSES. REPEAT 50A / B / C FOR UPPER FLUSH DOOR BOLT...
  • Page 61 Hixon: Assembly Guide ASSEMBLY STAGE 51 LOCATE AND SECURE DOOR HINGES ONTO DOOR ASSEMBLIES. 0203-27 0203-28 0203-37 0203-37 0203-27 0203-28 0203-37 0203-37 LOCATE DOOR HINGE PLATE 0203-37 WITHIN DOOR AS SHOWN. SECURE DOOR HINGE PLATE AND HINGE 0203-27 AND 0203-28 AS SHOWN.
  • Page 62 Hixon: Assembly Guide ASSEMBLY STAGE 52 LOCATE AND SECURE DOOR HINGES ONTO LEFT-HAND DOOR POST. 0203-27 UPPER LOCATION LOCATE DOOR POST PLATE 0203-39 WITHIN DOOR FRAME AS SHOWN. SECURE DOOR POST PLATE AND LEFT-HAND HINGE 0203-27 AS SHOWN. IMPORTANT: SLOT WITH FACE UPWARDS AT UPPER LOCATION.
  • Page 63 Hixon: Assembly Guide ASSEMBLY STAGE 53 LOCATE AND SECURE DOOR HINGES ONTO RIGHT-HAND DOOR POST. 0203-28 UPPER LOCATION LOCATE DOOR POST PLATE 0203-39 WITHIN DOOR FRAME AS SHOWN. SECURE DOOR POST PLATE AND RIGHT-HAND HINGE 0203-28 AS SHOWN. IMPORTANT: SLOT WITH FACE UPWARDS AT UPPER LOCATION.
  • Page 64 Hixon: Assembly Guide ASSEMBLY STAGE 54 LOCATE AND SECURE GAS STRUT BRACKETS 0205-66. LEFT-HAND RIGHT-HAND 0205-66 (x2) 0205-68 (x2) SECURE A GAS STRUT BALL JOINT 0205-68 ONTO ALIGN EACH GAS STRUT BRACKET WITH RELEVANT FIXING EACH GAS STRUT BRACKET 0205-66.
  • Page 65 Hixon: Assembly Guide ASSEMBLY STAGE 55 LOCATE DOOR ASSEMBLIES ONTO HINGES. 0205-37 0205-36 SLIDE EACH DOOR ASSEMBLY ONTO EACH OF THEIR RESPECTIVE HINGES. ASSEMBLED DOOR HINGE.
  • Page 66 Hixon: Assembly Guide ASSEMBLY STAGE 56 LOCATE AND SECURE GAS STRUT 0205-63 . SECURE A GAS STRUT BALL JOINT 0205-68 ONTO EACH GAS STRUT BRACKET THAT FIX EACH GAS STRUT ONTO RELEVANT GAS STRUT BALL JOINTS. IS PRE-RIVETED ONTO EACH DOOR ASSEMBLY.
  • Page 67 Hixon: Assembly Guide ASSEMBLY STAGE 57 LOCATE AND SECURE SHELF ASSEMBLY 0205-38. SLIDE SHELF POST UP INTO ROOF FRAME, ONCE THERE IS ENOUGH CLEARANCE AT THE BOTTOM LOCATE SHELF POST OVER FLOOR FRAME AND LOWER. THE SHELF ASSEMBLY CAN BE LOCATED AS DESIRED, PLEASE DETERMINE THE LOCATE EACH SHELF 0205-38-02 ONTO SHELF POST AS DESIRED.
  • Page 68 Caring for your HEX Living product Your HEX Living product is designed to stand the test of time, which is why we’re happy to offer a lifetime warranty on our products. With zero maintenance required, simply assemble your HEX Living product,and enjoy putting it to great use in your garden.
