Electric Pressure Cooker
USER MANUAL
MY-CS6037WP2
IMPORTANT NOTE: Please read the manual carefully before operating your
product. Retain it for future reference.
(Picture are for reference only, atual product may differ from picture shown)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MY-CS6037WP2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Midea MY-CS6037WP2

Summary of Contents for Midea MY-CS6037WP2

  • Page 1 Electric Pressure Cooker USER MANUAL MY-CS6037WP2 IMPORTANT NOTE: Please read the manual carefully before operating your product. Retain it for future reference. (Picture are for reference only, atual product may differ from picture shown)

  • Page 2: Important Precautions

    IMPORTANT PRECAUTIONS Caution 1. Read all the instructions 2. This appliance is for household use only. Do not use out- doors. 3. This appliance is not intended for use by persons with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
  • Page 3 IMPORTANT PRECAUTIONS Caution 12.The heating element surface is subject to residual heat after use, do not touch. 13.Warning: Avoid spillage on the connector. 14.Warning: Misuse may cause potential injury; 15.The appliance is not intended to be operated by means of an external timer or a separate remote-control system.
  • Page 4 Licence holder: Guangdong Midea Consumer Electric Manufacturing Co., Ltd. 19 Sanle Road, Beijiao, Shunde, 528311 Foshan, Guangdong, People’s Republic Of China Importer: MIDEA CONSUMER APPLIANCES DMCC...
  • Page 5 Product Structure Tips: 1. Please move the product with the handle of the cooker body; 2. Please remove the water from the housing cover with cloth. Note: ① Exhaust valve: Pull out the exhaust valve from the lid. Clean the internal side of the exhaust valve and the exhaust valve and float valve of the lid with brush and cloth at least once a month.

  • Page 6: Prepare For Cooking

    Use and maintain the inner pot 3. Keep it clean to prolong the service life Do not immerse it in water for a long period. Clean the inner pot with soap, mild detergent or warm water to remove dust, oil and dirt. Do not use a metal shovel or other hard tool, otherwise it will damage the inner surface of pot.

  • Page 7: General Function

    Prepare For Cooking when exhausting, do not keep the hands or Sealing schematic Exhaust schematic face above the exhaust opening; diagram diagram • Check if the floater valve drops down before working (before heating, the floater valve is down). General Function 1.

  • Page 8: Product Structure

    Size of Model Capacity Supply Pressure Temperature Power Inner Pot 220-240V~ 1000W 8.66" 60kPa 140° F~176° F MY-CS6037WP2 50/60Hz Power Cord Spoon User Manual Components Accessories Product Structure Description Exhaust valve handle Upper cover handle Seal ring Control Box Exhaust opening...
  • Page 9 Function Selection Operation Guidelines Function Operation Guidelines Under any state, press “Cancel” button to cancel the current Cancel work state and return standby state. Under standby state, press “Keep Warm” button, the indicator light is on and the digital screen shows default working time. Press “Cooking Timer”...

  • Page 10: Function Selection

    Function Selection Function Operation Guidelines Meat Curry Under standby state, press “Menu” button, the indicator light is Soup on and the digital screen shows default working time. Press Broth “Cooking Timer” button, then press “+” or “-” button to adjust the Steam working time.

  • Page 11: Daily Check And Maintenance

    Daily Check And Maintenance For use the product safely with a longer service life, please carefully check and maintain it. If followings occur Solutions • Power cord and plug is expanded, deformation, damaged and it color is changed. • One part of the power cord and plug are hotter. Stop using, and repair •...
  • Page 12 Safety Precautions Warning A socket shall be used alone • A socket of more than 10A rated current with ground- ing wire shall be used alone; • If shared with other electrical appliances, the socket may cause abnormal heat and result in fire. It is strictly prohibited to use other lid •...
  • Page 13 Safety Precautions Warning Warning on Opening the lid • When the electric pressure cooker is not working, there isn't pressure in the pot, the float valve is down; • When the electric pressure cooker is working, pressure in the cooker rises, float valve ascends;...
  • Page 14 Safety Precautions Caution When the cooker is working, please do not touch the lid • When the cooker is working, lid has high temperature, do not touch it; • Otherwise, it may possibly cause scalding. The total amount of food and water can not exceed Max scale •...

  • Page 15: Clean After Use

    Clean After Use 1. Clean after each use. 2. Before cleaning and maintenance, please unplug the power cord until the product cools. 3. Remove the lid and inner pot, clean with detergent first, then rinse well with water, and wipe dry with a soft cloth. 4.
  • Page 16 Troubleshooting Problem Reason Solution Exhaust valve not in sealing Turn the exhaust valve to position the sealing position Steam comes out from Send to the service center exhaust valve non-stop Pressure control fails for repair Power indicator doesn’t Please check the power Power socket bad contact light on socket...
  • Page 17 ‫اﺳﺗﻛﺷﺎف اﻷﻋطﺎل وإﺻﻼﺣﮭﺎ‬ ‫اﻟﺮﻗﻢ‬ ‫اﻟﺤﻞ‬ ‫اﻟﺴﺒﺐ‬ ‫اﻟﻤﺸﻜﻠﺔ‬ ‫اﻟﻤﺴﻠﺴﻞ‬ ‫أدر ﺻﻣﺎم ﺗﺣرﯾر اﻟﺿﻐط إﻟﻰ وﺿﻊ‬ ‫ﺻﻣﺎم اﻟﺗﻧﻔﯾس ﻏﯾر ﻣﺣﻛم اﻟﻐﻠق‬ ‫ﻣﻧﻊ اﻟﺗﺳرﯾب‬ ‫اﻟﺑﺧﺎر ﯾﺧرج ﻣن ﺻﻣﺎم‬ ‫اﻟﺗﻧﻔﯾس ﺑدون ﺗوﻗف‬ ‫أرﺳل اﻟﺟﮭﺎز إﻟﻰ ﻣرﻛز اﻟﺻﯾﺎﻧﺔ‬ ‫ﻓﺷل اﻟﺗﺣﻛم ﻓﻲ اﻟﺿﻐط‬ ‫ﻟﻺﺻﻼح‬ ‫ﯾرﺟﻰ اﻟﺗﺣﻘق ﻣن ﻣﻘﺑس اﻟطﺎﻗﺔ‬ ‫ﻋدم...
  • Page 18 ‫اﻟﺗﻧظﯾف ﺑﻌد اﻻﺳﺗﺧدام‬ .‫1. ﻗم ﺑﺗﻧظﯾف اﻟﻣﻧﺗﺞ ﺑﻌد ﻛل اﺳﺗﺧدام‬ .‫2. ﻗﺑل اﻟﺗﻧظﯾف واﻟﺻﯾﺎﻧﺔ، ﯾرﺟﻰ ﻓﺻل ﺳﻠك اﻟطﺎﻗﺔ ﺣﺗﻰ ﯾﺑرد اﻟﺟﮭﺎز‬ ‫3. أزل اﻟﻐطﺎء واﻟوﻋﺎء اﻟداﺧﻠﻲ، وﻧظﻔﮭﻣﺎ ﺑﺳﺎﺋل ﺗﻧظﯾف، وﻣن ﺛم اﺷطﻔﮭﻣﺎ ﺟﯾ د ً ا ﺑﺎﻟﻣﺎء وﺟﻔﻔﮭﺎ ﺑﺎﺳﺗﺧدام ﻗطﻌﺔ‬ .‫ﻗﻣﺎش...
  • Page 19 ‫اﺣﺗﯾﺎطﺎت اﻟﺳﻼﻣﺔ‬ ‫ﺗﺣذﯾر‬ ‫أﺛﻧﺎء ﺗﺷﻐﯾل ﺟﮭﺎز اﻟطﮭﻲ، ﯾرﺟﻰ ﻋدم ﻟﻣس اﻟﻐطﺎء‬ ‫• أﺛﻧﺎء ﺗﺷﻐﯾل اﻟﺟﮭﺎز، ﺗﻛون درﺟﺔ ﺣرارة اﻟﻐطﺎء ﻣرﺗﻔﻌﺔ، ﻟذا ﻓﻼ ﺗﻠﻣﺳﮫ؛‬ .‫• وإﻻ، ﻓﻘد ﯾﺗﺳﺑب ذﻟك ﻓﻲ ﺣدوث ﺣرق ﻣﺣﺗﻣل‬ .‫ﻻ ﯾﺟب أﻻ ﯾﺗﺟﺎوز إﺟﻣﺎﻟﻲ ﻛﻣﯾﺔ اﻟطﻌﺎم واﻟﻣﺎء اﻟﺣد اﻷﻗﺻﻰ ﻟﻠﻣﻘﯾﺎس‬ ‫•...
  • Page 20 ‫اﺣﺗﯾﺎطﺎت اﻟﺳﻼﻣﺔ‬ ‫ﺗﺣذﯾر‬ ‫ﺗﺣذﯾر ﻓﺗﺢ اﻟﻐطﺎء‬ ‫• ﻓﻲ ﺣﺎﻟﺔ ﻋدم ﺗﺷﻐﯾل ﺟﮭﺎز اﻟطﮭﻲ ﺑﺎﻟﺿﻐط اﻟﻛﮭرﺑﺎﺋﻲ، وﻋدم وﺟود ﺿﻐط ﻓﻲ اﻟوﻋﺎء، ﻓﺈن اﻟﺻﻣﺎم اﻟﻌﺎﺋم‬ ‫ﯾﻛون ﻷﺳﻔل؛‬ ‫• ﻓﻲ ﺣﺎﻟﺔ ﻋدم ﺗﺷﻐﯾل ﺟﮭﺎز اﻟطﮭﻲ ﺑﺎﻟﺿﻐط اﻟﻛﮭرﺑﺎﺋﻲ، ﯾزﯾد اﻟﺿﻐط داﺧل ﺟﮭﺎز اﻟطﮭﻲ، ﯾرﺗﻔﻊ اﻟﺻﻣﺎم‬ ‫اﻟﻌﺎﺋل؛...
  • Page 21 ‫اﺣﺗﯾﺎطﺎت اﻟﺳﻼﻣﺔ‬ ‫ﺗﺣذﯾر‬ ‫ﯾﺟب اﺳﺗﺧدام ﻣﻘﺑس ﻣﺳﺗﻘل‬ ‫• ﯾﺟب اﺳﺗﺧدام ﻣﻘﺑس ﻻ ﯾزﯾد اﻟﺗﯾﺎر اﻟﻣﺗردد اﻟﻣﻘدر ﺑﮫ ﻋن 01 أﻣﺑﯾر وﻣزود‬ ‫ﺑﺳﻠك ﺗﺄرﯾض ﻓﻘط؛‬ ‫• وﻓﻲ ﺣﺎﻟﺔ اﺳﺗﺧدام اﻟﺟﮭﺎز ﻣﻊ أﺟﮭزة ﻛﮭرﺑﺎﺋﯾﺔ أﺧرى، ﻓﻘد ﯾﺗﺳﺑب اﻟﻣﻘﺑس‬ .‫ﻓﻲ ارﺗﻔﺎع درﺟﺔ اﻟﺣرارة ﺑﺻورة ﻏﯾر طﺑﯾﻌﯾﺔ وﯾﻧﺗﺞ ﻋﻧﮫ ﻧﺷوب ﺣرﯾق‬ ‫ﯾ...
  • Page 22 ‫اﻻﺧﺗﺑﺎر اﻟﯾوﻣﻲ واﻟﺻﯾﺎﻧﺔ‬ .‫ﻻﺳﺗﺧدام اﻟﺟﮭﺎز ﺑﺄﻣﺎن وﺿﻣﺎن طول ﻓﺗرة اﺳﺗﺧداﻣﮫ، ﯾرﺟﻰ ﻓﺣﺻﮫ وﺻﯾﺎﻧﺗﮫ ﺑﻌﻧﺎﯾﺔ‬ ‫اﻟﺣﻠول‬ ‫ﻓﻲ ﺣﺎﻟﺔ ﺣدوث ﻣﺎ ﯾﻠﻲ‬ .‫• ﺗم ﺗﻣدﯾد ﺳﻠك اﻟطﺎﻗﺔ واﻟﻘﺎﺑس، وﺣدث ﺗﺷوه أو ﺗﻠف أو ﺗﻐﯾر اﻟﻠون‬ .‫• ﻗطﻌﺔ ﻣن ﺳﻠك اﻟطﺎﻗﺔ أو اﻟﻘﺎﺑس أﻛﺛر ﺳﺧوﻧﺔ‬ .‫•...
  • Page 23 ‫اﺧﺗﯾﺎر اﻟوظﯾﻔﺔ‬ ‫إرﺷﺎدات اﻟﺗﺷﻐﯾل‬ ‫اﻟوظﯾﻔﺔ‬ ‫ﻟﺣم‬ ‫ﻓﻲ وﺿﻊ اﻻﺳﺗﻌداد، اﺿﻐط ﻋﻠﻰ اﻟزر "ﻗﺎﺋﻣﺔ"، وﻣن ﺛم ﯾﺻﺑﺢ ﺿوء اﻟﻣؤﺷر ﻗﯾد اﻟﺗﺷﻐﯾل‬ ‫ﻛﺎري‬ ‫ﺷورﺑﺔ‬ ،"‫وﺗﻌرض اﻟﺷﺎﺷﺔ اﻟرﻗﻣﯾﺔ وﻗت اﻟﺗﺷﻐﯾل اﻻﻓﺗراﺿﻲ. اﺿﻐط ﻋﻠﻰ اﻟزر "دﻗﯾﻘﺔ اﻟطﮭﻲ‬ ‫ﻣرق‬ "‫وﻣن ﺛم اﺿﻐط ﻋﻠﻰ اﻟزر "+" أو "-" ﻟﺿﺑط وﻗت اﻟﺗﺷﻐﯾل. اﺿﻐط ﻋﻠﻰ اﻟزر "ﺑدء‬ ‫ﺑﺧﺎر‬...
  • Page 24 ‫اﺧﺗﯾﺎر اﻟوظﯾﻔﺔ‬ ‫إرﺷﺎدات اﻟﺗﺷﻐﯾل‬ ‫إرﺷﺎدات اﻟﺗﺷﻐﯾل‬ ‫اﻟوظﯾﻔﺔ‬ ‫ﻓﻲ أي وﻗت، اﺿﻐط ﻋﻠﻰ زر "إﻟﻐﺎء" ﻹﻟﻐﺎء وﺿﻊ اﻟﻌﻣل اﻟﺣﺎﻟﻲ واﻟرﺟوع إﻟﻰ وﺿﻊ‬ ‫إﻟﻐﺎء‬ .‫اﻻﺳﺗﻌداد‬ ‫ﻓﻲ وﺿﻊ اﻻﺳﺗﻌداد، اﺿﻐط ﻋﻠﻰ زر "ﯾﺣﻔظ داﻓ ﺋ ً ﺎ"، وﻣن ﺛم ﯾﺻﺑﺢ ﺿوء اﻟﻣؤﺷر ﻗﯾد‬ ‫اﻟﺗﺷﻐﯾل...
  • Page 25 240- 220 MY-CS6037WP2 1000 8.66 60 /50 "-" "+"...
  • Page 26 ‫اﻻﺳﺗﻌداد ﻟﻠطﮭﻲ‬ ‫• ﺑﺎﻟﻧﺳﺑﺔ إﻟﻰ اﻟﺗﻧﻔﯾس اﻟﯾدوي، ﯾرﺟﻰ ﺗدوﯾر ﻣﻘﺑض ﺻﻣﺎم اﻟﺗﻧﻔﯾس‬ ‫اﻟﻣﺧطط اﻟﺑﯾﺎﻧﻲ ﻟﻣﻧﻊ‬ ‫اﻟﻣﺧطط اﻟﺑﯾﺎﻧﻲ ﻟﻠﻌﺎدم‬ ‫إﻟﻰ وﺿﻊ اﻟﺗﻧﻔﯾس، ﺣﯾث ﯾظل ﺟﮭﺎز اﻟطﮭﻲ ﺑﺎﻟﺿﻐط اﻟﻛﮭرﺑﺎﺋﻲ‬ ‫اﻟﺗﺳرﯾب‬ ‫ﻋﻠﻰ وﺿﻊ اﻟﺗﻧﻔﯾس؛ ﻋﻧد اﻟﺗﻧﻔﯾس، ﻻ ﺗﺗرك ﯾدﯾك أو وﺟﮫ ﻓوق‬ .‫ﻓﺗﺣﺔ اﻟﺗﻧﻔﯾس‬ ‫•...
  • Page 27 ‫اﺳﺗﺧدم اﻟوﻋﺎء اﻟداﺧﻠﻲ وﺣﺎﻓظ ﻋﻠﯾﮫ‬ ‫3. أﺑق اﻟﺟﮭﺎز ﻧظﯾ ﻔ ً ﺎ ﻟﻼﺳﺗﻣﺗﺎع ﺑﻔﺗرة ﺧدﻣﺔ طوﯾﻠﺔ‬ .‫ﻻ ﺗﻐﻣر اﻟﺟﮭﺎز ﻓﻲ اﻟﻣﺎء ﻟﻔﺗرة طوﯾﻠﺔ‬ .‫ﻧظف اﻟوﻋﺎء اﻟداﺧﻠﻲ ﺑﺎﻟﺻﺎﺑون أو ﻣﻧظف ﻣﻌﺗدل أو اﻟﻣﺎء اﻟداﻓﺊ ﻹزاﻟﺔ اﻟﻐﺑﺎر واﻟزﯾت واﻷوﺳﺎخ‬ .‫ﻻ ﺗﺳ ـ ـﺗﺧدم ﻣﺟرﻓﺔ ﻣﻌدﻧﯾﺔ أو أي أداة ﺻﻠﺑﺔ أﺧرى، وإﻻ ﻓﺳ ـ ـوف ﺗﺗﻠف اﻟﺳ ـ ـطﺢ اﻟداﺧﻠﻲ ﻟﻠوﻋﺎء‬ ‫اﻻﺳﺗﻌداد...
  • Page 28 ‫ھﯾﻛل اﻟﻣﻧﺗﺞ‬ :‫ﺗﻠﻣﯾﺣﺎت‬ ‫1. ﯾرﺟﻰ ﺗﺣرﯾك اﻟﻣﻧﺗﺞ ﺑﻣﻘﺑض ھﯾﻛل ﺟﮭﺎز اﻟطﮭﻲ؛‬ .‫2. ﯾرﺟﻰ إزاﻟﺔ اﻟﻣﺎء ﻣن ﻏطﺎء ﺟﮭﺎز اﻟطﮭﻲ ﺑﺎﺳﺗﺧدام ﻗطﻌﺔ ﻗﻣﺎش‬ :‫ﻣﻼﺣظﺔ‬ ‫ﺻﻣﺎم اﻟﺗﻧﻔﯾس: اﺳﺣب ﺻﻣﺎم اﻟﺗﻧﻔﯾس ﻣن اﻟﻐطﺎء. ﻧظف اﻟﺟﺎﻧب اﻟداﺧﻠﻲ ﻟﺻﻣﺎم اﻟﺗﻧﻔﯾس وﺻﻣﺎم اﻟﺗﻧﻔﯾس‬ .‫واﻟﺻﻣﺎم اﻟﻌﺎﺋم ﻓﻲ اﻟﻐطﺎء ﺑﺎﺳﺗﺧدام ﻓرﺷﺎة وﻗطﻌﺔ ﻗﻣﺎش ﻣرة واﺣدة ﺷﮭر ﯾ ًﺎ‬ ‫ﺣﻠﻘﺔ...
  • Page 29 . 28 . 29 . 30 .Guangdong Midea Consumer Electric Manufacturing Co., Ltd 528311...
  • Page 30 ‫اﺣﺗﯾﺎطﺎت ﻣﮭﻣﺔ‬ ‫ﺗﻧﺑﯾﮫ‬ ‫21. ﯾﻛون ﺳ ـ ـطﺢ ﻋﻧﺻر اﻟﺗﺳ ـ ـﺧﯾن ﻋرﺿﺔ ﻟﻠﺣرارة اﻟﻣﺗﺑﻘﯾﺔ ﺑﻌد اﻻﺳ ـ ـﺗﺧدام، ﻻ‬ .‫ﺗﻠﻣﺳﮫ‬ .‫31. ﺗﺣذﯾر: ﺗﺟﻧب ﺣدوث اﻧﺳ ـ ـﻛﺎب ﻋﻠﻰ اﻟﻣوﺻل‬ .‫41. ﺗﺣذﯾر: ﻗد ﯾﺗﺳ ـ ـﺑب ﺳ ـ ـوء اﻻﺳ ـ ـﺗﺧدام ﻓﻲ ﺣدوث إﺻﺎﺑﺔ ﻣﺣﺗﻣﻠﺔ‬ ‫51.
  • Page 31 ‫اﺣﺗﯾﺎطﺎت ﻣﮭﻣﺔ‬ ‫ﺗﻧﺑﯾﮫ‬ ‫1. اﻗرأ ﺟﻣﯾﻊ اﻹرﺷﺎدات‬ .‫2. ھذا اﻟﺟﮭﺎز ﻣ ُﻌد ﻟﻼﺳ ـ ـﺗﺧدام اﻟﻣﻧزﻟﻲ ﻓﻘط. ﻻ ﺗﺳ ـ ـﺗﺧدم اﻟﺟﮭﺎز ﻓﻲ اﻟﮭواء اﻟطﻠق‬ ‫3. ﻻ ﯾﺻ ﻣ ﱠم ھذا اﻟﺟﮭﺎز ﻟﻼﺳ ـ ـﺗﺧدام ﺑواﺳ ـ ـطﺔ اﻷﺷ ـ ـﺧﺎص اﻟذﯾن ﯾﻌﺎﻧون ﻧﻘ ﺻ ً ﺎ ﻓﻲ‬ ،‫ﻗدراﺗﮭ...
  • Page 32 MY-CS6037WP2...
