  • Page 1 USER’S MANUAL VCO-6000-CFL-4M2 Superior Fanless Embedded System...
  • Page 2 VCO-6000-CFL-4M2 l User’s Manual Please note, the VCO-6131E-4M2 is now referred to as "VCO-6000-CFL- 4M2" due to a model name change. All product features and functionality remain the same. If any questions, please contact us for more information. Name Change Guide:...

  • Page 3: Table Of Contents

    VCO-6000-CFL-4M2 l User’s Manual Table of Contents Prefaces ……………………………………………………………………………………………….. 04 Revision ………………………………………………………..……………………………..……………….……….. 04 Disclaimer ……………………………………………………….…….……………….………………….………….. Copyright Notice …………………………………….…….….………………………………….………………… 04 Trademarks Acknowledgment …………..………….………………………………………....Environmental Protection Announcement ……………………………………..……..……………….. Safety Precautions ……………………………………………………………………………………….….…….. Technical Support and Assistance ………………………………...……………………..…….…….……. Conventions Used in this Manual …………………………………..……………………..….………..
  • Page 4 VCO-6000-CFL-4M2 l User’s Manual Chapter 4 BIOS Setup …………………………………………..……………..……………… 90 BIOS Introduction …….……….……………………………………….…….…..….…………... 91 Main Setup ……..……….………………….…………………………..….….………………..92 Advanced Setup …………………………………………..………………………………………… 93 4.3.1 Connectivity Configuration ...………………………………………..………………. 94 4.3.2 CPU Configuration ……..……..……………….………..………..……………..……... 95 4.3.3 PCH-FW Configuration ……….………………..……………….………………..…..96 4.3.4 SATA and RST Configuration …………………………………………….…………..97 4.3.5 RST (UEFI RAID) Configuration ……………..……………….………………..…..

  • Page 5: Prefaces

    2021/01/10 Disclaimer All specifications and information in this User’s Manual are believed to be accurate and up to date. Premio Inc. does not guarantee that the contents herein are complete, true, accurate or non-misleading. The information in this document is subject to change without notice and does not represent a commitment on the part of Premio Inc.

  • Page 6: Safety Precautions

    Preface VCO-6000-CFL-4M2 l User’s Manual Safety Precautions Before installing and using the equipment, please read the following precautions: ⚫ Put this equipment on a reliable surface during installation. Dropping it or letting it fall could cause damage. ⚫ The power outlet shall be installed near the equipment and shall be easily accessible.

  • Page 7: Technical Support And Assistance

    Preface VCO-6000-CFL-4M2 l User’s Manual Technical Support and Assistance 1. Visit the Premio Inc website at www.premioinc.com where you can find the latest information about the product. 2. Contact your distributor, our technical support team or sales representative for technical support if you need additional assistance.

  • Page 8: Package Contents

    Preface VCO-6000-CFL-4M2 l User’s Manual Package Contents Before installation, please ensure all the items listed in the following table are included in the package. Item Description Q’ty VCO-6131-4M2 Series Fanless Embedded System Utility DVD Driver Wall Mount Kit Accessory Kit Ordering Information Model No.

  • Page 9: Chapter 1 Product Introductions

    Chapter 1 Product Introductions...

  • Page 10: Overview

    Premio GPU Computing System is your great solution for Machine Vision, Embedded System, Traffic Vision, Telemedicine, Intelligent Control, Deep Learning, Artificial Intelligence, Voice Reorganization and any graphics performance driven Industry 4.0/IIoT applications.

  • Page 11: Hardware Specification

    Chapter 1: Product Introductions VCO-6000-CFL-4M2 l User’s Manual 1.2 Hardware Specification System 2x RS-232/422/485, Support 8 Gen Intel® CFL-R S Processor 2x RS-232/422/485 (internal) (LGA 1151, 65W/35W TDP) 4x USB 3.2 Gen 2 (10 Gbps), Intel® Core™ i7-9700E, 8 Cores, 12MB cache, up to 4.4 GHz 5x USB 3.2 Gen 1 (5 Gbps, internal),...

  • Page 12: System I/O

    Chapter 1: Product Introductions VCO-6000-CFL-4M2 l User’s Manual 1.3 System I/O Front Panel DisplayPort ATX power on/off switch Used to connect a DisplayPort monitor Press to power-on or power-off the system DVI-I port USB 3.2 Gen 2 port (10 Gbps)
  • Page 13 Chapter 1: Product Introductions VCO-6000-CFL-4M2 l User’s Manual 1.3 System I/O Top Panel Universal I/O Bracket Used to customized I/O output Top Panel Rear Panel...

  • Page 14: Mechanical Dimension

    Chapter 1: Product Introductions VCO-6000-CFL-4M2 l User’s Manual 1.4 Mechanical Dimensions Unit: mm...

  • Page 15: Chapter 2 Switches And Connectors

    Chapter 2 Switches and Connectors...

  • Page 16: Switch And Connector Locations

    Chapter 2: Switches and Connectors VCO-6000-CFL-4M2 l User’s Manual 2.1 Switch and Connector Locations 2.1.1 Top View...

  • Page 17: Bottom View

    Chapter 2: Switches and Connectors VCO-6000-CFL-4M2 l User’s Manual 2.1.2 Bottom View...

  • Page 18: Connector / Switch Definition

    Chapter 2: Switches and Connectors VCO-6000-CFL-4M2 l User’s Manual 2.2 Connector / Switch Definition List of Connector / Switch Connector Location Definition AT_ATX1 AT / ATX Power Mode Switch PWR_SW1 Power Switch RESET1 Reset Switch USB 3.2 Gen 2 、 USB 3.2 Gen 1 、 USB2.0...

  • Page 19: I/O Interface Descriptions

    Chapter 2: Switches and Connectors VCO-6000-CFL-4M2 l User’s Manual 2.3 I/O Interface Descriptions 2.3.1 LPC Debug Con Signal Signal +3.3V LPC_AD3 LPC_AD2 Reset LPC_AD1 LPC_FRAME-L LPC_AD0 Clock...
  • Page 20 Chapter 2: Switches and Connectors VCO-6000-CFL-4M2 l User’s Manual 2.3 I/O Interface Descriptions 2.3.2 Power Con POWER1 Signal +12V...
  • Page 21 Chapter 2: Switches and Connectors VCO-6000-CFL-4M2 l User’s Manual 2.3 I/O Interface Descriptions 2.3.3 DC IN/IGN IN (+9V ~ +48V) DC_IN1 Signal +DC_IN IGN_SENSE...
  • Page 22 Chapter 2: Switches and Connectors VCO-6000-CFL-4M2 l User’s Manual 2.3 I/O Interface Descriptions 2.3.4 COM Con 10 9 COM5_1 , COM6_1 Signal Signal DCD# DSR# RTS# CTS# DTR# RS232 / RS422 / RS485 Connector 2x5 10-pin box header, 2.0mm pitch...
  • Page 23 Chapter 2: Switches and Connectors VCO-6000-CFL-4M2 l User’s Manual 2.3 I/O Interface Descriptions COM1_2 , COM3_4 RS232 / RS422 / RS485 Connector Type: 9-pin D-Sub RS422 / 485 Full Duplex RS232 Definition RS485 Half Duplex Definition Definition 1(10) DCD# DATA-...
  • Page 24 Chapter 2: Switches and Connectors VCO-6000-CFL-4M2 l User’s Manual 2.3 I/O Interface Descriptions 2.3.5 SF100 SPI Con Signal Signal Power ( 3V ) MISO MOSI SPI_GATE#...
  • Page 25 Chapter 2: Switches and Connectors VCO-6000-CFL-4M2 l User’s Manual 2.3 I/O Interface Descriptions AT_ATX1 CAR_PWR1 CAR_PWR1 AT_ATX1 AT_ATX1: AT / ATX Power Mode Switch Switch Definition 1-2 (Left) ATX Power Mode (Default) 2-3 (Right) AT Power Mode CAR_PWR1: PC / Car Mode Switch...
  • Page 26 Chapter 2: Switches and Connectors VCO-6000-CFL-4M2 l User’s Manual 2.3 I/O Interface Descriptions 1 2 3 DELAY_TIME1 Power off delay time setup Switch Switch 1 / 2 / 3 Definition ON / ON / ON 3 sec.（Default Shutdown Timer by O.S）...
  • Page 27 Chapter 2: Switches and Connectors VCO-6000-CFL-4M2 l User’s Manual 2.3 I/O Interface Descriptions LINE_OUT1 MIC_IN1 LINE_OUT1 : MIC_IN1 : Line-out Jack (Green) Connector Type: 5- Microphone Jack (Pink) Connector Type: pin Phone Jack 5-pin Phone Jack Definition Definition OUT_R MIC_R...
  • Page 28 Chapter 2: Switches and Connectors VCO-6000-CFL-4M2 l User’s Manual 2.3 I/O Interface Descriptions CLR_CMOS1: Clear BIOS Switch Switch Definition 1-2 (Left) Normal Status (Default) 2-3 (Right) Clear BIOS PWR_SW1: Power Button Definition Definition Power Button...
  • Page 29 Chapter 2: Switches and Connectors VCO-6000-CFL-4M2 l User’s Manual 2.3 I/O Interface Descriptions RESET1 : Reset Button Definition RESET USB3_1 : USB3.1 Connector, Type A Definition Definition USB3_RX+ USB2_D- USB2_D+ USB3_TX- USB3_TX+ USB3_RX-...
  • Page 30 Chapter 2: Switches and Connectors VCO-6000-CFL-4M2 l User’s Manual 2.3 I/O Interface Descriptions CN7 : USB3.0 Connector 2x5 9-pin header, 2.0mm pitch Definition Definition USB3_TX- USB2_D- USB3_TX+ USB2_D+ USB3_RX- USB3_RX+...
  • Page 31 Chapter 2: Switches and Connectors VCO-6000-CFL-4M2 l User’s Manual 2.3 I/O Interface Descriptions CN6 : USB3.1 Connector, Type A x 4 Definition Definition USB3_RX+ USB2_D- USB2_D+ USB3_TX- USB3_TX+ USB3_RX-...
  • Page 32 Chapter 2: Switches and Connectors VCO-6000-CFL-4M2 l User’s Manual 2.3 I/O Interface Descriptions SIM1 : Top side SIM Card Socket SIM2 : Bottom side SIM Card Socket SIM1 SIM2 Definition Definition UIM_PWR UIM_VPP UIM_RESET UIM_DATA UIM_CLK...
  • Page 33 Chapter 2: Switches and Connectors VCO-6000-CFL-4M2 l User’s Manual 2.3 I/O Interface Descriptions DVI_I1: DVI-I Connector Definition Definition DVI_TX2- DVI Hot Plug Detect DVI_TX2+ DVI_TX0- DVI_TX0+ VGA_DDC_CLOCK DVI_DDC_CLOCK VGA_DDC_DATA DVI_DDC_DATA VGA VSYNC DVI_TXCLK+ DVI_TX1- DVI_TXCLK- DVI_TX1+ VGA_RED VGA_GREEN VGA_BLUE VGA_HSYNC...
  • Page 34 Chapter 2: Switches and Connectors VCO-6000-CFL-4M2 l User’s Manual 2.3 I/O Interface Descriptions DP1 DP2 : Display Port Connector Definition Definition DP_LANE0_P DP_LANE3_N DP_LANE0_N DP_LANE1_P DP_AUX_P DP_LANE1_N DP_LANE2_P DP_AUX_N DP_HPD DP_LANE2_N DP_LANE3_P +3.3V...
  • Page 35 Chapter 2: Switches and Connectors VCO-6000-CFL-4M2 l User’s Manual 2.3 I/O Interface Descriptions DIO : Digital Input / Output Connector Type: Terminal Block 2x9 18-pin, 3.5mm pitch Definition Definition DIN1 DOUT1 DIN2 DOUT2 DIN3 DOUT3 DIN4 DOUT4 DIN5 DOUT5 DIN6...
  • Page 36 Chapter 2: Switches and Connectors VCO-6000-CFL-4M2 l User’s Manual 2.3 I/O Interface Descriptions Digital Input Wurung Digital Output Wurung...
  • Page 37 Chapter 2: Switches and Connectors VCO-6000-CFL-4M2 l User’s Manual 2.3 I/O Interface Descriptions PWR_SW2 : Remote Power Switch Type: Terminal Block 1x2 2-pin, 3.5mm pitch Definition Power Button...
  • Page 38 Chapter 2: Switches and Connectors VCO-6000-CFL-4M2 l User’s Manual 2.3 I/O Interface Descriptions PWR_SW3 : Remote Power Switch 1x4 pin box header, 2.0mm pitch Definition Power Button PWR_LED HDD_LED...
  • Page 39 Chapter 2: Switches and Connectors VCO-6000-CFL-4M2 l User’s Manual 2.3 I/O Interface Descriptions CN3 CN4 : LAN and USB3.1 GEN 2 Ports Connector Type:RJ45 port with LEDs and dual USB3.1 ports Definition Definition Definition LAN1_MDI0P USB2_D1- USB2_D2- LAN1_MDI0N USB2_D1+ USB2_D2+...
  • Page 40 Chapter 2: Switches and Connectors VCO-6000-CFL-4M2 l User’s Manual 2.3 I/O Interface Descriptions Act LED Status Definition Blinking Yellow Data Activity No Activity Link LED Status Definition Steady Orange 1Gbps Network Link Steady Green 100Mbps Network Link 10Mbps Network Link...
  • Page 41 Chapter 2: Switches and Connectors VCO-6000-CFL-4M2 l User’s Manual 2.3 I/O Interface Descriptions MINIPCIE2 : Mini PCI-Express Socket Definition Definition WAKE# +3.3V +1.5V CLKREQ# UIM_PWR UIM_DATA REFCLK- UIM_CLK REFCLK+ UIM_RST UIM_VPP RESET# +3.3VAUX +1.5V SMB_CLK SMB_DATA USB2_D- USB2_D+ +3.3V +3.3V +1.5V...
  • Page 42 Chapter 2: Switches and Connectors VCO-6000-CFL-4M2 l User’s Manual 2.3 I/O Interface Descriptions MINIPCIE1 : Mini PCI-Express / mSATA Socket Definition Definition WAKE# +3.3V +1.5V CLKREQ# UIM_PWR UIM_DATA REFCLK- UIM_CLK REFCLK+ UIM_RST UIM_VPP RESET# +3.3VAUX +1.5V SMB_CLK SMB_DATA USB2_D- USB2_D+ +3.3V...
  • Page 43 Chapter 2: Switches and Connectors VCO-6000-CFL-4M2 l User’s Manual 2.3 I/O Interface Descriptions SATA with Power Connector Definition Definition +12V DEVSLP +12V +12V...
  • Page 44 Chapter 2: Switches and Connectors VCO-6000-CFL-4M2 l User’s Manual 2.3 I/O Interface Descriptions PCIE : PCI-Express x1 Slot Definition Definition +12V FAN_P4 +12V +12V +12V +12V SMB_CLK SMB_DATA +3.3V +3.3V +3.3VAUX +3.3V WAKE# RESET# FAN_P3 REFCLK+ TxP0 REFCLK- TxN0 RxP0...
  • Page 45 Chapter 2: Switches and Connectors VCO-6000-CFL-4M2 l User’s Manual 2.3 I/O Interface Descriptions PCIE : PCI-Express x8 Slot Definition Definition +12V +12V +12V +12V +12V SMB_CLK SMB_DATA +3.3V +3.3V +3.3VAUX +3.3V WAKE# RESET# REFCLK+ TxP0 REFCLK- TxN0 RxP0 RxN0...
  • Page 46 Chapter 2: Switches and Connectors VCO-6000-CFL-4M2 l User’s Manual 2.3 I/O Interface Descriptions PCIE : PCI-Express x8 Slot Definition Definition TxP1 TxN1 RxP1 RxN1 TxP2 TxN2 RxP2 RxN2 TxP3 TxN3 RxP3 RxN3 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN...
  • Page 47 Chapter 2: Switches and Connectors VCO-6000-CFL-4M2 l User’s Manual 2.3 I/O Interface Descriptions PCIE : PCI-Express x16 Slot Definition Definition +12V FAN_P4 +12V +12V +12V +12V SMB_CLK SMB_DATA +3.3V +3.3V +3.3VAUX +3.3V WAKE# RESET# FAN_P3 REFCLK+ TxP0 REFCLK- TxN0 RxP0...
  • Page 48 Chapter 2: Switches and Connectors VCO-6000-CFL-4M2 l User’s Manual 2.3 I/O Interface Descriptions PCIE : PCI-Express x16 Slot Definition Definition TxP1 TxN1 RxP1 RxN1 TxP2 TxN2 RxP2 RxN2 TxP3 TxN3 RxP3 RxN3 CFG_5 TxP4 CFG_6 TxN4 RxP4 RxN4 TxP5 TxN5...
  • Page 49 Chapter 2: Switches and Connectors VCO-6000-CFL-4M2 l User’s Manual 2.3 I/O Interface Descriptions PCIE : PCI-Express x16 Slot Definition Definition TxN8 RxP8 RxN8 TxP9 TxN9 RxP9 RxN9 TxP10 TxN10 RxP10 RxN10 TxP11 TxN11 RxP11 RxN11 TxP12 TxN12 RxP12 RxN12 TxP13...
  • Page 50 Chapter 2: Switches and Connectors VCO-6000-CFL-4M2 l User’s Manual 2.3 I/O Interface Descriptions CN1 : M.2 E Key Socket Definition Definition +3.3VAUX USB2_D+ +3.3VAUX USB2_D- LED1# LED2# TxP0 TxN0 RxP0 RxN0...
  • Page 51 Chapter 2: Switches and Connectors VCO-6000-CFL-4M2 l User’s Manual 2.3 I/O Interface Descriptions CN1 : M.2 E Key Socket Definition Definition REFCLK0+ REFCLK0- SUSCLK PERST0# WAKE0# TxP1 TxN1 Pull Low RxP1 PERST1# RxN1 WAKE1# REFCLK1+ +3.3VAUX REFCLK1- +3.3VAUX...
  • Page 52 Chapter 2: Switches and Connectors VCO-6000-CFL-4M2 l User’s Manual 2.3 I/O Interface Descriptions CN2 : M.2 M Key Socket Definition Definition +3.3V +3.3V RxN3 RxP3 LED# TxN3 +3.3V TxP3 +3.3V +3.3V RxN2 +3.3V RxP2 TxN2 TxP2 RxN1 RxP1 TxN1...
  • Page 53 Chapter 2: Switches and Connectors VCO-6000-CFL-4M2 l User’s Manual 2.3 I/O Interface Descriptions CN2 : M.2 M Key Socket Definition Definition TxP1 Pull Low RxN0/SATA_B+ RxP0/SATA_B- TxN0 TxP0 PERST# Pull Hi REFCLK- WAKE# REFCLK+ SUSCLK PEDET +3.3V +3.3V +3.3V...

  • Page 54: Chapter 3 System Setup

    Chapter 3 System Setup...

  • Page 55: Set Torque Force To 3.5 Kgf-Cm To Execute All The Screwing And Unscrewing

    Chapter 3: System Setup VCO-6000-CFL-4M2 l User’s Manual 3.1 Set torque force to 3.5 kgf-cm to execute all the screwing and unscrewing. 3.2 Removing heat sink cover In order to prevent electric shock or system damage, before removing the chassis cover, must turn off power and disconnect the unit from power source.
  • Page 56 Chapter 3: System Setup VCO-6000-CFL-4M2 l User’s Manual 2. Unscrew the 4 screws on the bottom side. 3. Now you can remove the heat sink cover.

  • Page 57: Disconnecting Expansion Module From Computing Module

    Chapter 3: System Setup VCO-6000-CFL-4M2 l User’s Manual Disconnecting expansion module from computing module 1. Remove the 3 connecting brackets on the top side of the system and the 3 brackets on the bottom side. 2. Now you can separate the expansion module from the computing module.

  • Page 58: Removing Chassis Top Cover

    Chapter 3: System Setup VCO-6000-CFL-4M2 l User’s Manual 3.4 Removing chassis bottom cover 1. Unscrew the 6 screws highlighted below. 2. Unscrew 4 screws on the front side. 3. Hold the body of the system and lift it vertically away.

  • Page 59: Install Hdd/Ssd On The Internal Sata Bay

    Chapter 3: System Setup VCO-6000-CFL-4M2 l User’s Manual 3.5 Install HDD/SSD on the internal SATA bay 1. Two internal SATA HDD/SSD bays are available for RCO-6100 series. 2. Unscrew the 4 screws (M3x5L) to remove the internal SATA HDD/SSD bay.
  • Page 60 Chapter 3: System Setup VCO-6000-CFL-4M2 l User’s Manual 4. Install the HDD/SSD bracket following the direction below. 5. Fasten the 4 screws to lock the internal HDD/SSD bracket.

  • Page 61: Installing Hdd On Removable Sata Hdd Bay

    Chapter 3: System Setup VCO-6000-CFL-4M2 l User’s Manual 3.6 Installing HDD on removable SATA HDD bay Two removable SATA HDD bays are available for VCO-6000 Series. 1. Unscrew the two sun screws circled below to take out the removable SATA HDD bay.
  • Page 62 Chapter 3: System Setup VCO-6000-CFL-4M2 l User’s Manual 3. Slide the HDD bracket back and then fasten the sun screws. 4. Installation complete...

  • Page 63: Installing Sodimm

    Chapter 3: System Setup VCO-6000-CFL-4M2 l User’s Manual 3.7 Installing SODIMM 1. Place the system body with SODIMM socket facing upward. Two SODIMM sockets are available for RCO-6100 series on the top side. 2. Insert memory module from 45 degree direction.

  • Page 64: Installing Cpu

    Chapter 3: System Setup VCO-6000-CFL-4M2 l User’s Manual 3.8 Installing CPU 1. Press down the CPU socket lever in order to open the socket cover. 2. Remove the CPU protective cover.
  • Page 65 Chapter 3: System Setup VCO-6000-CFL-4M2 l User’s Manual 3. Insert CPU gently. 4. Press down the lever again to hold the socket cover.
  • Page 66 Chapter 3: System Setup VCO-6000-CFL-4M2 l User’s Manual 5. Paste thermal pad on the CPU. 6. Place the designated heat block onto the CPU with thermal pad.
  • Page 67 Chapter 3: System Setup VCO-6000-CFL-4M2 l User’s Manual 7. Lock the heat block with three screws (M3x5L). Screw driver will able to penetrate through the holes on the top in order to fasten the screws with copper stud. 8. Paste the thermal pad onto the installed heat block.
  • Page 68 Chapter 3: System Setup VCO-6000-CFL-4M2 l User’s Manual 9. Paste the thermal pad onto the installed heat block.

  • Page 69: Installing Mini Pcie Card / Msata

    Chapter 3: System Setup VCO-6000-CFL-4M2 l User’s Manual 3.9 Installing Mini PCIe card / mSATA The RCO-6100 series has two Mini PCIe slots, both of which are on the top. The MINI-PCI E1 on the top supports mSATA. MINI-PCI 1. Insert Mini PCIe card from 45 degree direction.

  • Page 70: Installing M.2 2280 Nvme Ssd

    Chapter 3: System Setup VCO-6000-CFL-4M2 l User’s Manual 3.10 Installing M.2 2280 NVMe SSD RCO-6100 series PCBA has an M.2 M key slot on the top, CN2 currently supports NVMe SSD applications 1. Insert M.2 M Key card from 45 degree direction.

  • Page 71: Installing Wifi Module

    Chapter 3: System Setup VCO-6000-CFL-4M2 l User’s Manual 3.11 Installing WiFi Module RCO-6100 series PCBA has an M.2 E key slot on the top, CN1 currently supports WiFi application 1. Insert M.2 E Key card from 45 degree direction. 2. Press the M.2 E Key card down and lock it with one screw (M2x3.7L).
  • Page 72 Chapter 3: System Setup VCO-6000-CFL-4M2 l User’s Manual 3. RCO-6100 series system has 4 antenna holes, remove antenna hole plug on the system panel. 4. Have antenna jack penetrate through the hole, and fasten the nut with SMA jack.
  • Page 73 Chapter 3: System Setup VCO-6000-CFL-4M2 l User’s Manual 5. Assemble the antenna and SMA jack together. 6. Attach the RF connector at the cable-end onto the communication module.

  • Page 74: Installing Mini Pcie Card / 4Glte

    Chapter 3: System Setup VCO-6000-CFL-4M2 l User’s Manual 3.12 Installing Mini PCIe card / 4GLTE RCO-6100 series PCBA has two Mini PCIe slots on the top, MINI-PCI E2 currently supports 4GLTE applications MINI-PCI E2 1. Insert Mini PCIe card from 45 degree direction.

  • Page 75: Installing Antenna

    Chapter 3: System Setup VCO-6000-CFL-4M2 l User’s Manual 3.13 Installing antenna 1. Remove antenna hole cover on the system panel. 2. Have antenna jack penetrate through the hole, and fasten the nut with SMA jack...
  • Page 76 Chapter 3: System Setup VCO-6000-CFL-4M2 l User’s Manual 3. Assemble the antenna and SMA jack together. 4. Attach the RF connector at the cable-end onto the communication module.

  • Page 77: Installing Graphic Card

    Chapter 3: System Setup VCO-6000-CFL-4M2 l User’s Manual 3.14 Installing graphic Card 1. Remove the 6 screws in the circle below. 2. Push the chassis cover following the below direction to open the expansion module.

  • Page 78: Ac Adapter With 4P Terminal Block

    Chapter 3: System Setup VCO-6000-CFL-4M2 l User’s Manual 3. Now you can remove the top cover. 4. Remove the 11 screws in the circle below...

  • Page 79: Ac Adapter With 4P Terminal Block

    Chapter 3: System Setup VCO-6000-CFL-4M2 l User’s Manual 5. Now you can remove the graphic card expansion module. 6. Remove the power cable.
  • Page 80 Chapter 3: System Setup VCO-6000-CFL-4M2 l User’s Manual 7. Remove the SFF 8654 x8 cable.
  • Page 81 Chapter 3: System Setup VCO-6000-CFL-4M2 l User’s Manual 8. Unscrew the 5 screws highlighted below. 9. Unscrew the 4 screws highlighted below.
  • Page 82 Chapter 3: System Setup VCO-6000-CFL-4M2 l User’s Manual 10. Unscrew the screw to remove the I/O sheild. 11. Install the graphic card according to the below direction and ensure the gold finger is inserted into the slot.
  • Page 83 Chapter 3: System Setup VCO-6000-CFL-4M2 l User’s Manual 12. Install the screw back to secure the graphic card. 13. Insert power cable from the power board to the graphic card.
  • Page 84 Chapter 3: System Setup VCO-6000-CFL-4M2 l User’s Manual 14. Adjust the arm until it holds the card firmly in place. 15. Then fasten the screw on the holder.
  • Page 85 Chapter 3: System Setup VCO-6000-CFL-4M2 l User’s Manual 16. Fasten the 4 screws. 17. Fasten the 2 screws.
  • Page 86 Chapter 3: System Setup VCO-6000-CFL-4M2 l User’s Manual 18. Put the graphic expansion module into the expansion chassis. 19. Fasten the 11 screws.
  • Page 87 Chapter 3: System Setup VCO-6000-CFL-4M2 l User’s Manual 20. Insert the power cable. 21. Insert the SFF 8654 x8 cable...
  • Page 88 Chapter 3: System Setup VCO-6000-CFL-4M2 l User’s Manual 22. Close the chassis cover...
  • Page 89 Chapter 3: System Setup VCO-6000-CFL-4M2 l User’s Manual 3.15 AC Adapter with 3P terminal block 1. 3P Wiring Diagram of AC Adapter 2. DC power input 3P wiring diagram...
  • Page 90 Chapter 3: System Setup VCO-6000-CFL-4M2 l User’s Manual 3.16 AC Adapter with 4P terminal block * 12V requires 4-pin terminal block for card/storage expansion 1. AC adapter 4P wiring diagram 2. DC power input 4P wiring diagram...

  • Page 91: Chapter 4 Bios Setup

    Chapter 4 BIOS Setup...

  • Page 92: Bios Introduction

    Chapter 4: BIOS Setup VCO-6000-CFL-4M2 l User’s Manual 4.1 BIOS Introduction The BIOS provides an interface to modify the configuration. When the battery is removed, all the parameters will be reset. BIOS Setup Power on the embedded system and by pressing <Del> immediately allows you to enter the setup screens.

  • Page 93: Main Setup

    Chapter 4: BIOS Setup VCO-6000-CFL-4M2 l User’s Manual 4.2 Main Setup Press <Del> to enter BIOS CMOS Setup Utility. The Main setup screen is showed as following when the setup utility is entered. System Date/Time is set up in the Main Menu.

  • Page 94: Advanced Setup

    Chapter 4: BIOS Setup VCO-6000-CFL-4M2 l User’s Manual 4.3 Advanced Setup...

  • Page 95: Connectivity Configuration

    Chapter 4: BIOS Setup VCO-6000-CFL-4M2 l User’s Manual 4.3.1 Connectivity Configuration Item Options Description CNVi Mode Disable Integrated, This option configures Connectivity. [Auto Auto Detection] means that if Discrete solution is Detection[Default] discovered it will be enabled by default. Otherwise Integrated solution (CNVi) will be enabled;...

  • Page 96: Cpu Configuration

    Chapter 4: BIOS Setup VCO-6000-CFL-4M2 l User’s Manual 4.3.2 CPU Configuration Item Options Description Intel (VMX) Virtualization Disabled, When enabled, a VMM can utilize the Technology Enabled[Default] additional hardware capabilities provided by Virtualization Technology. Active Processor Cores All[Default] Number of cores to enable in each processor package.

  • Page 97: Pch-Fw Configuration

    Chapter 4: BIOS Setup VCO-6000-CFL-4M2 l User’s Manual 4.3.3 PCH-FW Configuration Item Options Description AMT BIOS Features Disabled, When disabled AMT BIOS Features are no Enabled[Default] longer supported and user is no longer able to access MEBx Setup. Note:This option does not disable Manageability Features in FW.

  • Page 98: Sata And Rst Configuration

    Chapter 4: BIOS Setup VCO-6000-CFL-4M2 l User’s Manual 4.3.4 SATA and RST Configuration Item Options Description SATA Controller(s) Disabled, Enable/Disable SATA Device. Enabled[Default] SATA Mode Selection AHCI[Default] , Determines how SATA controller(s) operate. Intel RST Premium With Intel Optane System...

  • Page 99: Rst (Uefi Raid) Configuration

    Chapter 4: BIOS Setup VCO-6000-CFL-4M2 l User’s Manual 4.3.5 RST (UEFI RAID) Configuration How to set the UEFI RAID: 1. When set to “Intel RST Premium With Intel Optane System Acceleration“, please save change reset system. 2. After reboot the system, please into BIOS utility and then will see “Intel (R) Rapid Storage...
  • Page 100 Chapter 4: BIOS Setup VCO-6000-CFL-4M2 l User’s Manual 3. Into Intel(R) Rapid Storage Technology, and start create RAID volume. 4. Start Create the RAID ■ Select Disk that you want to do the RAID ■ Select [x]; No-Select [ ]...

  • Page 101: Trusted Computing

    Chapter 4: BIOS Setup VCO-6000-CFL-4M2 l User’s Manual 4.3.6 Trusted Computing Item Options Description Security Device Support Enabled, Enable/Disable BIOS support for security Disabled[Default] , device. O.S. will not show Security Device.TCG EFI protocol and INT1A interface will not be available.

  • Page 102: Acpi Settings

    Chapter 4: BIOS Setup VCO-6000-CFL-4M2 l User’s Manual 4.3.7 ACPI Settings Item Options Description Enable Hibernation Disabled , Enables or Disables System ability to Enabled[Default], Hibernate (OS/S4 Sleep State). This option may not be effective with some operating systems. ACPI Sleep State...

  • Page 103: Super Io Configuration

    Chapter 4: BIOS Setup VCO-6000-CFL-4M2 l User’s Manual 4.3.8 Super IO Configuration This setting allows you to select options for the Super IO Configuration, and change the value of the selected option. Item Description Serial Port 1 Configuration Set Parameters of Serial Port 1 (COMA).
  • Page 104 Chapter 4: BIOS Setup VCO-6000-CFL-4M2 l User’s Manual ◼ Serial Port 1 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the address IO=3F8h; IRQ=4; , &...
  • Page 105 Chapter 4: BIOS Setup VCO-6000-CFL-4M2 l User’s Manual ◼ Serial Port 2 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the address IO=2F8h; IRQ=3; , &...
  • Page 106 Chapter 4: BIOS Setup VCO-6000-CFL-4M2 l User’s Manual ◼ Serial Port 3 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the address IO=3E8h; IRQ=7; , &...
  • Page 107 Chapter 4: BIOS Setup VCO-6000-CFL-4M2 l User’s Manual ◼ Serial Port 4 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the address IO=2E8h; IRQ=7; , &...
  • Page 108 Chapter 4: BIOS Setup VCO-6000-CFL-4M2 l User’s Manual ◼ Serial Port 5 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the address IO=2F0h; IRQ=7; , &...
  • Page 109 Chapter 4: BIOS Setup VCO-6000-CFL-4M2 l User’s Manual ◼ Serial Port 6 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the address IO=2E0h; IRQ=7; , &...

  • Page 110: Hardware Monitor

    Chapter 4: BIOS Setup VCO-6000-CFL-4M2 l User’s Manual 4.3.9 Hardware Monitor These items display the current status of all monitored hardware devices/ components such as voltages and temperatures. Item Options Description Smart Fan Function Disabled[Default], Enabled or Disable Smart Fan...
  • Page 111 Chapter 4: BIOS Setup VCO-6000-CFL-4M2 l User’s Manual ◼ Smart Fan Mode Configuration Item Options Description Expansion Fan Manual Mode, Smart Fan Mode Select SmartFan Control SMART FAN IV Mode[Default], Temperature 1~4 1~100 Auto fan speed control. SMART FAN IV...

  • Page 112: Serial Port Console Redirection

    Chapter 4: BIOS Setup VCO-6000-CFL-4M2 l User’s Manual 4.3.10 Serial Port Console Redirection Item Options Description Console Redirection Disabled[Default], These items allows you to enable or disable Enabled COM1 console redirection...

  • Page 113: Network Stack Configuration

    Chapter 4: BIOS Setup VCO-6000-CFL-4M2 l User’s Manual 4.3.11 Network Stack Configuration Item Options Description Network Stack Disabled[Default] , Enable/Disable UEFI Network Stack. Enabled...

  • Page 114: Csm Configuration

    Chapter 4: BIOS Setup VCO-6000-CFL-4M2 l User’s Manual 4.3.12 CSM Configuration Item Options Description CSM Support Disabled, This item allows users to enable or disable Enabled[Default] for “CSM Support”. GateA20 Active Upon Request[Default] , This item allows users to set Upon Request Always or Always for "GateA20 Active“.

  • Page 115: Usb Configuration

    Chapter 4: BIOS Setup VCO-6000-CFL-4M2 l User’s Manual 4.3.13 USB Configuration Item Options Description Legacy USB Support Enabled[Default] Enables Legacy USB support. AUTO option Disabled disables legacy support if no USB devices Auto are connected. DISABLE option will keep USB devices available only for EFI applications.

  • Page 116: Chipset

    Chapter 4: BIOS Setup VCO-6000-CFL-4M2 l User’s Manual 4.4 Chipset This section allows you to configure and improve your system and allows you to set up some system features according to your preference. 4.4.1 System Agent (SA) Configuration...
  • Page 117 Chapter 4: BIOS Setup VCO-6000-CFL-4M2 l User’s Manual ◼ Memory Configuration Item Options Description Max TOLUD Dynamic[Default], Maximum Value of TOLUD. Dynamic 1GB, assignment would adjust TOLUD 1.25GB, automatically based on largest MMIO 1.5 GB, length of installed graphic controller 1.75 GB,...
  • Page 118 Chapter 4: BIOS Setup VCO-6000-CFL-4M2 l User’s Manual ◼ Graphic Configuration Item Options Description Primary Display Auto[Default] , Select which of IGFX/PEG Graphics device PEG + IGFX should be Primary Display. PEG+IGFX(Multiple-Displays): IGFX will be primary and only display under BIOS and DOS mode.
  • Page 119 Chapter 4: BIOS Setup VCO-6000-CFL-4M2 l User’s Manual ◼ PEG Port Configuration Item Options Description Enable Root Port Enabled[Default] , Enable or Disable the Root Port Disabled Max Link Speed Auto[Default] , Configure PEG 0:X:X Max Speed Gen1, Gen3, Gen3,...

  • Page 120: Pch-Io Configuration

    Chapter 4: BIOS Setup VCO-6000-CFL-4M2 l User’s Manual 4.4.2 PCH-IO Configuration Item Options Description PCH LAN Controller Enabled [Default] , Enable/Disable onboard NIC. Disabled Wake on LAN Enabled, Enable/Disable integrated LAN to wake the Enable Disabled [Default] system. Restore AC Power...
  • Page 121 Chapter 4: BIOS Setup VCO-6000-CFL-4M2 l User’s Manual ◼ PCI Express Configuration...
  • Page 122 Chapter 4: BIOS Setup VCO-6000-CFL-4M2 l User’s Manual ◼ PCI Express Root Port 8 / 9 / 16 Item Options Description PCI Express Root Disabled [Default] , Control the PCI Express Root Port. Port Enabled 5 /10 /14/15/16/19/21 ASPM Disabled [Default] ,...
  • Page 123 Chapter 4: BIOS Setup VCO-6000-CFL-4M2 l User’s Manual ◼ USB Configuration Item Options Description XHCI Disable Disabled [Default] , Option to enable Compliance Mode. Compliance mode Enabled Default is to disable Compliance Mode. Change to enabled for Compliance Mode testing.
  • Page 124 Chapter 4: BIOS Setup VCO-6000-CFL-4M2 l User’s Manual ◼ HD Audio Configuration Item Options Description HD Audio Disabled, Control Detection of the HD-Audio device. Enabled [Default] Disabled = HDA will be unconditionally disabled Enabled = HDA will be unconditionally enabled.

  • Page 125: Security

    Chapter 4: BIOS Setup VCO-6000-CFL-4M2 l User’s Manual 4.5 Security Security menu allow users to change administrator password and user password settings. ◼ Administrator Password This item allows you to set Administrator Password. ◼ User Password This item allows you to set User Password.
  • Page 126 Chapter 4: BIOS Setup VCO-6000-CFL-4M2 l User’s Manual ◼ Security Boot Item Options Description Secure Boot Disabled [Default] , Secure Boot feature is Active if Secure Boot Enabled is Enabled,Platform Key(PK) is enrolled and the System is in User mode.
  • Page 127 Chapter 4: BIOS Setup VCO-6000-CFL-4M2 l User’s Manual ◼ Key Management Item Options Description Factory Key Provision Disabled [Default] , Install factory default Secure Boot keys Enabled after the platform reset and while the System is in Setup mode...

  • Page 128: Boot

    Chapter 4: BIOS Setup VCO-6000-CFL-4M2 l User’s Manual 4.6 Boot This menu allows you to setup the system boot options. Item Options Description Setup Prompt 1[Default] Number of seconds to wait for setup Timeout activation key. 65535(0xFFFF) means indefinite waiting.

  • Page 129: Save & Exit

    Chapter 4: BIOS Setup VCO-6000-CFL-4M2 l User’s Manual 4.7 Save & Exit This setting allows users to configure the boot settings. ◼ Save Changes and Reset This item allows user to reset the system after saving the changes. This item allows user to reset the system after saving the changes.

  • Page 130: Appendix Wdt & Gpio

    Appendix WDT & GPIO This appendix provides the sample codes of WDT (Watch Dog Timer) and GPIO (General Purpose Input/ Output).

  • Page 131: Wdt Sample Code

    Appendix – WDT & GPIO VCO-6000-CFL-4M2 l User’s Manual WDT Sample Code WDT Setting Psuedo Code #define AddrPort 0x2e #define DataPort 0x2f #define SIO_UnLock_Value 0x87 #define SIO_Lock_Value 0xaa #define WATCHDOG_LDN 0x08 #define GPIO_Port 0xF1 //Enter_Config WriteByte (AddrPort, SIO_UnLock_Value); WriteByte (AddrPort, SIO_UnLock_Value);...

  • Page 132: Gpio Sample Code

    Appendix – WDT & GPIO VCO-6000-CFL-4M2 l User’s Manual GPIO Sample Code GPIO Setting PIN# GPIO# Default Configuration XCOM- XCOM+ OUT8 DIO Output8 DIO Input8 OUT7 DIO Output7 DIO Input7 OUT6 DIO Output6 DIO Input6 OUT5 DIO Output5 DIO Input5...
  • Page 133 Copyright © Premio Inc. All Rights Reserve www.premioinc.com...

Table of Contents
