Amada AMPS02 Instruction Manual

Step 2 Secure the Connector to the Top of the Tray Support Leg
C
Tighten the knob
Step 3 Secure the Tray to the Connector
Note:
● The holes in the connector should be aligned with the holes on the
tray.
● Do not tighten the bolts [D] until all of them are in right positions.
D
B
04
Step 4 Tilt and Height Adjustment
N
N
O
Phillips
Screwdriver
(Not Included)
K
Tilt Adjustment of Tray
Slightly loosen the tilt adjustment knobs
M [K] for better to adjust the height. When
you adjust the tray to your desired tilt
angle, tighten the knobs [K] to secure
the height in place.

Height Adjustment of Tray Support Leg

1. Remove the safety pin [M] from the
tray support leg.
2. Slightly loosen the height adjustment
knob [N] for better to adjust the height.
3. When you adjust the tray support leg
to your desired height, tighten the knob
[N] and insert the safety pin [M] into the
M
hole of the tray support leg.

Height Adjustment of Tripod Stand

1. Slightly loosen the height adjust-
ment knob [O] for better to adjust the
height of the tripod stand.
2. When you adjust the tripod stand to
your desired height, tighten the knob
[O] to secure the height in place.
05
Tripod Stand Instruction Manual
Model: AMPS02
Thank you for choosing this AMADA product! At AMADA we strive to provide
you with the best quality products and services in the industry. Should you
have any issues, please don't hesitate to contact us at
support@amadahome.com
V1.0(B)
