Ex-Or MP2000UF Installation And Commissioning Instructions

Ex-Or
Haydock Lane, Haydock,
Merseyside WA11 9UJ
Tel: +44 (0)1942 719229
Fax: +44 (0)1942 272767
Email: technicalsales.ex-or@honeywell.com
www.ex-or.com
Parameter
Ballast
Selects ballast type (referred to as 'Mode' in this document).
Power Up
Modes affected: NON DIM only
If set to Auto, a light measurement is taken to determine
whether lights need to be switched on.
PCT (Passing Cloud Timer)
Modes affected: NON DIM, others if BRIGHT-OUT = YES
If the light level has been continuously higher than SET
POINT H (or lower than SET POINT L) for longer than the
duration of the Passing Cloud Timer the relay output will
switch off (on). If the level was not continuously higher than
SET POINT H or lower than SET POINT L then the PCT will
be refreshed.
PCT
In Asymmetrical mode the lights will switch on as soon as the
light level drops below the lower threshold (SET POINT L)
In Symmetrical mode the light level must be continually lower
than the SET POINT L value for the duration of the PCT
before the output will switch on.
Start Lamps
Modes affected: DSI, DALI & 1-10V
Dimming
Modes affected: DSI, DALI & 1-10V
100% = Regulate over the full range of the ballast's capability.
Other % = Regulate within the stated percentage of the
ballast's capability. (With 90% selected, the photocell will not
dim the lights to less than 10% output. With 80%, lights will
not be dimmed below 20% and so on.)
Bright-out
Modes affected: DSI, DALI & 1-10V
If set to YES and the light level has been greater than the
value stored in Set Point H for the duration of the PCT, the
output will turn off. The output will turn back on immediately
when the light level falls to the normal regulating level stored
in Set Point L.
12Hr Reset
Modes affected: ALL
If set to YES and the unit is overridden using an HC6 Hand-
held Controller it will return to normal operation after 12 hours
or immediately if power supply interrupted.
At the end of their useful life
the packaging and product
should be disposed of via a
suitable recycling centre.
Do not dispose of with normal
household waste.
Do not burn.
W4142F
Options and Factory Defaults
DSI, DALI (1, 3, 10%),
1-10V, NON DIM
Default: DSI 1%
On, Auto
Default: On
10 seconds, 5-60 minutes
Default: 20 minutes
Symmetrical, Asymmetrical
Default: Asymmetrical
Max, Min
Default: Max
50-100%
Default: 100%
Yes, No
Default: No
Yes, No
Default: No
Universal Photocell
for Digital DSI, Digital DALI, Analogue1-10V
and non-dimmable ballasts
Installation and Commissioning
Instructions
Note: HP2000 required for commissioning
Parameter
Set Point L
Modes affected: ALL
This is the regulating set point. In NON DIM mode it is the
lower threshold. This is not a Lux value - it is a representation
of the Lux level at the time of programming.
Set Point H
Modes affected: ALL
This is the upper threshold. In regulating mode with BRIGHT
OUT set to YES, this is the value at which the output will turn
off. This is not a Lux value - it is a representation of the Lux
level at the time of programming.
Set Light Level
Modes affected: ALL
See Commissioning
Request Download
Following a successful download, the number of perceived
light level units prior to the lights being turned off is shown on
the display. If the lights were already off then the perceived
level is the ambient light level.
MP2000UF
Options and Factory Defaults
0 - 1023
Default: 1000
0 - 1023
Default: 1023
Up, Down, Send
