- Page 1 CESSNA AIRCRAFT COMPANY AIRCRAFT DIVISION WICHITA, KANSAS 67277 Magnetometer Relocation ICA Supplement MODEL NO: 750 SUPPLEMENT NO: ICA-750-34-00002 SUPPLEMENT DATE: 11/20/2014 © Cessna Aircraft Company Form 2261 Rev 1...
- Page 3 When the chapter/system element number is followed with zeros in the section/subsystem and subject/unit element number (28-00-00), the information is applicable to the entire system. Page 1 of 6 Nov 20/2014 © Cessna Aircraft Company ICA-750-34-00002 Form 2261 Rev 1...
- Page 4 All revisions to this supplement will have changes identified in detail in the revision block(s) above. All pages in this ICA supplement will have the same date and are valid as of the date shown. Page 2 of 6 Nov 20/2014 © Cessna Aircraft Company ICA-750-34-00002 Form 2261 Rev 1...
- Page 5 This supplement will be completely superseded by the manuals listed in the REVISIONS table when it has been incorporated in all of the manuals. Page 3 of 6 Nov 20/2014 © Cessna Aircraft Company ICA-750-34-00002 Form 2261 Rev 1...
- Page 6 The purpose of this Supplement is to provide the maintenance technician with the information necessary to ensure the correct functionality and performance of the Magnetometer Relocation on the Cessna Model 750 until this information gets incorporated into the next revision to the manuals listed in the "REVISIONS" section of this supplement.
- Page 7 CESSNA AIRCRAFT COMPANY AIRCRAFT DIVISION WICHITA, KANSAS 67277 LIST OF INSTRUCTIONS FOR CONTINUED AIRWORTHINESS Model 750 Maintenance Manual Chapter 34 Navigation Refer to 34-15-00, Standby Instruments - Description and Operation Refer to 34-15-20, L-3 Communications MAG-3000 Magnetometer - Removal/Installation Page 5 of 6 Nov 20/2014 ©...
- Page 8 Continuous Inspection Program This ICA Supplement does not affect the current inspection program. Airworthiness Limitations Cessna Aircraft Company Model 750 (0501 & On) Maintenance Manual, Chapter 4, Airworthiness Limitations, contains the system and airframe limitations for the Model 750. NOTE: The Airworthiness Limitations section is FAA-approved and specifies maintenance...
- Page 9 CESSNA AIRCRAFT COMPANY MODEL 750 (SERIAL -0501 AND ON) MAINTENANCE MANUAL STANDBY INSTRUMENTS - DESCRIPTION AND OPERATION General This section gives a description and the operation of the standby instrument system. The line replaceable units (LRU's) in the standby instrument system are the L-3 Communications GH-3900 Secondary Flight Display (SFD), L-3 Communications GH-3900 Detachable Configuration Module...
- Page 10 CESSNA AIRCRAFT COMPANY MODEL 750 (SERIAL -0501 AND ON) MAINTENANCE MANUAL Standby Instrument System Figure 1 (Sheet 1) 34-15-00 Page 2 Nov 20/2014 © Cessna Aircraft Company ICA-750-34-00002 Form 2261 Rev 1...
- Page 11 CESSNA AIRCRAFT COMPANY MODEL 750 (SERIAL -0501 AND ON) MAINTENANCE MANUAL Standby Static Port There is a left and a right standby static port installed on the airplane. They are installed at FS 117.60 and WL 100.23, below the cockpit floorboard panels. They are attached to the fuselage skin with rivets and have a tube that connects to the rear side of it.
- Page 13 CESSNA AIRCRAFT COMPANY MODEL 750 (SERIAL -0501 AND ON) MAINTENANCE MANUAL L-3 COMMUNICATIONS MAG-3000 MAGNETOMETER - REMOVAL/INSTALLATION General This section gives the removal and installation procedures for the L-3 Communications MAG-3000 Magnetometer (UV007). For a general description of the magnetometer, refer to Standby Instruments - Description and Operation .
- Page 14 CESSNA AIRCRAFT COMPANY MODEL 750 (SERIAL -0501 AND ON) MAINTENANCE MANUAL L-3 Communications MAG-3000 Magnetometer Installation Figure 401 (Sheet 1) 34-15-20 Page 402 Nov 20/2014 © Cessna Aircraft Company ICA-750-34-00002 Form 2261 Rev 1...
- Page 15 CESSNA AIRCRAFT COMPANY MODEL 750 (SERIAL -0501 AND ON) MAINTENANCE MANUAL L-3 Communications MAG-3000 Magnetometer Post-Maintenance Checks Do the Magnetometer Post-Maintenance Checks Do an electrical bond check (Type I) between the magnetometer (UV007) and the bracket. Refer to Chapter 20, Electrical Bonding - Maintenance Practices.
- Page 17 CESSNA AIRCRAFT COMPANY AIRCRAFT DIVISION WICHITA, KANSAS 67277 SUPPLEMENT NO: ICA-750-34-00002 APPENDIX A: ILLUSTRATED PARTS CATALOG NOT APPLICABLE © Cessna Aircraft Company Form 2261 Rev 1...
- Page 19 CESSNA AIRCRAFT COMPANY AIRCRAFT DIVISION WICHITA, KANSAS 67277 SUPPLEMENT NO: ICA-750-34-00002 APPENDIX B: WIRING DIAGRAM MANUAL NOT APPLICABLE © Cessna Aircraft Company Form 2261 Rev 1...
