- Page 1 Phantom Sim Frame Assembly Instructions Your pit crew is here to support you. Skype Us info@allin1gaming.com allin1gaming.com allin1gaming.com/support allin1gaming support page chat with a live agent email our team...
- Page 2 BASE ASSEMBLY Repeat the process for the positions below PH-EXT-004-020 ST-HP-003-0001 PH-EXT-004-050 HW-FN-002-0001 HW-FN-003-0016...
- Page 3 SIM FEET ASSEMBLY Please flip unit over to complete assembly. 12 x 4 4 4 4 x x x x 12 x 4 4 4 4 x x x x HW-FN-002-0001 HW-FN-008-0001 BP-PH-001 HW-FN-003-0020 HW-LF-008-0001...
- Page 4 UPRIGHT ASSEMBLY Repeat the process for the positions below 32 x ST-GP-008-0001 HW-FN-003-0018 HW-FN-002-0001 PH-EXT-003-0030...
- Page 5 SIDE MOUNT ASSEMBLY ST-HP-003-0001 PH-EXT-002-0023 HW-FN-002-0001 HW-FN-003-0018 PH-EXT-001-0014...
- Page 6 SIDE MOUNT ASSEMBLY DELUXE SIDE MOUNT Repeat step 1 for the remaining 4 brackets. Add 4 t- nuts into the slots of the 180mm profiles to match with the hole locations of your shifter (or other). HW-FN-002-0001 PH-EXT-001-0014 PH-EXT-001-0014 PH-EXT-001-0014 WITH SHIFTER PLATE HW-FN-003-0016 HW-FN-002-0001...
- Page 7 FRONT WHEEL MOUNT ASSEMBLY 30mm 25mm 25mm 30mm HW-FN-015-0030 HW-FN-008-0003 HW-FN-015-0025 ST-GP-003-0001 MT-FW-001 MT-WH-002 MT-WH-001 Page 7 front...
- Page 8 WHEEL DECK MOUNT ASSEMBLY HW-WD-001 HW-FN-001 HW-FN-008-0003 ST-GP-003-0001 HW-FN-002 HW-FN-015-0025 Page 7 deck...
- Page 9 FANATEC PODIUM MOUNT ASSEMBLY do step 3 after 1 /2 om the following page HW-FN-003-0020 MT-PD-002 HW-FN-015-0025 MT-PD-001 ST-EXT-002-0187 MT-WH-001 MT-WH-002 Page 7 Fanatec...
- Page 10 ATTACH WHEEL MOUNT TO UPRIGHTS HW-FN-002-0001 HW-FN-003-0020...
- Page 11 SEAT MOUNT ASSEMBLY Repeat step 1 for other side Optional -With Undermount Seating Kit 12 x 12 x HW-FN-003-0016 HW-FN-002-0001 SPHEXT-001-0195...
- Page 12 The pedal plates can be mounted either freestyle (step 7c) or using the center hole as a pivot if you want to easily rotate your pedal angle PEDAL MOUNT ASSEMBLY - USING THE PIVOT METHOD Place one T-nut in the center top slot with 1 on each side 12 inches from the center T-nut Align the center T-nut with the...
- Page 13 ADD PEDAL MOUNT HARDWARE For pedals with a through hole capable of mounting from above OPTIONAL WITH PURCHASE OF MOUNTING KIT For pedals that mount upwards, use the provided 4 x corner brackets Align the 2 spreader bars into the slots as in the photo.
- Page 14 PEDAL MOUNT ASSEMBLY Place your pedals set onto the pedal mount. Adjust the 45x45 profile by sliding it forward/backward so that all mounting postions are aligned. Once aligned, remove pedal set and tighten 45x45 profile. Center screw acts as a pivot. Keep in place when rotating and adjust positions of the other screws.
- Page 15 PEDAL MOUNT - FREESTYLE METHOD To mount your pedals using any hole combination, angle, and height that you choose, follow the same steps above changing only the t-nut layout from step #4 from page 12 and screw positions from steps 2 & 3 from page 14. Examples of custom freestyle mounting options.
