Ex-Or MP102 Installation And Commissioning Instructions

Technical Data
Nominal voltage: 220-240V, ~, +10%/-15%
Frequency: 50-60Hz
On/off switch delay: 0-20 min
Power consumption: ca. 3 VA
Contact material: AgSn0
2
Contact: phase-independent (zero-crossover switching)
Gap: <3mm (µ)
Switching capacity max: 16A, 250V~, cos = 1
Switching capacity min: 10mA/230V AC
100mA/12V AC/DC
Switching capacity fluorescent lamps: 16 AX
Incandescent lamp load: 3600 W
Halogen lamp load: 3600 W
Fluorescent lamp loads - capacitive ballast:
uncorrected: 3600 VA
series corrected: 3600 VA
parallel corrected: 1200 VA (130µF)
dual circuit: 3600 VA
Fluorescent lamps - electronic ballast: 1200 VA
Mercury and sodium vapour lamps: series corrected: 1200 VA (130µF)
Compact fluorescent lamps - electronic ballast: 34x7 W, 27x11 W, 24 x 15 W, 22 x 23 W
o
Permissible ambient temperature: -30 C ...+55 C (control unit)
o
-40 C ... +70 C (sensor)
Protection class: II (light sensors III) for designated installation
Protection rating: IP20 (control unit), IP65 (sensor)
Ex-Or
Haydock Lane, Haydock, Merseyside WA11 9UJ
Tel: +44 (0)1942 719229
Fax: +44 (0)1942 272767
Email: technicalsales.ex-or@honeywell.com
www.ex-or.com
o
o
At the end of their useful life
the packaging and product
should be disposed of via a
suitable recycling centre.
Do not dispose of with normal
household waste.
Do not burn.
W4331B
MP102 LightSpot Photocell
Installation and Commissioning
Instructions
