  • Page 1 USER’S MANUAL VCO-6100 Series Superior Machine Vision System...

  • Page 2: Table Of Contents

    VCO-6100 Series Table of Contents Prefaces ……………………………………………………………………………………………….. 04 Revision ………………………………………………………..……………………………..……………….……….. 04 Disclaimer ……………………………………………………….…….……………….………………….………….. Copyright Notice …………………………………….…….….………………………………….………………… Trademarks Acknowledgment …………..………….………………………………………....Environmental Protection Announcement ……………………………………..……..……………….. Safety Precautions ……………………………………………………………………………………….….…….. Technical Support and Assistance ………………………………...……………………..…….…….……. Conventions Used in this Manual …………………………………..……………………..….……….. Package Contents ……………………………………………………………………..…..…………………….…...
  • Page 3 VCO-6100 Series Chapter 3 System Setup …………………………..…………………………….…………… 71 Set torque force to 3.5 kgf-cm to execute all the screwing and unscrewing …………………………………………………………………………………………….. 72 Removing heat sink cover………………...………………………………………....72 Disconnecting expansion module from computing module......74 Removing chassis bottom cover……..………………………….….………………..75 Install HDD/SSD on the internal SATA bay……………..…….………………………..

  • Page 4: Prefaces

    2021/1/27 Disclaimer All specifications and information in this User’s Manual are believed to be accurate and up to date. Premio Inc. does not guarantee that the contents herein are complete, true, accurate or non-misleading. The information in this document is subject to change without notice and does not represent a commitment on the part of Premio Inc.

  • Page 5: Safety Precautions

    Preface VCO-6100 Series Safety Precautions Before installing and using the equipment, please read the following precautions:  Put this equipment on a reliable surface during installation. Dropping it or letting it fall could cause damage.  The power outlet shall be installed near the equipment and shall be easily accessible.

  • Page 6: Technical Support And Assistance

    Preface VCO-6100 Series Technical Support and Assistance 1. Visit the Premio Inc website at premioinc.comwhere you can find the latest information about the product. 2. Contact your distributor, our technical support team or sales representative for technical support if you need additional assistance. Please have following information ready before you call: ...

  • Page 7: Package Contents

    Package Contents Before installation, please ensure all the items listed in the following table are included in the package. Item Description Q’ty VCO-6100 Series Fanless Embedded System Utility DVD Driver Wall Mount Kit Accessory Kit DVI to VGA Adapter Ordering Information Model No.

  • Page 8: Optional Accessory

    Preface VCO-6100 Series Optional Accessories Model No. Product Description Adapter AC/DC 24V/11.67A 280W with 3pin Terminal Block Plug 1-E09A22801 5.0mm Pitch Adapter AC/DC 24V 9.2A 220W with 3pin Terminal Block Plug 1-E09A22102 5.0mm Pitch SFICBL022 Power Cord, 3-pin US Type, 180cm...

  • Page 9: Chapter 1 Product Introductions

    Chapter 1 Product Introductions...

  • Page 10: Overview

    Chapter 1: Product Introductions 1.1 Overview The VCO-6100 series support 9th Gen. Intel® Core™ i7-9700E (4.4GHz, 8 Cores) / i5-9500E (4.2GHz, 6 Cores) / i3-9100E (3.7GHz, 4 Cores) / i7-9700TE (3.8GHz, 8 Cores) / i5-9500TE (3.6GHz, 6 Cores) / i3- 9100TE (3.2GHz, 4 Cores) or 8th Gen.

  • Page 11: Hardware Specification

    VCO-6100 Series Chapter 1: Product Introductions 1.2 Hardware Specification System Support 8 Gen Intel® CFL-R S Processor (LGA 1151, 65W/35W TDP) Intel® Core™ i7-9700E, 8 Cores, 12MB cache, up to 4.4 GHz (24V) Intel® Core™ i7-9700TE, 8 Cores, 12MB cache, up to 3.8 GHz Intel®...
  • Page 12 VCO-6100 Series Chapter 1: Product Introductions Model: VCO-6122C-2PWR 1x PCIe x16, 1x PCl Model: VCO-6133E-2PWR 1x PCIe x16, 2x PCIe x4 (1-Lane) Card Dimension 310 (L) x 112 (H) mm 2x RS-232/422/485, 4x RS-232/422/485 (internal) 4x USB 3.2 Gen 2 (10 Gbps), 4x USB 3.2 Gen 1 (5 Gbps, internal))
  • Page 13 VCO-6100 Series Chapter 1: Product Introductions VCO-6122: 4.21 kg VCO-6133: 4.26 kg VCO-6144: 4.31 kg Weight VCO-6155: 4.36 kg VCO-6122C-2PWR: 7.83 kg VCO-6133E-2PWR: 8.34 kg Mounting Wall Mounting / Book mounting (Optional)

  • Page 14: System I/O

    VCO-6100 Series Chapter 1: Product Introductions 1.3 System I/O 1.3.1 VCO-6122 Front Panel DVI-I port ATX power on/off switch Used to connect a DVI monitor or connect Press to power-on or power-off the system optional split cable for dual display mode...
  • Page 15 VCO-6100 Series Chapter 1: Product Introductions 1.3.1 VCO-6122 Rear Panel & Top View ATX power on/off switch 2x Universal I/O Bracket (By mini PCIe interface) Rear Panel Top View...

  • Page 16: Vco-6133

    VCO-6100 Series Chapter 1: Product Introductions 1.3 System I/O 1.3.2 VCO-6133 Front Panel DVI-I port ATX power on/off switch Used to connect a DVI monitor or connect Press to power-on or power-off the system optional split cable for dual display mode...
  • Page 17 VCO-6100 Series Chapter 1: Product Introductions 1.3.2 VCO-6133 Rear Panel & Top View ATX power on/off switch 2x Universal I/O Bracket (By mini PCIe interface) Rear Panel Top View...

  • Page 18: Vco-6144

    VCO-6100 Series Chapter 1: Product Introductions 1.3 System I/O 1.3.3 VCO-6144 Front Panel DVI-I port ATX power on/off switch Used to connect a DVI monitor or connect Press to power-on or power-off the system optional split cable for dual display mode...
  • Page 19 VCO-6100 Series Chapter 1: Product Introductions 1.3.3 VCO-6144 Rear Panel & Top View ATX power on/off switch 2x Universal I/O Bracket (By mini PCIe interface) Rear Panel Top View...

  • Page 20: Vco-6155

    VCO-6100 Series Chapter 1: Product Introductions 1.3 System I/O 1.3.4 VCO-6155 Front Panel DVI-I port ATX power on/off switch Used to connect a DVI monitor or connect Press to power-on or power-off the system optional split cable for dual display mode...
  • Page 21 VCO-6100 Series Chapter 1: Product Introductions 1.3.4 VCO-6155 Rear Panel & Top View ATX power on/off switch 2x Universal I/O Bracket (By mini PCIe interface) Rear Panel Top View...

  • Page 22: Vco-6122C-2Pwr

    VCO-6100 Series Chapter 1: Product Introductions 1.3 System I/O 1.3.5 VCO-6122C-2PWR Front Panel DVI-I port ATX power on/off switch Used to connect a DVI monitor or connect Press to power-on or power-off the system optional split cable for dual display mode...
  • Page 23 VCO-6100 Series Chapter 1: Product Introductions 1.3.5 VCO-6122C-2PWR Rear Panel & Top View ATX power on/off switch 2x Universal I/O Bracket (By mini PCIe interface) Rear Panel Top View...

  • Page 24: Vco-6133E-2Pwr

    VCO-6100 Series Chapter 1: Product Introductions 1.3 System I/O 1.3.6 VCO-6133E-2PWR Front Panel DVI-I port ATX power on/off switch Used to connect a DVI monitor or connect Press to power-on or power-off the system optional split cable for dual display mode...
  • Page 25 VCO-6100 Series Chapter 1: Product Introductions 1.3.6 VCO-6133E-2PWR Rear Panel & Top View ATX power on/off switch 2x Universal I/O Bracket (By mini PCIe interface) Rear Panel Top View...

  • Page 26: Mechanical Dimension

    VCO-6100 Series Chapter 1: Product Introductions 1.4 Mechanical Dimensions 1.4.1 VCO-6122 Unit: mm...

  • Page 27: Vco-6133

    VCO-6100 Series Chapter 1: Product Introductions 1.4.2 VCO-6133 Unit: mm...

  • Page 28: Vco-6144

    VCO-6100 Series Chapter 1: Product Introductions 1.4.3 VCO-6144 Unit: mm...

  • Page 29: Vco-6155

    VCO-6100 Series Chapter 1: Product Introductions 1.4.4 VCO-6155 Unit: mm...

  • Page 30: Vco-6122C-2Pwr

    VCO-6100 Series Chapter 1: Product Introductions 1.4.5 VCO-6122C-2PWR Unit: mm...

  • Page 31: Vco-6133E-2Pwr

    VCO-6100 Series Chapter 1: Product Introductions 1.4.6 VCO-6133E-2PWR Unit: mm...

  • Page 32: Chapter 2 Switches And Connectors

    Chapter 2 Switches and Connectors...

  • Page 33: Switch And Connector Locations

    VCO-6100 Series Chapter 2: Switches and Connectors 2.1 Switch and Connector Locations 2.1.1 Top View...

  • Page 34: Bottom View

    VCO-6100 Series Chapter 2: Switches and Connectors 2.1.2 Bottom View...

  • Page 35: Connector / Switch Definition

    VCO-6100 Series Chapter 2: Switches and Connectors 2.2 Connector / Switch Definition List of Connector / Switch Connector Location Definition AT_ATX1 AT / ATX Power Mode Switch PWR_SW1 Power Switch RESET1 Reset Switch USB 3.2 Gen 2 、 USB 3.2 Gen 1 、 USB2.0...

  • Page 36: I/O Interface Descriptions

    VCO-6100 Series Chapter 2: Switches and Connectors 2.3 I/O Interface Descriptions 2.3.1 LPC Debug Con Signal Signal +3.3V LPC_AD3 LPC_AD2 Reset LPC_AD1 LPC_FRAME-L LPC_AD0 Clock...

  • Page 37: Power Con

    VCO-6100 Series Chapter 2: Switches and Connectors 2.3 I/O Interface Descriptions 2.3.2 Power Con 1 2 3 4 POWER1 Signal +12V...

  • Page 38: Dc In/Ign In (+9V ~ +48V)

    VCO-6100 Series Chapter 2: Switches and Connectors 2.3 I/O Interface Descriptions 2.3.3 DC IN/IGN IN (+9V ~ +48V) 1 2 3 DC_IN1 Signal +DC_IN IGN_SENSE...

  • Page 39: Com Con

    VCO-6100 Series Chapter 2: Switches and Connectors 2.3 I/O Interface Descriptions 2.3.4 COM Con COM5_1 , COM6_1 Signal Signal DCD# DSR# RTS# CTS# DTR# RS232 / RS422 / RS485 Connector 2x5 10-pin box header, 2.0mm pitch RS232 Definition RS422 / 485 Full Duplex Definition RS485 Half Duplex Definition...
  • Page 40 VCO-6100 Series Chapter 2: Switches and Connectors 2.3 I/O Interface Descriptions COM1_2 , COM3_4 RS232 / RS422 / RS485 Connector Type: 9-pin D-Sub RS422 / 485 Full Duplex RS232 Definition RS485 Half Duplex Definition Definition 1(10) DCD# DATA- 2(11) DATA+...

  • Page 41: Sf100 Spi Con

    VCO-6100 Series Chapter 2: Switches and Connectors 2.3 I/O Interface Descriptions 2.3.5 SF100 SPI Con Signal Signal Power ( 3V ) MISO MOSI SPI_GATE#...
  • Page 42 VCO-6100 Series Chapter 2: Switches and Connectors 2.3 I/O Interface Descriptions AT_ATX1 Left Right CAR_PWR1 Left Right CAR_PWR1 AT_ATX1 AT_ATX1: AT / ATX Power Mode Switch Switch Definition 1-2 (Left) ATX Power Mode (Default) 2-3 (Right) AT Power Mode CAR_PWR1: PC / Car Mode Switch...
  • Page 43 VCO-6100 Series Chapter 2: Switches and Connectors 2.3 I/O Interface Descriptions 1 2 3 DELAY_TIME1 Power off delay time setup Switch Switch 1 / 2 / 3 Definition ON / ON / ON 3 sec.（Default Shutdown Timer by O.S） ON / ON / OFF 1 min.
  • Page 44 VCO-6100 Series Chapter 2: Switches and Connectors 2.3 I/O Interface Descriptions LINE_OUT1 MIC_IN1 LINE_OUT1 : MIC_IN1 : Line-out Jack (Green) Connector Type: 5- Microphone Jack (Pink) Connector Type: pin Phone Jack 5-pin Phone Jack Definition Definition OUT_R MIC_R OUT_L MIC_L...
  • Page 45 VCO-6100 Series Chapter 2: Switches and Connectors 2.3 I/O Interface Descriptions CLR_CMOS1: Clear BIOS Switch Switch Definition 1-2 (Left) Normal Status (Default) 2-3 (Right) Clear BIOS PWR_SW1: Power Button Definition Definition Power Button...
  • Page 46 VCO-6100 Series Chapter 2: Switches and Connectors 2.3 I/O Interface Descriptions RESET1 : Reset Button Definition RESET USB3_1 : USB3.1 Connector, Type A Definition Definition USB3_RX+ USB2_D- USB2_D+ USB3_TX- USB3_TX+ USB3_RX-...
  • Page 47 VCO-6100 Series Chapter 2: Switches and Connectors 2.3 I/O Interface Descriptions CN7 : USB2.0 Connector 2x5 10-pin box header, 2.0mm pitch Definition Definition USB2_D- USB2_D- USB2_D+ USB2_D+...
  • Page 48 VCO-6100 Series Chapter 2: Switches and Connectors 2.3 I/O Interface Descriptions CN6 : USB3.1 Connector, Type A x 4 Definition Definition USB3_RX+ USB2_D- USB2_D+ USB3_TX- USB3_TX+ USB3_RX-...
  • Page 49 VCO-6100 Series Chapter 2: Switches and Connectors 2.3 I/O Interface Descriptions SIM1 : Top size SIM Card Socket SIM2 : Bottom size SIM Card Socket SIM1 SIM2 Definition Definition UIM_PWR UIM_VPP UIM_RESET UIM_DATA UIM_CLK...
  • Page 50 VCO-6100 Series Chapter 2: Switches and Connectors 2.3 I/O Interface Descriptions DVI_I1: DVI-I Connector Definition Definition DVI_TX2- DVI Hot Plug Detect DVI_TX2+ DVI_TX0- DVI_TX0+ VGA_DDC_CLOCK DVI_DDC_CLOCK VGA_DDC_DATA DVI_DDC_DATA VGA VSYNC DVI_TXCLK+ DVI_TX1- DVI_TXCLK- DVI_TX1+ VGA_RED VGA_GREEN VGA_BLUE VGA_HSYNC...
  • Page 51 VCO-6100 Series Chapter 2: Switches and Connectors 2.3 I/O Interface Descriptions DP1 DP2 : Display Port Connector Definition Definition DP_LANE0_P DP_LANE3_N DP_LANE0_N DP_LANE1_P DP_AUX_P DP_LANE1_N DP_LANE2_P DP_AUX_N DP_HPD DP_LANE2_N DP_LANE3_P +3.3V...
  • Page 52 VCO-6100 Series Chapter 2: Switches and Connectors 2.3 I/O Interface Descriptions DIO : Digital Input / Output Connector Type: Terminal Block 2x9 18-pin, 3.5mm pitch Definition Definition DIN1 DOUT1 DIN2 DOUT2 DIN3 DOUT3 DIN4 DOUT4 DIN5 DOUT5 DIN6 DOUT6 DIN7...
  • Page 53 VCO-6100 Series Chapter 2: Switches and Connectors 2.3 I/O Interface Descriptions Digital Input Wurung Digital Output Wurung...
  • Page 54 VCO-6100 Series Chapter 2: Switches and Connectors 2.3 I/O Interface Descriptions PWR_SW2 : Remote Power Switch Type: Terminal Block 1x2 2-pin, 3.5mm pitch Definition Power Button...
  • Page 55 VCO-6100 Series Chapter 2: Switches and Connectors 2.3 I/O Interface Descriptions PWR_SW3 : Remote Power Switch 1x4 pin box header, 2.0mm pitch Definition Power Button PWR_LED HDD_LED...
  • Page 56 VCO-6100 Series Chapter 2: Switches and Connectors 2.3 I/O Interface Descriptions CN3 CN4 : LAN and USB3.1 GEN 2 Ports Connector Type:RJ45 port with LEDs and dual USB3.1 ports Definition Definition Definition LAN1_MDI0P USB2_D1- USB2_D2- LAN1_MDI0N USB2_D1+ USB2_D2+ LAN1_MDI1P LAN1_MDI2P...
  • Page 57 VCO-6100 Series Chapter 2: Switches and Connectors 2.3 I/O Interface Descriptions Act LED Status Definition Blinking Yellow Data Activity No Activity Link LED Status Definition Steady Orange 1Gbps Network Link Steady Green 100Mbps Network Link 10Mbps Network Link PWR_LED1 HDD_LED1...
  • Page 58 VCO-6100 Series Chapter 2: Switches and Connectors 2.3 I/O Interface Descriptions MINIPCIE2 : Mini PCI-Express Socket Definition Definition WAKE# +3.3V +1.5V CLKREQ# UIM_PWR UIM_DATA REFCLK- UIM_CLK REFCLK+ UIM_RST UIM_VPP RESET# +3.3VAUX +1.5V SMB_CLK SMB_DATA USB2_D- USB2_D+ +3.3V +3.3V +1.5V +3.3V...
  • Page 59 VCO-6100 Series Chapter 2: Switches and Connectors 2.3 I/O Interface Descriptions MINIPCIE1 : Mini PCI-Express / mSATA Socket Definition Definition WAKE# +3.3V +1.5V CLKREQ# UIM_PWR UIM_DATA REFCLK- UIM_CLK REFCLK+ UIM_RST UIM_VPP RESET# +3.3VAUX +1.5V SMB_CLK SMB_DATA USB2_D- USB2_D+ +3.3V +3.3V DEVSLP +1.5V...
  • Page 60 VCO-6100 Series Chapter 2: Switches and Connectors 2.3 I/O Interface Descriptions SATA with Power Connector Definition Definition +12V DEVSLP +12V +12V...
  • Page 61 VCO-6100 Series Chapter 2: Switches and Connectors 2.3 I/O Interface Descriptions PCIE : PCI-Express x1 Slot Definition Definition +12V FAN_P4 +12V +12V +12V +12V SMB_CLK SMB_DATA +3.3V +3.3V +3.3VAUX +3.3V WAKE# RESET# FAN_P3 REFCLK+ TxP0 REFCLK- TxN0 RxP0 FAN_PER RxN0...
  • Page 62 VCO-6100 Series Chapter 2: Switches and Connectors 2.3 I/O Interface Descriptions PCIE : PCI-Express x8 Slot Definition Definition +12V +12V +12V +12V +12V SMB_CLK SMB_DATA +3.3V +3.3V +3.3VAUX +3.3V WAKE# RESET# REFCLK+ TxP0 REFCLK- TxN0 RxP0 RxN0...
  • Page 63 VCO-6100 Series Chapter 2: Switches and Connectors 2.3 I/O Interface Descriptions PCIE : PCI-Express x8 Slot Definition Definition TxP1 TxN1 RxP1 RxN1 TxP2 TxN2 RxP2 RxN2 TxP3 TxN3 RxP3 RxN3 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN...
  • Page 64 VCO-6100 Series Chapter 2: Switches and Connectors 2.3 I/O Interface Descriptions PCIE : PCI-Express x16 Slot Definition Definition +12V FAN_P4 +12V +12V +12V +12V SMB_CLK SMB_DATA +3.3V +3.3V +3.3VAUX +3.3V WAKE# RESET# FAN_P3 REFCLK+ TxP0 REFCLK- TxN0 RxP0 FAN_PWR RxN0...
  • Page 65 VCO-6100 Series Chapter 2: Switches and Connectors 2.3 I/O Interface Descriptions PCIE : PCI-Express x16 Slot Definition Definition TxP1 TxN1 RxP1 RxN1 TxP2 TxN2 RxP2 RxN2 TxP3 TxN3 RxP3 RxN3 CFG_5 TxP4 CFG_6 TxN4 RxP4 RxN4 TxP5 TxN5 RxP5 RxN5...
  • Page 66 VCO-6100 Series Chapter 2: Switches and Connectors 2.3 I/O Interface Descriptions PCIE : PCI-Express x16 Slot Definition Definition TxN8 RxP8 RxN8 TxP9 TxN9 RxP9 RxN9 TxP10 TxN10 RxP10 RxN10 TxP11 TxN11 RxP11 RxN11 TxP12 TxN12 RxP12 RxN12 TxP13 TxN13 RxP13...
  • Page 67 VCO-6100 Series Chapter 2: Switches and Connectors 2.3 I/O Interface Descriptions CN1 : M.2 E Key Socket Definition Definition +3.3VAUX USB2_D+ +3.3VAUX USB2_D- LED1# LED2# TxP0 TxN0 RxP0 RxN0...
  • Page 68 VCO-6100 Series Chapter 2: Switches and Connectors 2.3 I/O Interface Descriptions CN1 : M.2 E Key Socket Definition Definition REFCLK0+ REFCLK0- SUSCLK PERST0# WAKE0# TxP1 TxN1 Pull Low RxP1 PERST1# RxN1 WAKE1# REFCLK1+ +3.3VAUX REFCLK1- +3.3VAUX...
  • Page 69 VCO-6100 Series Chapter 2: Switches and Connectors 2.3 I/O Interface Descriptions CN2 : M.2 M Key Socket Definition Definition +3.3V +3.3V RxN3 RxP3 LED# TxN3 +3.3V TxP3 +3.3V +3.3V RxN2 +3.3V RxP2 TxN2 TxP2 RxN1 RxP1 TxN1...
  • Page 70 VCO-6100 Series Chapter 2: Switches and Connectors 2.3 I/O Interface Descriptions CN2 : M.2 M Key Socket Definition Definition TxP1 Pull Low RxN0/SATA_B+ RxP0/SATA_B- TxN0 TxP0 PERST# Pull Hi REFCLK- WAKE# REFCLK+ SUSCLK PEDET +3.3V +3.3V +3.3V...

  • Page 71: Chapter 3 System Setup

    Chapter 3 System Setup...

  • Page 72: Set Torque Force To 3.5 Kgf-Cm To Execute All The Screwing And Unscrewing

    VCO-6100 Series Chapter 3: System Setup 3.1 Set torque force to 3.5 kgf-cm to execute all the screwing and unscrewing. 3.2 Removing heat sink cover In order to prevent electric shock or system damage, before removing the chassis cover, must turn off power and disconnect the unit from power source.
  • Page 73 VCO-6100 Series Chapter 3: System Setup 2. Unscrew the 4 screws on the bottom side. 3. Now you can remove the heat sink cover.

  • Page 74: Disconnecting Expansion Module From Computing Module

    VCO-6100 Series Chapter 3: System Setup Disconnecting expansion module from computing module 1. Remove the 3 connecting brackets on the top side of the system and the 3 brackets on the bottom side. 2. Now you can separate the expansion module from the computing module.

  • Page 75: Removing Chassis Bottom Cover

    VCO-6100 Series Chapter 3: System Setup 3.4 Removing chassis bottom cover 1. Unscrew the 6 screws highlighted below. 2. Unscrew 4 screws on the front side. 3. Hold the body of the system and lift it vertically away.

  • Page 76: Install Hdd/Ssd On The Internal Sata Bay

    Chapter 3: System Setup 3.5 Install HDD/SSD on the internal SATA bay 1. Two internal SATA HDD/SSD bays are available for VCO-6100 series. 2. Unscrew the 4 screws (M3x5L) to remove the internal SATA HDD/SSD bay. 3. Lock the 2.5” HDD with HDD/SSD bracket using four screws (M3x4L).
  • Page 77 VCO-6100 Series Chapter 3: System Setup 4. Install the HDD/SSD bracket following the direction below. 5. Fasten the 4 screws to lock the internal HDD/SSD bracket.

  • Page 78: Installing Hdd On Removable Sata Hdd Bay

    VCO-6100 Series Chapter 3: System Setup 3.6 Installing HDD on removable SATA HDD bay Two removable SATA HDD bays are available for VCO-6000 Series. 1. Unscrew the two sun screws circled below to take out the removable SATA HDD bay.
  • Page 79 VCO-6100 Series Chapter 3: System Setup 3. Slide the HDD bracket back and then fasten the sun screws. 4. Installation complete...

  • Page 80: Installing Sodimm

    3.7 Installing SODIMM 1. Place the system body with SODIMM socket facing upward. Two SODIMM sockets are available for VCO-6100 series on the top side. 2. Insert memory module from 45 degree direction. 3. Press the memory module vertically downward until you hear the “click” sound.

  • Page 81: Installing Cpu

    VCO-6100 Series Chapter 3: System Setup 3.8 Installing CPU 1. Press down the CPU socket lever in order to open the socket cover. 2. Remove the CPU protective cover.
  • Page 82 VCO-6100 Series Chapter 3: System Setup 3. Insert CPU gently. 4. Press down the lever again to hold the socket cover.
  • Page 83 VCO-6100 Series Chapter 3: System Setup 5. Paste thermal pad on the CPU. 6. Place the designated heat block onto the CPU with thermal pad.
  • Page 84 VCO-6100 Series Chapter 3: System Setup 7. Lock the heat block with three screws (M3x5L). Screw driver will able to penetrate through the holes on the top in order to fasten the screws with copper stud. 8. Paste the thermal pad onto the installed heat block.
  • Page 85 VCO-6100 Series Chapter 3: System Setup 9. Paste the thermal pad onto the installed heat block.

  • Page 86: Installing Mini Pcie Card / Msata

    VCO-6100 Series Chapter 3: System Setup 3.9 Installing Mini PCIe card / mSATA The VCO-6100 series has two Mini PCIe slots, both of which are on the top. The MINI- PCI E1 on the top supports mSATA. MINI-PCI 1. Insert Mini PCIe card from 45 degree direction.

  • Page 87: Installing M.2 2280 Nvme Ssd

    VCO-6100 Series Chapter 3: System Setup 3.10 Installing M.2 2280 NVMe SSD VCO-6100 series PCBA has an M.2 M key slot on the top, CN2 currently supports NVMe SSD applications 1. Insert M.2 M Key card from 45 degree direction.

  • Page 88: Installing Wifi Module

    VCO-6100 Series Chapter 3: System Setup 3.11 Installing WiFi Module VCO-6100 series PCBA has an M.2 E key slot on the top, CN1 currently supports WiFi application 1. Insert M.2 E Key card from 45 degree direction. 2. Press the M.2 E Key card down and lock it with one screw (M2x3.7L).
  • Page 89 VCO-6100 Series Chapter 3: System Setup 3. VCO-6100 series system has 4 antenna holes, remove antenna hole plug on the system panel. 4. Have antenna jack penetrate through the hole, and fasten the nut with SMA jack.
  • Page 90 VCO-6100 Series Chapter 3: System Setup 5. Assemble the antenna and SMA jack together. 6. Attach the RF connector at the cable-end onto the communication module.

  • Page 91: Installing Mini Pcie Card / 4Glte

    VCO-6100 Series Chapter 3: System Setup 3.12 Installing Mini PCIe card / 4GLTE VCO-6100 series PCBA has two Mini PCIe slots on the top, MINI-PCI E2 currently supports 4GLTE applications MINI-PCI E2 1. Insert Mini PCIe card from 45 degree direction.

  • Page 92: Installing Antenna

    VCO-6100 Series Chapter 3: System Setup 3.13 Installing Antenna 1. Remove antenna hole cover on the system panel. 2. Have antenna jack penetrate through the hole, and fasten the nut with SMA jack...
  • Page 93 VCO-6100 Series Chapter 3: System Setup 3. Assemble the antenna and SMA jack together. 4. Attach the RF connector at the cable-end onto the communication module.

  • Page 94: Installing Graphic Card

    VCO-6100 Series Chapter 3: System Setup 3.14 Installing graphic Card (For GPU/2PWR Series Product) 1. Remove the 2 screws in the circle below. 2. Push the chassis cover following the below direction to open the expansion module.
  • Page 95 VCO-6100 Series Chapter 3: System Setup 3. Remove the 5 nuts(M3) in the circle below​...
  • Page 96 VCO-6100 Series Chapter 3: System Setup 4. Remove the 4 screws in the circle below 5. Remove the 4 screws in the circle below...
  • Page 97 VCO-6100 Series Chapter 3: System Setup 6. Install the fan according to the below direction 7. Fasten the 4 screws.
  • Page 98 VCO-6100 Series Chapter 3: System Setup 8. Insert fan power cable 9. Unscrew the card bracket screws to remove the bracket from the expansion slots.
  • Page 99 VCO-6100 Series Chapter 3: System Setup 10. Install the graphic card according to the below direction and ensure the gold finger is inserted into the slot. and then fasten the screws. 11. Adjust the arm until it holds the card firmly in place.
  • Page 100 VCO-6100 Series Chapter 3: System Setup 12. Then fasten the screw on the holder. 13. Insert power cable from the power board to the graphic card.
  • Page 101 VCO-6100 Series Chapter 3: System Setup 14. Close the chassis cover.
  • Page 102 VCO-6100 Series Chapter 3: System Setup 15. Following the below direction to close the chassis cover.

  • Page 103: Chapter 4 Bios Setup

    Chapter 4 BIOS Setup...

  • Page 104: Bios Introduction

    VCO-6100 Series Chapter 4: BIOS Setup 4.1 BIOS Introduction The BIOS provides an interface to modify the configuration. When the battery is removed, all the parameters will be reset. BIOS Setup Power on the embedded system and by pressing <Del> immediately allows you to enter the setup screens.

  • Page 105: Main Setup

    VCO-6100 Series Chapter 4: BIOS Setup 4.2 Main Setup Press <Del> to enter BIOS CMOS Setup Utility. The Main setup screen is showed as following when the setup utility is entered. System Date/Time is set up in the Main Menu.

  • Page 106: Advanced Setup

    VCO-6100 Series Chapter 4: BIOS Setup 4.3 Advanced Setup...

  • Page 107: Cpu Configuration

    VCO-6100 Series Chapter 4: BIOS Setup 4.3.1 CPU Configuration Item Options Description Intel (VMX) Virtualization Disabled, When enabled, a VMM can utilize the Technology Enabled[Default] additional hardware capabilities provided by Virtualization Technology. Active Processor Cores All[Default] Number of cores to enable in each processor package.

  • Page 108: Pch-Fw Configuration

    VCO-6100 Series Chapter 4: BIOS Setup 4.3.2 PCH-FW Configuration Item Options Description AMT BIOS Features Disabled, When disabled AMT BIOS Features are no Enabled[Default] longer supported and user is no longer able to access MEBx Setup. Note:This option does not disable Manageability Features in FW.

  • Page 109: Sata And Rst Configuration

    VCO-6100 Series Chapter 4: BIOS Setup 4.3.3 SATA and RST Configuration Item Options Description SATA Controller(s) Disabled, Enable/Disable SATA Device. Enabled[Default] SATA Mode Selection AHCI[Default] , Determines how SATA controller(s) operate. Intel RST Premium With Intel Optane System Acceleration Use RST Legacy OROM Disabled[Default] , Use RST Legacy OROM when CSM is Enabled.

  • Page 110: Rst (Uefi Raid) Configuration

    VCO-6100 Series Chapter 4: BIOS Setup 4.3.4 RST (UEFI RAID) Configuration How to set the UEFI RAID: 1. When set to “Intel RST Premium With Intel Optane System Acceleration“, please save change reset system. 2. After reboot the system, please into BIOS utility and then will see “Intel (R) Rapid Storage...
  • Page 111 VCO-6100 Series Chapter 4: BIOS Setup 3. Into Intel(R) Rapid Storage Technology, and start create RAID volume. 4. Start Create the RAID  Select Disk that you want to do the RAID  Select [x]; No-Select [ ]...

  • Page 112: Trusted Computing

    VCO-6100 Series Chapter 4: BIOS Setup 4.3.5 Trusted Computing Item Options Description Security Device Support Enabled, Enable/Disable BIOS support for security Disabled[Default] , device. O.S. will not show Security Device.TCG EFI protocol and INT1A interface will not be available. Pending operation None[Default] , Schedule an Operation for the Security Device.

  • Page 113: Acpi Settings

    VCO-6100 Series Chapter 4: BIOS Setup 4.3.6 ACPI Settings Item Options Description Enable Hibernation Disabled , Enables or Disables System ability to Enabled[Default], Hibernate (OS/S4 Sleep State). This option may not be effective with some operating systems. ACPI Sleep State...

  • Page 114: Super Io Configuration

    VCO-6100 Series Chapter 4: BIOS Setup 4.3.7 Super IO Configuration This setting allows you to select options for the Super IO Configuration, and change the value of the selected option. Item Description Serial Port 1 Configuration Set Parameters of Serial Port 1 (COMA).
  • Page 115 VCO-6100 Series Chapter 4: BIOS Setup  Serial Port 1 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the address IO=3F8h; IRQ=4; , & IRQ settings of the specified serial port.
  • Page 116 VCO-6100 Series Chapter 4: BIOS Setup  Serial Port 2 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the address IO=2F8h; IRQ=3; , & IRQ settings of the specified serial port.
  • Page 117 VCO-6100 Series Chapter 4: BIOS Setup  Serial Port 3 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the address IO=3E8h; IRQ=7; , & IRQ settings of the specified serial port.
  • Page 118 VCO-6100 Series Chapter 4: BIOS Setup  Serial Port 4 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the address IO=2E8h; IRQ=7; , & IRQ settings of the specified serial port.
  • Page 119 VCO-6100 Series Chapter 4: BIOS Setup  Serial Port 5 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the address IO=2F0h; IRQ=7; , & IRQ settings of the specified serial port.
  • Page 120 VCO-6100 Series Chapter 4: BIOS Setup  Serial Port 6 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the address IO=2E0h; IRQ=7; , & IRQ settings of the specified serial port.

  • Page 121: Hardware Monitor

    VCO-6100 Series Chapter 4: BIOS Setup 4.3.8 Hardware Monitor These items display the current status of all monitored hardware devices/ components such as voltages and temperatures. Item Options Description Smart Fan Function Disabled[Default], Enabled or Disable Smart Fan Enabled...
  • Page 122 VCO-6100 Series Chapter 4: BIOS Setup  Smart Fan Mode Configuration Item Options Description Expansion Fan Manual Mode, Smart Fan Mode Select SmartFan Control SMART FAN IV Mode[Default], 4M2 Expansion Fan Manual Mode, Smart Fan Mode Select SmartFan Control SMART FAN IV Mode[Default],...

  • Page 123: Serial Port Console Redirection

    VCO-6100 Series Chapter 4: BIOS Setup 4.3.9 Serial Port Console Redirection Item Options Description Console Redirection Disabled[Default], These items allows you to enable or disable Enabled COM1 console redirection...

  • Page 124: Network Stack Configuration

    VCO-6100 Series Chapter 4: BIOS Setup 4.3.10 Network Stack Configuration Item Options Description Network Stack Disabled[Default] , Enable/Disable UEFI Network Stack. Enabled...

  • Page 125: Csm Configuration

    VCO-6100 Series Chapter 4: BIOS Setup 4.3.11 CSM Configuration Item Options Description CSM Support Disabled, This item allows users to enable or disable Enabled[Default] for “CSM Support”. GateA20 Active Upon Request[Default] , This item allows users to set Upon Request Always or Always for "GateA20 Active“.

  • Page 126: Usb Configuration

    VCO-6100 Series Chapter 4: BIOS Setup 4.3.12 USB Configuration Item Options Description Legacy USB Support Enabled[Default] Enables Legacy USB support. AUTO option Disabled disables legacy support if no USB devices Auto are connected. DISABLE option will keep USB devices available only for EFI applications.

  • Page 127: Chipset

    VCO-6100 Series Chapter 4: BIOS Setup 4.4 Chipset This section allows you to configure and improve your system and allows you to set up some system features according to your preference. 4.4.1 System Agent (SA) Configuration...
  • Page 128 VCO-6100 Series Chapter 4: BIOS Setup  Memory Configuration Item Options Description Max TOLUD Dynamic[Default], Maximum Value of TOLUD. Dynamic 1GB, assignment would adjust TOLUD 1.25GB, automatically based on largest MMIO 1.5 GB, length of installed graphic controller 1.75 GB, 2 GB, 2.25 GB,...
  • Page 129 VCO-6100 Series Chapter 4: BIOS Setup  Graphic Configuration Item Options Description Primary Display Auto[Default] , Select which of IGFX/PEG Graphics device PEG + IGFX should be Primary Display. PEG+IGFX(Multiple-Displays): IGFX will be primary and only display under BIOS and DOS mode.
  • Page 130 VCO-6100 Series Chapter 4: BIOS Setup  PEG Port Configuration Item Options Description Enable Root Port Enabled[Default] , Enable or Disable the Root Port Disabled Max Link Speed Auto[Default] , Configure PEG 0:X:X Max Speed Gen1, Gen3, Gen3, PEG0 Hotplug...

  • Page 131: Pch-Io Configuration

    VCO-6100 Series Chapter 4: BIOS Setup 4.4.2 PCH-IO Configuration Item Options Description PCH LAN Controller Enabled [Default] , Enable/Disable onboard NIC. Disabled Wake on LAN Enabled, Enable/Disable integrated LAN to wake the Enable Disabled [Default] system. Restore AC Power Power On, Specify what state to go to when power is ■...
  • Page 132 VCO-6100 Series Chapter 4: BIOS Setup  PCI Express Configuration...
  • Page 133 VCO-6100 Series Chapter 4: BIOS Setup  PCI Express Root Port 8 / 9 / 16 Item Options Description PCI Express Root Disabled [Default] , Control the PCI Express Root Port. Port Enabled 5 /10 /14/15/16/19/21 ASPM Disabled [Default] ,...
  • Page 134 VCO-6100 Series Chapter 4: BIOS Setup  USB Configuration Item Options Description XHCI Disable Disabled [Default] , Option to enable Compliance Mode. Compliance mode Enabled Default is to disable Compliance Mode. Change to enabled for Compliance Mode testing.
  • Page 135 VCO-6100 Series Chapter 4: BIOS Setup  HD Audio Configuration Item Options Description HD Audio Disabled, Control Detection of the HD-Audio device. Enabled [Default] Disabled = HDA will be unconditionally disabled Enabled = HDA will be unconditionally enabled.

  • Page 136: Security

    VCO-6100 Series Chapter 4: BIOS Setup 4.5 Security Security menu allow users to change administrator password and user password settings.  Administrator Password This item allows you to set Administrator Password.  User Password This item allows you to set User Password.
  • Page 137 VCO-6100 Series Chapter 4: BIOS Setup  Security Boot Item Options Description Secure Boot Disabled [Default] , Secure Boot feature is Active if Secure Boot Enabled is Enabled,Platform Key(PK) is enrolled and the System is in User mode. The mode change requires platform reset...
  • Page 138 VCO-6100 Series Chapter 4: BIOS Setup  Key Management Item Options Description Factory Key Provision Disabled [Default] , Install factory default Secure Boot keys Enabled after the platform reset and while the System is in Setup mode...

  • Page 139: Boot

    VCO-6100 Series Chapter 4: BIOS Setup 4.6 Boot This menu allows you to setup the system boot options. Item Options Description Setup Prompt 1[Default] Number of seconds to wait for setup Timeout activation key. 65535(0xFFFF) means indefinite waiting. Bootup NumLock On[Default] , Select the Keyboard NumLock state.

  • Page 140: Save & Exit

    VCO-6100 Series Chapter 4: BIOS Setup 4.7 Save & Exit This setting allows users to configure the boot settings.  Save Changes and Reset This item allows user to reset the system after saving the changes. This item allows user to reset the system after saving the changes.

  • Page 141: Appendix Wdt & Gpio

    Appendix WDT & GPIO This appendix provides the sample codes of WDT (Watch Dog Timer) and GPIO (General Purpose Input/ Output).

  • Page 142: Wdt Sample Code

    VCO-6100 Series Appendix – WDT & GPIO WDT Sample Code WDT Setting Psuedo Code #define AddrPort 0x2e #define DataPort 0x2f #define SIO_UnLock_Value 0x87 #define SIO_Lock_Value 0xaa #define WATCHDOG_LDN 0x07 #define GPIO_Port 0xF1 //Enter_Config WriteByte (AddrPort, SIO_UnLock_Value); WriteByte (AddrPort, SIO_UnLock_Value); //Enter WATCHDOG LDN WriteByte (AddrPort, 0x07);...

  • Page 143: Gpio Sample Code

    VCO-6100 Series Appendix – WDT & GPIO GPIO Sample Code GPIO Setting PIN# GPIO# Default Configuration XCOM- XCOM+ OUT8 DIO Output8 DIO Input8 OUT7 DIO Output7 DIO Input7 OUT6 DIO Output6 DIO Input6 OUT5 DIO Output5 DIO Input5 OUT4 DIO Output4...
  • Page 144 Copyright © Premio Inc. All Rights Reserved www.premioinc.com...

This manual is also suitable for:

Vco-6122eVco-6122pVco-6122cVco-6133eVco-6133pVco-6133c ... Show all

Table of Contents
