  • Page 2 Congratulations, you got the Byte! The Byte is an 8-bit digital synthesizer that detects the sound of the bass and generates it’s own sound on response to it. The detector is monophonic (it only handles one note at a time). It has two independent oscillators with several waveforms, one running at the original frequency, and another one octave lower (suboscillator), which can be used together or separate.
  • Page 3 Controls Output level of the synthesized signal. 01 - LEVEL Output level of the clean signal which is added in parallel to the effect. 02 - BLEND Double function 03 - WAVE / START • Wave: Selects the waveform of the synthesized signal between this five options, or silence: Pulse Bipolar Pulse...
  • Page 4 Controls Controls • Filter: When activated, sets the final frequency for the envelope filter sweep. Double function. Optical switch with this functions: 12 - CONTROL Double function • By keeping the switch pressed, it makes a sweep on the sample rate set by the 05 - SUB / DECAY •...

  • Page 5: Technical Specifications

    Technical specifications Problems and solutions Model 2016 – BYT-1 • The LED lights up but there is only sound when the effect is in bypass: True Bypass Make sure the instrument is properly connected to the INPUT jack, and the amplifier Input impedance: 750Kohm to the OUTPUT jack.

  • Page 6: Terms Of Warranty

    • DEDALO will choose to repair or replace any faulty piece on the pedal at its sole option. • Failures due to accident or misuse are not covered in the warranty. • DEDALO is not responsible for any loss or damage the user may suffer as a result of Sound Settings using the pedal.
  • Page 7 Sound Settings Sound Settings Pixel Bass Synth Bass (Use control) Clean Octave Slow Sweep (Use control)
  • Page 8 Sound Settings Strings www.dedalofx.com.ar...
