TD60D - - TD70D - - TD80D - - TD90D - -
TD95D MODEL TRACTORS
SECTIONS
GENERAL
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ENGINE
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CLUTCH
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GEARBOX
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TRANSMISSION OF MOTION
FRONT MECHANICAL TRANSMISSION
REAR MECHANICAL TRANSMISSION
POWER TAKE- OFF
BRAKES
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HYDRAULIC SYSTEMS
STEERING
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
AXLE AND WHEELS
AUXILIARY EQUIPMENT
ELECTRICAL SYSTEM
CAB
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
S
SERVICE MANUAL
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
E
R
. . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . .
V
I
C
00
10
18
21
23
25
27
31
33
35
41
44
50
55
90
E
Advertisement
Related Manuals for New Holland TD60D
Summary of Contents for New Holland TD60D
- Page 1 TD60D - - TD70D - - TD80D - - TD90D - - TD95D MODEL TRACTORS SERVICE MANUAL SECTIONS GENERAL ........... .
- Page 2 SECTION 10 - - ENGINE - - CHAPTER 1 ENGINE Removal - - Installation (Operation 10 001 10) DANGER Lift and handle all heavy parts using suitable lifting equipment. Make sure that assemblies or parts are supported by means of suitable slings and hooks. Check that no one is in the vicinity of the load to be lifted.
- Page 3 SECTION 10 - - ENGINE - - CHAPTER 1 5. Remove the weights (1) from the front support. TRE0602A 6. Remove the exhaust pipe, attach lifting chains to the bonnet (1) and attach the chain to the hoist. 24872 7. Disconnect the electrical leads (1) from headlamps (2).
- Page 4 SECTION 10 - - ENGINE - - CHAPTER 1 9. Remove the four bonnet hinge bolts (1) and lift the bonnet clear. TRE0604A 10. Remove the wire mesh guard (1) from right-- hand side of the fan. 25028 11. Disconnect the tachometer cable (1) and remove the retaining ring and sleeve.
- Page 5 SECTION 10 - - ENGINE - - CHAPTER 1 13. After recovering the air--conditioner gas (HRC 134a) with the recovery and recycling station 294048, disconnect the pipes of the cab air conditioner (1) and (2). 24892 14. Detach the cab heating pipes (1) and (2). 25411 15.
- Page 6 SECTION 10 - - ENGINE - - CHAPTER 1 16. Disconnect the electrical connectors. Detach the fusebox by unscrewing the nut (1). TRE0606A 17. Disconnect the delivery and return lines (1) to the power steering cylinders. TRE0607A 18. Remove the hose (1) from the lift pump suction pipe.
- Page 7 SECTION 10 - - ENGINE - - CHAPTER 1 19. Detach the lift pump delivery pipe (1). TRE0609A 20. Detach the fuel pipes from the injection pump and fuel pump and the pipe connecting the tank to the sedimentation filter. TRE0610A 21.
- Page 8 SECTION 10 - - ENGINE - - CHAPTER 1 22. Remove the front, centre and rear retaining bolts from the front axle drive shaft guard and remove the guard. 25038 23. Remove the circlip (2) from the front of the prop shaft and slide the sleeve (1), in the direction shown by the arrow, until it is free of the splines on the front axle.
