MICROTUBES INFINITY: USER GUIDE
If you feed an unbalanced input from these outputs,
use an instrument cable with a mono 1/4" plug.

DIRECT OUTPUT

An XLR output with a ground lift switch provides a
reliable standard connection to a mixing desk or an
external audio interface for a guaranteed low-noise
signal.

MIDI IN

A standard 1/8" TRS (Type B) jack allows connecting
an external MIDI controller to the Microtubes Infinity
for even more flexibility. Read more about the
MIDI capabilities at
creations/microtubes-infinity/

USB

The USB-C port unlocks the Microtubes Infinity's USB
audio interface capabilities and enables interaction
with the Darkglass Suite desktop app, allowing for
software updates and access to the Darkglass IR
library, containing hundreds of cabinet simulations.
USB MIDI is also supported.
SIGNAL CHAIN OPTIONS
The position of the Cabsim block in the signal chain
can be changed from the Suite.
4
https://www. darkglass.com/
MODES 1, 4 AND 5
DEFAULT
INPUT
LOW PASS HIGH PASS
FILTER FILTER
DISTORTION/
COMPRESSOR
PREAMP
CABSIM
BLEND
EQ
OUTPUT
MODES 2 AND 3
DEFAULT
INPUT
COMPRESSOR
DISTORTION/
PREAMP
CABSIM
BLEND
EQ
OUTPUT
OPTIONAL
INPUT
LOW PASS HIGH PASS
FILTER FILTER
DISTORTION/
COMPRESSOR
PREAMP
BLEND
CABSIM
EQ
OUTPUT
OPTIONAL
INPUT
COMPRESSOR
DISTORTION/
PREAMP
BLEND
CABSIM
EQ
OUTPUT
