SECO-LARM ENFORCER VG-1C12BQ Installation Manual

ENFORCER Video Ground Loop Isolator
Also Available:
Video Balun with Ground Loop Isolator
EB-P101-24GQ
Ideal for new CCTV installations where passive
video baluns have not yet been installed
BNC Input Connector
Balun with Ground
Loop Isolator
(EB-P101-24GQ)
ENFORCER
Bullet Camera
IMPORTANT:
Users and installers of this product are responsible for ensuring this product complies with all national, state,
and local laws and statutes related to monitoring and recording audio and video signals. SECO-LARM will not be held
responsible for the use of this product in violation of any current laws or statutes.
WARNING:
Incorrect mounting which leads to exposure to rain or moisture inside the enclosure could cause a dangerous
electric shock, damage the device, and void the warranty. Do not open the case of this device, as there are no field-serviceable
components inside.
WARRANTY:
This SECO-LARM product is warranted against defects in material and workmanship while used in normal
service for a period of one (1) year from the date of sale to the original consumer customer. SECO-LARM's obligation is limited
to the repair or replacement of any defective part if the unit is returned, transportation prepaid, to SECO-LARM.
This Warranty is void if damage is caused by or attributed to acts of God, physical or electrical misuse or abuse, neglect,
repair, or alteration, improper or abnormal usage, or faulty installation, or if for any other reason SECO-LARM determines that
such equipment is not operating properly as a result of causes other than defects in material and workmanship.
The sole obligation of SECO-LARM, and the purchaser's exclusive remedy, shall be limited to replacement or repair only, at
SECO-LARM option. In no event shall SECO-LARM be liable for any special, collateral, incidental, or consequential personal
or property damages of any kind to the purchaser or anyone else.
NOTICE:
The information and specifications printed in this manual are current at the time of publication. However, the
SECO-LARM policy is one of continual development and improvement. For this reason, SECO-LARM reserves the right to
change specifications without notice. SECO-LARM is also not responsible for misprints or typographical errors.
Copyright © 2014 SECO-LARM U.S.A., Inc. All rights reserved. This material may not be reproduced or copied, in whole or in
part, without the written permission of SECO-LARM.
16842 Millikan Avenue, Irvine, CA 92606
Tel: 800-662-0800 / 949-261-2999 Fax: 949-261-7326
4
Balun (EVT-PB1Q)
Cat5e/6 Cable
Color: Up to 1,300ft (400m)
B/W: Up to 2,000ft (610m)
DVR, Monitor, Switch, etc.
MiVG-1C12BQ_1401.docx
Website: www.seco-larm.com
E-mail: sales@seco-larm.com
SECO-LARM U.S.A., Inc.
Remote
• Reduces ground loop interference
• Built-in surge suppressor
• Passive operation – No external power required
• High immunity from interference – Built-in impedance coupled device and noise
filter helps reduce RF interference, cross talk, picture tearing, and other picture helps reduce RF interference, cross talk, picture tearing, and other picture
quality problems
• BNC terminals for easy installation
PITSW4
VG-1C12BQ
Video Ground Loop Isolator Video Ground Loop Isolator
Installation Manual
evice and noise
