- Page 1 PAK TECH APPLICATOR OPERATING INSTRUCTION MANUAL Version 3.0 Date 12/03/19...
- Page 2 • Keep clear of all moving parts. • Clear machine jams only when in E-stop mode or fully powered down. • It is recommended that you wear safety glasses anytime during operation of the Pak Tech system. PAK TECH OIM (V3.0) Page 2 of 10...
- Page 3 PAK TECH TABLE OF CONTENTS 1 INTRODUCTION 2 MACHINE REQUIREMENTS 3 GENERAL MACHINE SERVICE 4 START UP PROCEDURE PAK TECH OIM (V3.0) Page 3 of 10...
- Page 4 PAK TECH 1 INTRODUCTION • Thank you for purchasing a microcanner PAK TECH system. This manual is written for your benefit to help you fully understand how to operate and service your machine. With proper operation and service your machine will offer you years of service.
- Page 5 Air Regulator at the machine is to be set at 70 P.S.I. If your pressure needle jumps around during operation, you will need to supply a surge tank near the machine. PAK TECH OIM (V3.0) Page 5 of 10...
- Page 6 • After cleaning a food grade zero weight grease (http://www.mcmaster.com/#1242k11/=125v2xd) needs to be applied using your finger to the H slide rods and push cylinder rod (push cylinder rod only for MC- 1000 and MC-202 users) PAK TECH OIM (V3.0) Page 6 of 10...
- Page 7 4 START UP PROCEDURE/SWITCHING FROM 8OZ TO 12OZ TO 16OZ 1. Line up the Pak Tech to the end of the canning line (See pictures). The drop from the canning conveyor/chute to the Pak Tech deck should be level or slightly below.
- Page 8 PAK TECH 3. Fill the hopper with Pak Tech’s, do not stack higher than 2 inches above tops of alignment posts. PAK TECH OIM (V3.0) Page 8 of 10...
- Page 9 4.1 ADJUSTING THE PRESS ZONE 1. Use 2 seamed cans and place them under the Pak Tech drop chute. 2. Place a Pak Tech on the drop chute let it slide down until it hits the stopper hook. 3. Manually push the cans toward the angled Pak Tech. It should catch the edge of the can and bend under the press bar.
- Page 10 You want the roller to be just above the cans. Make sure to tighten down the hex head screws so they are touching the roller and properly locked down. If a Pak Tech is not fully locking onto the can this bar might need further adjustment once running.
