NY900U Series
Installation Instructions
READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
When using electrical equipment, basic safety precautions should always be followed including the following:
• DISCONNECT AC POWER SUPPLY BEFORE SERVICING.
• Installation and servicing of this equipment should be performed by qualified service personnel only.
• Ensure that the electrical wiring conforms to the National Electrical Code NEC® and local regulations, if
applicable.
• Do not mount near gas or electrical heaters.
• Do not use outdoors.
• Do not let power cords touch hot surfaces.
• Equipment should be mounted in locations and at heights where it will not be readily subjected to tampering
by unauthorized personnel.
• The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
• Any modification or use of non-original components will void the warranty and product liability.
• Do not use this equipment for other than intended use.
• Allow battery to charge for 24 hours before first use.
• Use caution when servicing batteries. Battery acid can cause burns to skin and eyes. If acid is spilled on skin
or eyes, flush acid with fresh water and contact a physician immediately.
10070149 REV 4 - 04/22
IMPORTANT SAFEGUARDS
SAVE THESE INSTRUCTIONS!
Technical Support
■ (623) 580-8943 ■ technicalsupport@barronltg.com
1
800-533-3948 www.barronltg.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for BARRON Exitronix NY900U Series
Summary of Contents for BARRON Exitronix NY900U Series
- Page 1 NY900U Series Installation Instructions IMPORTANT SAFEGUARDS READ AND FOLLOW ALL SAFETY INSTRUCTIONS. When using electrical equipment, basic safety precautions should always be followed including the following: • DISCONNECT AC POWER SUPPLY BEFORE SERVICING. • Installation and servicing of this equipment should be performed by qualified service personnel only. •...
-
Page 2: End Mount
NY900U Series Installation Instructions Surface Ceiling or Surface Wall Mount Fig. 1 Front Cover 1. Secure the crossbar to the J-box using appropriate hardware (provided by others). 2. Using a screwdriver, carefully open the front cover. (Fig. 1) 3. Secure the canopy to the enclosure using the included Fig. - Page 3 NY900U Series Installation Instructions Recessed Ceiling or Recessed Wall Mount Fig. 6 1. Using a screwdriver, carefully open the front cover. (Fig. 6) AC Wires 2. Remove the J-box cover from the included J-box and punch out the knockout from the J-box cover. 3.
-
Page 4: Electrical Connections
NY900U Series Installation Instructions Recessed Ceiling or Recessed Wall Mount, Continued Fig. 11 13. Guide the fixture into the hanger bracket until it snaps into place. (Fig. 11) 14. Connect the test switch and install the LED indicator into the bushing in the trimplate. - Page 5 NY900U Series Installation Instructions Self-Test/Self-Diagnostics (G2) Operation The purpose of this option is to provide Self-testing and Self-diagnostic capabilities to the emergency unit. At predetermined intervals, the emergency unit will automatically switch into battery mode. Refer to the Self-Test Feature section below for timing details.
