CESSNA AIRCRAFT COMPANY
MODEL 750
INTERIOR MAINTENANCE MANUAL AND ILLUSTRATED PARTS CATALOG
Subject
Forward
Maintenance
Parts
Lavatories
Aft Vanity ......................................................................................................... 25-40-01 ................. 25-40-02
Aft Closet ......................................................................................................... 25-40-03 ................. 25-40-04
Water Barrier .................................................................................................... 25-40-05 ................. 25-40-06
Toilet Installation .............................................................................................. 25-40-07 ................. 25-40-08
CONTENT
Original Issue
