CARE AND MAINTENANCE
Store outdoor furniture indoors or cover well when not in use.
Remove wooden furniture from standing water. Dust regularly with small brush or vacuum
Spills should be taken care of immediately before they harden or
stain with a slightly dampened sponge.
NOTICE
* Please make sure that you have all parts indicated before you begin assembly of this item
* This item should be assembled on a soft surface to prevent scratching the finish during assembly
* This item may require periodic tightening
Part List and Hardware List
PIECE
DESCRIPTION
Seat Frame
A
Leg Frame
B
Back frame
C
Cross bar of leg
D
Screw -1
E
Screw -2
H1
Screw -3
H2
H3
Allen bolt L
H4
Reinforcement plate
H5
Allen key
QUANTITY
1X
2X
1X
2X
6X
M7x90
1X
M7x70
6X
M4x20
4X
M8x75
3X
1X
2X
Model# FOX6007A
Product Dimensions:21.25" W x 29.13" D x 33.25" H
