SECO-LARM ENFORCER MVD-AH12-01Q Installation Manual

4k hdmi splitters

4K HDMI Splitters

MVD-AH14-01Q shown

Model

MVD-AH12-01Q

MVD-AH14-01Q

The ENFORCER 4K HDMI Splitters allow for one HDMI source to simultaneously transmit to up to

four different monitors. The splitters work with most HDMI devices, delivering the very best in

digital audio and video signals with HD resolutions of up to 4K@60Hz. An LED indicator clearly

displays power status as well as which outputs are active. The 4K HDMI Splitters can be daisy-

chained up to four levels for even more outputs.

• Transmits an HDMI source to up to two (MVD-AH12-01Q) or four (MVD-AH14-01Q) different

HDMI displays

• Additional splitters can be daisy-chained for more outputs

• HDR Support

• Supports up to 4K@60Hz resolution and 3D video

• Individual status LEDs for each HDMI output

• Two EDID management settings

• One 5VDC power supply included

HDMI, the HDMI Logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

Type

4K 1x2 HDMI Splitter

4K 1x4 HDMI Splitter

Table of Contents

Need help?

Do you have a question about the ENFORCER MVD-AH12-01Q and is the answer not in the manual?

Page 1 4K HDMI Splitters Installation Manual MVD-AH14-01Q shown Model Type MVD-AH12-01Q 4K 1x2 HDMI Splitter MVD-AH14-01Q 4K 1x4 HDMI Splitter The ENFORCER 4K HDMI Splitters allow for one HDMI source to simultaneously transmit to up to four different monitors. The splitters work with most HDMI devices, delivering the very best in digital audio and video signals with HD resolutions of up to 4K@60Hz.
Page 2 "x " "x6 "x " Dimensions (56x100x16 mm) (63x163x16 mm) Weight 6-oz (165g) 9-oz (260g) Overview HDMI OUTPUT HDMI INPUT " MVD-AH12-01Q (16 mm) 5VDC " (56 mm) 1x2 HDMI Splitter EDID POWER 1080P/TV " (100 mm) SECO-LARM U.S.A., Inc.
Page 3 5. Turn the HDMI source and displays on. 6. Adjust the EDID settings as necessary EDID Management Settings – Copy the display resolution from Output 1 to other Output displays. – 1080p Limit the resolution to 1080p. SECO-LARM U.S.A., Inc.
Page 4 SECO-LARM’s obligation is limited to the repair or replacement of any defective part if the unit is returned, transportation prepaid, to SECO-LARM. This Warranty is void if damage is caused by or attributed to acts of God, physical or electrical misuse or abuse, neglect, repair or alteration, improper or abnormal usage, or faulty installation, or if for any other reason SECO-LARM determines that such equipment is not operating properly as a result of causes other than defects in material and workmanship.
