ENGINE GUARD KIT
PART NUMBER: 121696
PACKING LIST:
Listed below are parts included in this kit. If any parts are missing or damaged, please contact the
®
Hustler
Parts Department. Retain these instructions for replacement parts.
Allow the engine and muffler to cool before beginning installation.
2
3
INDEX NO.
PART NO.
1
552968
2
029629
3
016899
1
DESCRIPTION
ENGINE GUARD (WITH DECAL)
CS .375-16 X .75 HX FLK
NT .375-16 HX FLK ZNYC
INSTRUCTION
121697
REV. A
QTY.
1
4
4
