Page 1 USER’S MANUAL VCO-6000-CFL Series Superior Machine Vision System GPU Computing System...
Page 2 VCO-6000-CFL Series Please note, the VCO-6100 is now referred to as "VCO-6000-CFL" due to a model name change. All product features and functionality remain the same. If any questions, please contact us for more information. Name Change Guide: LEGACY Model Name...
Page 3: Table Of Contents
VCO-6000-CFL Series Table of Contents Prefaces ……………………………………………………………………………………………….. 04 Revision ………………………………………………………..……………………………..……………….……….. 04 Disclaimer ……………………………………………………….…….……………….………………….………….. Copyright Notice …………………………………….…….….………………………………….………………… 04 Trademarks Acknowledgment …………..………….………………………………………....Environmental Protection Announcement ……………………………………..……..……………….. Safety Precautions ……………………………………………………………………………………….….…….. Technical Support and Assistance ………………………………...……………………..…….…….……. Conventions Used in this Manual …………………………………..……………………..….……….. Package Contents ……………………………………………………………………..…..…………………….…...
Page 4 VCO-6000-CFL Series Chapter 3 System Setup …………………………..…………………………….…………… 73 Set torque force to 3.5 kgf-cm to execute all the screwing and unscrewing …………………………………………………………………………………………….. 74 Removing heat sink cover………………...………………………………………....74 Disconnecting expansion module from computing module......76 Removing chassis bottom cover……..………………………….….………………..77 Install HDD/SSD on the internal SATA bay……………..…….………………………..
Page 5: Prefaces
2021/7/12 Disclaimer All specifications and information in this User’s Manual are believed to be accurate and up to date. Premio Inc. does not guarantee that the contents herein are complete, true, accurate or non-misleading. The information in this document is subject to change without notice and does not represent a commitment on the part of Premio Inc.
Page 6: Safety Precautions
Preface VCO-6000-CFL Series Safety Precautions Before installing and using the equipment, please read the following precautions: ⚫ Put this equipment on a reliable surface during installation. Dropping it or letting it fall could cause damage. ⚫ The power outlet shall be installed near the equipment and shall be easily accessible.
Page 7: Technical Support And Assistance
Preface VCO-6000-CFL Series Technical Support and Assistance 1. Visit the Premio Inc website at premioinc.com where you can find the latest information about the product. 2. Contact your distributor, our technical support team or sales representative for technical support if you need additional assistance.
Page 8: Package Contents
Preface VCO-6000-CFL Series Package Contents Before installation, please ensure all the items listed in the following table are included in the package. Item Description Q’ty VCO-6100 Series Embedded System Utility DVD Driver Wall Mount Kit Accessory Kit DVI to VGA Adapter Ordering Information Model No.
Page 9: Optional Accessory
Preface VCO-6000-CFL Series Model No. Product Description GPU Computing System with LGA 1151 for Intel 8th/9th Gen CPU & Q370 VCO-6122C-2PWR PCH, 1x PCIe x16, 2x Power Input GPU Computing System with LGA 1151 for Intel 8th/9th Gen CPU & Q370...
Page 10: Chapter 1 Product Introductions
Chapter 1 Product Introductions...
Page 11: Overview
VCO-6122 VCO-6133 VCO-6144 VCO-6155 Premio GPU Computing System is your great solution for Machine Vision, Embedded System, Traffic Vision, Telemedicine, Intelligent Control, Deep Learning, Artificial Intelligence, Voice Reorganization and any graphics performance driven Industry 4.0/IIoT applications. VCO-6122C-2PWR VCO-6133E-2PWR...
Page 12: Hardware Specification
Chapter 1: Product Introductions VCO-6000-CFL Series 1.2 Hardware Specification System Intel® Q370 Express Chipset System Chipset Processor GbE1: Intel I219LM (Support Chipset Wake-on-LAN and PXE) - Support 8th/9th Gen Intel® CFL-R S Processor (LGA 1151, 65W/35W TDP) GbE2: Intel I210-AT (Support - Intel®...
Page 13 Chapter 1: Product Introductions VCO-6000-CFL Series Expansion Mini PCI Express 2x Full-size Mini PCIe (1x shared by 1x mSATA) 2x RS-232/422/485, 4x RS- 232/422/485 (internal) • VCO-6122E : 2x PCIe x16 (8-Lane) Model: • VCO-6122P : 2x PCl VCO-6122 4x USB 3.2 Gen 2 (10 Gbps), 4x USB •...
Page 14: System I/O
Chapter 1: Product Introductions VCO-6000-CFL Series 1.3 System I/O 1.3.1 VCO-6122 Front Panel DVI-I port ATX power on/off switch Used to connect a DVI monitor or connect Press to power-on or power-off the system optional split cable for dual display mode...
Page 15 Chapter 1: Product Introductions VCO-6000-CFL Series 1.3.1 VCO-6122 Rear Panel & Top View ATX power on/off switch 2x Universal I/O Bracket (By mini PCIe interface) Rear Panel Universal I/O Bracket Top View...
Page 16: Vco-6133
Chapter 1: Product Introductions VCO-6000-CFL Series 1.3.2 VCO-6133 Front Panel DVI-I port ATX power on/off switch Used to connect a DVI monitor or connect Press to power-on or power-off the system optional split cable for dual display mode DC IN...
Page 17 Chapter 1: Product Introductions VCO-6000-CFL Series 1.3.2 VCO-6133 Rear Panel & Top View ATX power on/off switch 2x Universal I/O Bracket (By mini PCIe interface) Rear Panel Universal I/O Bracket Top View...
Page 18: Vco-6144
Chapter 1: Product Introductions VCO-6000-CFL Series 1.3.3 VCO-6144 Front Panel DVI-I port ATX power on/off switch Used to connect a DVI monitor or connect Press to power-on or power-off the system optional split cable for dual display mode DC IN...
Page 19 Chapter 1: Product Introductions VCO-6000-CFL Series 1.3.3 VCO-6144 Rear Panel & Top View ATX power on/off switch 2x Universal I/O Bracket (By mini PCIe interface) Rear Panel Universal I/O Bracket Top View...
Page 20: Vco-6155
Chapter 1: Product Introductions VCO-6000-CFL Series 1.3.4 VCO-6155 Front Panel DVI-I port ATX power on/off switch Used to connect a DVI monitor or connect Press to power-on or power-off the system optional split cable for dual display mode DC IN...
Page 21 Chapter 1: Product Introductions VCO-6000-CFL Series 1.3.4 VCO-6155 Rear Panel & Top View ATX power on/off switch 2x Universal I/O Bracket (By mini PCIe interface) Rear Panel Universal I/O Bracket Top View...
Page 22: Vco-6122C-2Pwr
Chapter 1: Product Introductions VCO-6000-CFL Series 1.3.5 VCO-6122C-2PWR Front Panel DVI-I port ATX power on/off switch Used to connect a DVI monitor or connect Press to power-on or power-off the system optional split cable for dual display mode DC IN...
Page 23 Chapter 1: Product Introductions VCO-6000-CFL Series 1.3.5 VCO-6122C-2PWR Rear Panel & Top View ATX power on/off switch 2x Universal I/O Bracket (By mini PCIe interface) Rear Panel Universal I/O Bracket Top View...
Page 24: Vco-6133E-2Pwr
Chapter 1: Product Introductions VCO-6000-CFL Series 1.3.6 VCO-6133E-2PWR Front Panel DVI-I port ATX power on/off switch Used to connect a DVI monitor or connect Press to power-on or power-off the system optional split cable for dual display mode DC IN...
Page 25 Chapter 1: Product Introductions VCO-6000-CFL Series 1.3.6 VCO-6133E-2PWR Rear Panel & Top View ATX power on/off switch 2x Universal I/O Bracket (By mini PCIe interface) Rear Panel Universal I/O Bracket Top View...
Page 26: Vco-6120-2060S
Chapter 1: Product Introductions VCO-6000-CFL Series 1.3.7 VCO-6120-2060S Front Panel DVI-I port ATX power on/off switch Used to connect a DVI monitor or connect Press to power-on or power-off the system optional split cable for dual display mode DC IN...
Page 27 Chapter 1: Product Introductions VCO-6000-CFL Series 1.3.7 VCO-6120-2060S Rear Panel & Top View ATX power on/off switch 2x Universal I/O Bracket (By mini PCIe interface) Rear Panel Universal I/O Bracket Top View...
Page 28: Mechanical Dimension
Chapter 1: Product Introductions VCO-6000-CFL Series 1.4 Mechanical Dimensions 1.4.1 VCO-6122 Unit: mm...
Page 29: Vco-6133
Chapter 1: Product Introductions VCO-6000-CFL Series 1.4.2 VCO-6133 Unit: mm...
Page 30: Vco-6144
Chapter 1: Product Introductions VCO-6000-CFL Series 1.4.3 VCO-6144 Unit: mm...
Page 31: Vco-6155
Chapter 1: Product Introductions VCO-6000-CFL Series 1.4.4 VCO-6155 Unit: mm...
Page 32: Vco-6122C-2Pwr
Chapter 1: Product Introductions VCO-6000-CFL Series 1.4.5 VCO-6122C-2PWR Unit: mm...
Page 33: Vco-6133E-2Pwr
Chapter 1: Product Introductions VCO-6000-CFL Series 1.4.6 VCO-6133E-2PWR Unit: mm...
Page 34: Vco-6120-2060S
Chapter 1: Product Introductions VCO-6000-CFL Series 1.4.7 VCO-6120-2060S Unit: mm...
Page 35: Chapter 2 Switches And Connectors
Chapter 2 Switches and Connectors...
Page 36: Switch And Connector Locations
Chapter 2: Switches and Connectors VCO-6000-CFL Series 2.1 Switch and Connector Locations 2.1.1 Top View...
Page 37: Bottom View
Chapter 2: Switches and Connectors VCO-6000-CFL Series 2.1.2 Bottom View...
Page 38: Connector / Switch Definition
Chapter 2: Switches and Connectors VCO-6000-CFL Series 2.2 Connector / Switch Definition List of Connector / Switch Connector Location Definition AT_ATX1 AT / ATX Power Mode Switch PWR_SW1 Power Switch RESET1 Reset Switch USB 3.2 Gen 2 、 USB 3.2 Gen 1 、 USB2.0...
Page 39: I/O Interface Descriptions
Chapter 2: Switches and Connectors VCO-6000-CFL Series 2.3 I/O Interface Descriptions 2.3.1 LPC Debug Con Signal Signal +3.3V LPC_AD3 LPC_AD2 Reset LPC_AD1 LPC_FRAME-L LPC_AD0 Clock...
Page 40: Power Con
Chapter 2: Switches and Connectors VCO-6000-CFL Series 2.3 I/O Interface Descriptions 2.3.2 Power Con POWER1 Signal +12V...
Page 41: Dc In/Ign In (+9V ~ +48V)
Chapter 2: Switches and Connectors VCO-6000-CFL Series 2.3 I/O Interface Descriptions 2.3.3 DC IN/IGN IN (+9V ~ +48V) DC_IN1 Signal +DC_IN IGN_SENSE...
Page 42: Com Con
Chapter 2: Switches and Connectors VCO-6000-CFL Series 2.3 I/O Interface Descriptions 2.3.4 COM Con 10 9 COM5_1 , COM6_1 Signal Signal DCD# DSR# RTS# CTS# DTR# RS232 / RS422 / RS485 Connector 2x5 10-pin box header, 2.0mm pitch RS232 Definition...
Page 43 Chapter 2: Switches and Connectors VCO-6000-CFL Series 2.3 I/O Interface Descriptions COM1_2 , COM3_4 RS232 / RS422 / RS485 Connector Type: 9-pin D-Sub RS422 / 485 Full Duplex RS232 Definition RS485 Half Duplex Definition Definition 1(10) DCD# DATA- 2(11) DATA+...
Page 44: Sf100 Spi Con
Chapter 2: Switches and Connectors VCO-6000-CFL Series 2.3 I/O Interface Descriptions 2.3.5 SF100 SPI Con Signal Signal Power ( 3V ) MISO MOSI SPI_GATE#...
Page 45 Chapter 2: Switches and Connectors VCO-6000-CFL Series 2.3 I/O Interface Descriptions AT_ATX1 CAR_PWR1 CAR_PWR1 AT_ATX1 AT_ATX1: AT / ATX Power Mode Switch Switch Definition 1-2 (Left) ATX Power Mode (Default) 2-3 (Right) AT Power Mode CAR_PWR1: PC / Car Mode Switch...
Page 46 Chapter 2: Switches and Connectors VCO-6000-CFL Series 2.3 I/O Interface Descriptions 1 2 3 DELAY_TIME1 Power off delay time setup Switch Switch 1 / 2 / 3 Definition ON / ON / ON 3 sec.（Default Shutdown Timer by O.S） ON / ON / OFF 1 min.
Page 47 Chapter 2: Switches and Connectors VCO-6000-CFL Series 2.3 I/O Interface Descriptions LINE_OUT1 MIC_IN1 LINE_OUT1 : MIC_IN1 : Line-out Jack (Green) Connector Type: 5- Microphone Jack (Pink) Connector Type: pin Phone Jack 5-pin Phone Jack Definition Definition OUT_R MIC_R OUT_L MIC_L...
Page 48 Chapter 2: Switches and Connectors VCO-6000-CFL Series 2.3 I/O Interface Descriptions CLR_CMOS1: Clear BIOS Switch Switch Definition 1-2 (Left) Normal Status (Default) 2-3 (Right) Clear BIOS PWR_SW1: Power Button Definition Definition Power Button...
Page 49 Chapter 2: Switches and Connectors VCO-6000-CFL Series 2.3 I/O Interface Descriptions RESET1 : Reset Button Definition RESET USB3_1 : USB3.1 Connector, Type A Definition Definition USB3_RX+ USB2_D- USB2_D+ USB3_TX- USB3_TX+ USB3_RX-...
Page 50 Chapter 2: Switches and Connectors VCO-6000-CFL Series 2.3 I/O Interface Descriptions CN7 : USB3.0 Connector 2x5 9-pin header, 2.0mm pitch Definition Definition USB3_TX- USB2_D- USB3_TX+ USB2_D+ USB3_RX- USB3_RX+...
Page 51 Chapter 2: Switches and Connectors VCO-6000-CFL Series 2.3 I/O Interface Descriptions CN6 : USB3.1 Connector, Type A x 4 Definition Definition USB3_RX+ USB2_D- USB2_D+ USB3_TX- USB3_TX+ USB3_RX-...
Page 52 Chapter 2: Switches and Connectors VCO-6000-CFL Series 2.3 I/O Interface Descriptions SIM1 : Top side SIM Card Socket SIM2 : Bottom side SIM Card Socket SIM1 SIM2 Definition Definition UIM_PWR UIM_VPP UIM_RESET UIM_DATA UIM_CLK...
Page 53 Chapter 2: Switches and Connectors VCO-6000-CFL Series 2.3 I/O Interface Descriptions DVI_I1: DVI-I Connector Definition Definition DVI_TX2- DVI Hot Plug Detect DVI_TX2+ DVI_TX0- DVI_TX0+ VGA_DDC_CLOCK DVI_DDC_CLOCK VGA_DDC_DATA DVI_DDC_DATA VGA VSYNC DVI_TXCLK+ DVI_TX1- DVI_TXCLK- DVI_TX1+ VGA_RED VGA_GREEN VGA_BLUE VGA_HSYNC...
Page 54 Chapter 2: Switches and Connectors VCO-6000-CFL Series 2.3 I/O Interface Descriptions DP1 DP2 : Display Port Connector Definition Definition DP_LANE0_P DP_LANE3_N DP_LANE0_N DP_LANE1_P DP_AUX_P DP_LANE1_N DP_LANE2_P DP_AUX_N DP_HPD DP_LANE2_N DP_LANE3_P +3.3V...
Page 55 Chapter 2: Switches and Connectors VCO-6000-CFL Series 2.3 I/O Interface Descriptions DIO : Digital Input / Output Connector Type: Terminal Block 2x9 18-pin, 3.5mm pitch Definition Definition DIN1 DOUT1 DIN2 DOUT2 DIN3 DOUT3 DIN4 DOUT4 DIN5 DOUT5 DIN6 DOUT6 DIN7...
Page 56 Chapter 2: Switches and Connectors VCO-6000-CFL Series 2.3 I/O Interface Descriptions Digital Input Wurung Digital Output Wurung...
Page 57 Chapter 2: Switches and Connectors VCO-6000-CFL Series 2.3 I/O Interface Descriptions PWR_SW2 : Remote Power Switch Type: Terminal Block 1x2 2-pin, 3.5mm pitch Definition Power Button...
Page 58 Chapter 2: Switches and Connectors VCO-6000-CFL Series 2.3 I/O Interface Descriptions PWR_SW3 : Remote Power Switch 1x4 pin box header, 2.0mm pitch Definition Power Button PWR_LED HDD_LED...
Page 59 Chapter 2: Switches and Connectors VCO-6000-CFL Series 2.3 I/O Interface Descriptions CN3 CN4 : LAN and USB3.1 GEN 2 Ports Connector Type:RJ45 port with LEDs and dual USB3.1 ports Definition Definition Definition LAN1_MDI0P USB2_D1- USB2_D2- LAN1_MDI0N USB2_D1+ USB2_D2+ LAN1_MDI1P LAN1_MDI2P...
Page 60 Chapter 2: Switches and Connectors VCO-6000-CFL Series 2.3 I/O Interface Descriptions Act LED Status Definition Blinking Yellow Data Activity No Activity Link LED Status Definition Steady Orange 1Gbps Network Link Steady Green 100Mbps Network Link 10Mbps Network Link PWR_LED1: Power LED Status...
Page 61 Chapter 2: Switches and Connectors VCO-6000-CFL Series 2.3 I/O Interface Descriptions MINIPCIE2 : Mini PCI-Express Socket Definition Definition WAKE# +3.3V +1.5V CLKREQ# UIM_PWR UIM_DATA REFCLK- UIM_CLK REFCLK+ UIM_RST UIM_VPP RESET# +3.3VAUX +1.5V SMB_CLK SMB_DATA USB2_D- USB2_D+ +3.3V +3.3V +1.5V +3.3V...
Page 62 Chapter 2: Switches and Connectors VCO-6000-CFL Series 2.3 I/O Interface Descriptions MINIPCIE1 : Mini PCI-Express / mSATA Socket Definition Definition WAKE# +3.3V +1.5V CLKREQ# UIM_PWR UIM_DATA REFCLK- UIM_CLK REFCLK+ UIM_RST UIM_VPP RESET# +3.3VAUX +1.5V SMB_CLK SMB_DATA USB2_D- USB2_D+ +3.3V +3.3V DEVSLP +1.5V...
Page 63 Chapter 2: Switches and Connectors VCO-6000-CFL Series 2.3 I/O Interface Descriptions SATA with Power Connector Definition Definition +12V DEVSLP +12V +12V...
Page 64 Chapter 2: Switches and Connectors VCO-6000-CFL Series 2.3 I/O Interface Descriptions PCIE : PCI-Express x1 Slot Definition Definition +12V FAN_P4 +12V +12V +12V +12V SMB_CLK SMB_DATA +3.3V +3.3V +3.3VAUX +3.3V WAKE# RESET# FAN_P3 REFCLK+ TxP0 REFCLK- TxN0 RxP0 FAN_PER RxN0...
Page 65 Chapter 2: Switches and Connectors VCO-6000-CFL Series 2.3 I/O Interface Descriptions PCIE : PCI-Express x8 Slot Definition Definition +12V +12V +12V +12V +12V SMB_CLK SMB_DATA +3.3V +3.3V +3.3VAUX +3.3V WAKE# RESET# REFCLK+ TxP0 REFCLK- TxN0 RxP0 RxN0...
Page 66 Chapter 2: Switches and Connectors VCO-6000-CFL Series 2.3 I/O Interface Descriptions PCIE : PCI-Express x8 Slot Definition Definition TxP1 TxN1 RxP1 RxN1 TxP2 TxN2 RxP2 RxN2 TxP3 TxN3 RxP3 RxN3 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN...
Page 67 Chapter 2: Switches and Connectors VCO-6000-CFL Series 2.3 I/O Interface Descriptions PCIE : PCI-Express x16 Slot Definition Definition +12V FAN_P4 +12V +12V +12V +12V SMB_CLK SMB_DATA +3.3V +3.3V +3.3VAUX +3.3V WAKE# RESET# FAN_P3 REFCLK+ TxP0 REFCLK- TxN0 RxP0 FAN_PWR RxN0...
Page 68 Chapter 2: Switches and Connectors VCO-6000-CFL Series 2.3 I/O Interface Descriptions PCIE : PCI-Express x16 Slot Definition Definition TxP1 TxN1 RxP1 RxN1 TxP2 TxN2 RxP2 RxN2 TxP3 TxN3 RxP3 RxN3 CFG_5 TxP4 CFG_6 TxN4 RxP4 RxN4 TxP5 TxN5 RxP5 RxN5...
Page 69 Chapter 2: Switches and Connectors VCO-6000-CFL Series 2.3 I/O Interface Descriptions PCIE : PCI-Express x16 Slot Definition Definition TxN8 RxP8 RxN8 TxP9 TxN9 RxP9 RxN9 TxP10 TxN10 RxP10 RxN10 TxP11 TxN11 RxP11 RxN11 TxP12 TxN12 RxP12 RxN12 TxP13 TxN13 RxP13...
Page 70 Chapter 2: Switches and Connectors VCO-6000-CFL Series 2.3 I/O Interface Descriptions CN1 : M.2 E Key Socket Definition Definition +3.3VAUX USB2_D+ +3.3VAUX USB2_D- LED1# LED2# TxP0 TxN0 RxP0 RxN0...
Page 71 Chapter 2: Switches and Connectors VCO-6000-CFL Series 2.3 I/O Interface Descriptions CN1 : M.2 E Key Socket Definition Definition REFCLK0+ REFCLK0- SUSCLK PERST0# WAKE0# TxP1 TxN1 Pull Low RxP1 PERST1# RxN1 WAKE1# REFCLK1+ +3.3VAUX REFCLK1- +3.3VAUX...
Page 72 Chapter 2: Switches and Connectors VCO-6000-CFL Series 2.3 I/O Interface Descriptions CN2 : M.2 M Key Socket Definition Definition +3.3V +3.3V RxN3 RxP3 LED# TxN3 +3.3V TxP3 +3.3V +3.3V RxN2 +3.3V RxP2 TxN2 TxP2 RxN1 RxP1 TxN1...
Page 73 Chapter 2: Switches and Connectors VCO-6000-CFL Series 2.3 I/O Interface Descriptions CN2 : M.2 M Key Socket Definition Definition TxP1 Pull Low RxN0/SATA_B+ RxP0/SATA_B- TxN0 TxP0 PERST# Pull Hi REFCLK- WAKE# REFCLK+ SUSCLK PEDET +3.3V +3.3V +3.3V...
Page 74: Chapter 3 System Setup
Chapter 3 System Setup...
Page 75: Set Torque Force To 3.5 Kgf-Cm To Execute All The Screwing And Unscrewing
Chapter 3: System Setup VCO-6000-CFL Series 3.1 Set torque force to 3.5 kgf-cm to execute all the screwing and unscrewing. 3.2 Removing heat sink cover In order to prevent electric shock or system damage, before removing the chassis cover, must turn off power and disconnect the unit from power source.
Page 76 Chapter 3: System Setup VCO-6000-CFL Series 2. Unscrew the 4 screws on the bottom side. 3. Now you can remove the heat sink cover.
Page 77: Disconnecting Expansion Module From Computing Module
Chapter 3: System Setup VCO-6000-CFL Series Disconnecting expansion module from computing module 1. Remove the 3 connecting brackets on the top side of the system and the 3 brackets on the bottom side. 2. Now you can separate the expansion module from the computing module.
Page 78: Removing Chassis Bottom Cover
Chapter 3: System Setup VCO-6000-CFL Series 3.4 Removing chassis bottom cover 1. Unscrew the 6 screws highlighted below. 2. Unscrew 4 screws on the front side. 3. Hold the body of the system and lift it vertically away.
Page 79: Install Hdd/Ssd On The Internal Sata Bay
Chapter 3: System Setup VCO-6000-CFL Series 3.5 Install HDD/SSD on the internal SATA bay 1. Two internal SATA HDD/SSD bays are available for VCO-6100 series. 2. Unscrew the 4 screws (M3x5L) to remove the internal SATA HDD/SSD bay. 3. Lock the 2.5” HDD with HDD/SSD bracket using four screws (M3x4L).
Page 80 Chapter 3: System Setup VCO-6000-CFL Series 4. Install the HDD/SSD bracket following the direction below. 5. Fasten the 4 screws to lock the internal HDD/SSD bracket.
Page 81: Installing Hdd On Removable Sata Hdd Bay
Chapter 3: System Setup VCO-6000-CFL Series 3.6 Installing HDD on removable SATA HDD bay Two removable SATA HDD bays are available for VCO-6100 Series. 1. Unscrew the two sun screws circled below to take out the removable SATA HDD bay.
Page 82 Chapter 3: System Setup VCO-6000-CFL Series 3. Slide the HDD bracket back and then fasten the sun screws. 4. Installation complete...
Page 83: Installing Sodimm
Chapter 3: System Setup VCO-6000-CFL Series 3.7 Installing SODIMM 1. Place the system body with SODIMM socket facing upward. Two SODIMM sockets are available for VCO-6100 series on the top side. 2. Insert memory module from 45 degree direction. 3. Press the memory module vertically downward until you hear the “click” sound.
Page 84: Installing Cpu
Chapter 3: System Setup VCO-6000-CFL Series 3.8 Installing CPU 1. Press down the CPU socket lever in order to open the socket cover. 2. Remove the CPU protective cover.
Page 85 Chapter 3: System Setup VCO-6000-CFL Series 3. Insert CPU gently. 4. Press down the lever again to hold the socket cover.
Page 86 Chapter 3: System Setup VCO-6000-CFL Series 5. Paste thermal pad on the CPU. 6. Place the designated heat block onto the CPU with thermal pad.
Page 87 Chapter 3: System Setup VCO-6000-CFL Series 7. Lock the heat block with three screws (M3x5L). Screw driver will able to penetrate through the holes on the top in order to fasten the screws with copper stud. 8. Paste the thermal pad onto the installed heat block.
Page 88 Chapter 3: System Setup VCO-6000-CFL Series 9. Paste the thermal pad onto the installed heat block.
Page 89: Installing Mini Pcie Card / Msata
Chapter 3: System Setup VCO-6000-CFL Series 3.9 Installing Mini PCIe card / mSATA The VCO-6100 series has two Mini PCIe slots, both of which are on the top. The MINI- PCIE1 supports mSATA. MINI-PCIE1 1. Insert Mini PCIe card from 45 degree direction.
Page 90: Installing M.2 2280 Nvme Ssd
Chapter 3: System Setup VCO-6000-CFL Series 3.10 Installing M.2 2280 NVMe SSD VCO-6100 series PCBA has an M.2 M key slot on the top, CN2 currently supports NVMe SSD applications 1. Insert M.2 M Key card from 45 degree direction.
Page 91: Installing Wifi Module
Chapter 3: System Setup VCO-6000-CFL Series 3.11 Installing WiFi Module VCO-6100 series PCBA has an M.2 E key slot on the top, CN1 currently supports WiFi application 1. Insert M.2 E Key card from 45 degree direction. 2. Press the M.2 E Key card down and lock it with one screw (M2x3.7L).
Page 92 Chapter 3: System Setup VCO-6000-CFL Series 3. VCO-6100 series system has 4 antenna holes, remove antenna hole plug on the system panel. 4. Have antenna jack penetrate through the hole, and fasten the nut with SMA jack.
Page 93 Chapter 3: System Setup VCO-6000-CFL Series 5. Assemble the antenna and SMA jack together. 6. Attach the RF connector at the cable-end onto the communication module.
Page 94: Installing Mini Pcie Card / 4Glte
Chapter 3: System Setup VCO-6000-CFL Series 3.12 Installing Mini PCIe card / 4GLTE VCO-6100 series PCBA has two Mini PCIe slots on the top, MINI-PCIE2 currently supports 4GLTE applications MINI-PCIE2 1. Insert Mini PCIe card from 45 degree direction. 2. Press the Mini PCIe card down and lock it with two screws (M2x3.7L).
Page 95: Installing Antenna
Chapter 3: System Setup VCO-6000-CFL Series 3.13 Installing Antenna 1. Remove antenna hole cover on the system panel. 2. Have antenna jack penetrate through the hole, and fasten the nut with SMA jack...
Page 96 Chapter 3: System Setup VCO-6000-CFL Series 3. Assemble the antenna and SMA jack together. 4. Attach the RF connector at the cable-end onto the communication module.
Page 97: Installing Graphic Card (For Superior Machine Vision System)
Chapter 3: System Setup VCO-6000-CFL Series 3.14 Installing graphic Card (For Superior Machine Vision System) 1. Remove the 3 screws in the circle below. 2. Push the chassis cover following the below direction to open the expansion module.
Page 98 Chapter 3: System Setup VCO-6000-CFL Series Remove the 3 screws in the circle below.
Page 99 Chapter 3: System Setup VCO-6000-CFL Series 4. Unscrew the 2 screws to remove the I/O shield. 5. Unscrew the card bracket screws to remove the bracket from the expansion slots.
Page 100 Chapter 3: System Setup VCO-6000-CFL Series 6. Install the graphic card and ensure the gold finger is inserted into the slot. and then fasten the screws 7. Adjust the arm until it holds the card firmly in place. Then fasten the screw on the...
Page 101 Chapter 3: System Setup VCO-6000-CFL Series 8. Fasten the 2 screws 9. Insert power cable from the power board to the graphic card.
Page 102: Installing Pcie/Pci Expansion Card
Chapter 3: System Setup VCO-6000-CFL Series 3.15 Installing PCIe/PCI expansion Card 1. Remove the screw in the circle below. 2. Install the PCIe/PCI extension card and ensure the gold finger is inserted into the slot. and then fasten the screw.
Page 103 Chapter 3: System Setup VCO-6000-CFL Series 3. Put the graphic expansion module into the expansion chassis. 4. Fasten the 3 screws in the circle below...
Page 104 Chapter 3: System Setup VCO-6000-CFL Series 5. Following the below direction to close the chassis cover. 6. Fasten the 3 screws in the circle below...
Page 105: Installing Wall Mount Kit
Chapter 3: System Setup Chapter 3: System Setup VCO-6000-CFL Series 3.16 Installing wall mount kit 1. Wall mount kit is available for VCO-6100 included in the standard package. 2. Lock the wall mount kit with 10 screws...
Page 106: Ac Adapter With 3P Terminal Block
Chapter 3: System Setup VCO-6000-CFL Series 3.17 AC Adapter with 3P terminal block 1. 3P Wiring Diagram of AC Adapter 2. DC power input 3P wiring diagram...
Page 107: Ac Adapter With 4P Terminal Block
Chapter 3: System Setup VCO-6000-CFL Series 3.18 AC Adapter with 4P terminal block * 12V requires 4-pin terminal block for card/storage expansion 1. AC adapter 4P wiring diagram 2. DC power input 4P wiring diagram...
Page 108: Chapter 4 Bios Setup
Chapter 4 BIOS Setup...
Page 109: Bios Introduction
Chapter 4: BIOS Setup VCO-6000-CFL Series 4.1 BIOS Introduction The BIOS provides an interface to modify the configuration. When the battery is removed, all the parameters will be reset. BIOS Setup Power on the embedded system and by pressing <Del> immediately allows you to enter the setup screens.
Page 110: Main Setup
Chapter 4: BIOS Setup VCO-6000-CFL Series 4.2 Main Setup Press <Del> to enter BIOS CMOS Setup Utility. The Main setup screen is showed as following when the setup utility is entered. System Date/Time is set up in the Main Menu.
Page 111: Advanced Setup
Chapter 4: BIOS Setup VCO-6000-CFL Series 4.3 Advanced Setup...
Page 112: Connectivity Configuration
Chapter 4: BIOS Setup VCO-6000-CFL Series 4.3.1 Connectivity Configuration Item Options Description CNVi Mode Disable Integrated, This option configures Connectivity. [Auto Auto Detection] means that if Discrete solution is Detection[Default] discovered it will be enabled by default. Otherwise Integrated solution (CNVi) will be enabled;...
Page 113: Cpu Configuration
Chapter 4: BIOS Setup VCO-6000-CFL Series 4.3.2 CPU Configuration Item Options Description Intel (VMX) Virtualization Disabled, When enabled, a VMM can utilize the Technology Enabled[Default] additional hardware capabilities provided by Virtualization Technology. Active Processor Cores All[Default] Number of cores to enable in each processor package.
Page 114: Pch-Fw Configuration
Chapter 4: BIOS Setup VCO-6000-CFL Series 4.3.3 PCH-FW Configuration Item Options Description AMT BIOS Features Disabled, When disabled AMT BIOS Features are no Enabled[Default] longer supported and user is no longer able to access MEBx Setup. Note:This option does not disable Manageability Features in FW.
Page 115: Sata And Rst Configuration
Chapter 4: BIOS Setup VCO-6000-CFL Series 4.3.4 SATA and RST Configuration Item Options Description SATA Controller(s) Disabled, Enable/Disable SATA Device. Enabled[Default] SATA Mode Selection AHCI[Default] , Determines how SATA controller(s) operate. Intel RST Premium With Intel Optane System Acceleration Use RST Legacy OROM Disabled[Default] , Use RST Legacy OROM when CSM is Enabled.
Page 116: Rst (Uefi Raid) Configuration
Chapter 4: BIOS Setup VCO-6000-CFL Series 4.3.5 RST (UEFI RAID) Configuration How to set the UEFI RAID: 1. When set to “Intel RST Premium With Intel Optane System Acceleration“, please save change reset system. 2. After reboot the system, please into BIOS utility and then will see “Intel (R) Rapid Storage...
Page 117 Chapter 4: BIOS Setup VCO-6000-CFL Series 3. Into Intel(R) Rapid Storage Technology, and start create RAID volume. 4. Start Create the RAID ■ Select Disk that you want to do the RAID ■ Select [x]; No-Select [ ]...
Page 118: Trusted Computing
Chapter 4: BIOS Setup VCO-6000-CFL Series 4.3.6 Trusted Computing Item Options Description Security Device Support Enabled, Enable/Disable BIOS support for security Disabled[Default] , device. O.S. will not show Security Device.TCG EFI protocol and INT1A interface will not be available. Pending operation None[Default] , Schedule an Operation for the Security Device.
Page 119: Acpi Settings
Chapter 4: BIOS Setup VCO-6000-CFL Series 4.3.7 ACPI Settings Item Options Description Enable Hibernation Disabled , Enables or Disables System ability to Enabled[Default], Hibernate (OS/S4 Sleep State). This option may not be effective with some operating systems. ACPI Sleep State...
Page 120: Super Io Configuration
Chapter 4: BIOS Setup VCO-6000-CFL Series 4.3.8 Super IO Configuration This setting allows you to select options for the Super IO Configuration, and change the value of the selected option. Item Description Serial Port 1 Configuration Set Parameters of Serial Port 1 (COMA).
Page 121 Chapter 4: BIOS Setup VCO-6000-CFL Series ◼ Serial Port 1 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the address IO=3F8h; IRQ=4; , & IRQ settings of the specified serial port.
Page 122 Chapter 4: BIOS Setup VCO-6000-CFL Series ◼ Serial Port 2 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the address IO=2F8h; IRQ=3; , & IRQ settings of the specified serial port.
Page 123 Chapter 4: BIOS Setup VCO-6000-CFL Series ◼ Serial Port 3 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the address IO=3E8h; IRQ=7; , & IRQ settings of the specified serial port.
Page 124 Chapter 4: BIOS Setup VCO-6000-CFL Series ◼ Serial Port 4 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the address IO=2E8h; IRQ=7; , & IRQ settings of the specified serial port.
Page 125 Chapter 4: BIOS Setup VCO-6000-CFL Series ◼ Serial Port 5 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the address IO=2F0h; IRQ=7; , & IRQ settings of the specified serial port.
Page 126 Chapter 4: BIOS Setup VCO-6000-CFL Series ◼ Serial Port 6 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the address IO=2E0h; IRQ=7; , & IRQ settings of the specified serial port.
Page 127: Hardware Monitor
Chapter 4: BIOS Setup VCO-6000-CFL Series 4.3.9 Hardware Monitor These items display the current status of all monitored hardware devices/ components such as voltages and temperatures. Item Options Description Smart Fan Function Disabled[Default], Enabled or Disable Smart Fan Enabled...
Page 128 Chapter 4: BIOS Setup VCO-6000-CFL Series ◼ Smart Fan Mode Configuration Item Options Description Expansion Fan Manual Mode, Smart Fan Mode Select SmartFan Control SMART FAN IV Mode[Default], Temperature 1~4 1~100 Auto fan speed control. SMART FAN IV Duty Cycle 1~4 20~100 Auto fan speed control.
Page 129: Serial Port Console Redirection
Chapter 4: BIOS Setup VCO-6000-CFL Series 4.3.10 Serial Port Console Redirection Item Options Description Console Redirection Disabled[Default], These items allows you to enable or disable Enabled COM1 console redirection...
Page 130: Network Stack Configuration
Chapter 4: BIOS Setup VCO-6000-CFL Series 4.3.11 Network Stack Configuration Item Options Description Network Stack Disabled[Default] , Enable/Disable UEFI Network Stack. Enabled...
Page 131: Csm Configuration
Chapter 4: BIOS Setup VCO-6000-CFL Series 4.3.12 CSM Configuration Item Options Description CSM Support Disabled, This item allows users to enable or disable Enabled[Default] for “CSM Support”. GateA20 Active Upon Request[Default] , This item allows users to set Upon Request Always or Always for "GateA20 Active“.
Page 132: Usb Configuration
Chapter 4: BIOS Setup VCO-6000-CFL Series 4.3.13 USB Configuration Item Options Description Legacy USB Support Enabled[Default] Enables Legacy USB support. AUTO option Disabled disables legacy support if no USB devices Auto are connected. DISABLE option will keep USB devices available only for EFI applications.
Page 133: Chipset
Chapter 4: BIOS Setup VCO-6000-CFL Series 4.4 Chipset This section allows you to configure and improve your system and allows you to set up some system features according to your preference. 4.4.1 System Agent (SA) Configuration...
Page 134 Chapter 4: BIOS Setup VCO-6000-CFL Series ◼ Memory Configuration Item Options Description Max TOLUD Dynamic[Default], Maximum Value of TOLUD. Dynamic 1GB, assignment would adjust TOLUD 1.25GB, automatically based on largest MMIO 1.5 GB, length of installed graphic controller 1.75 GB, 2 GB, 2.25 GB,...
Page 135 Chapter 4: BIOS Setup VCO-6000-CFL Series ◼ Graphic Configuration Item Options Description Primary Display Auto[Default] , Select which of IGFX/PEG Graphics device PEG + IGFX should be Primary Display. PEG+IGFX(Multiple-Displays): IGFX will be primary and only display under BIOS and DOS mode.
Page 136 Chapter 4: BIOS Setup VCO-6000-CFL Series ◼ PEG Port Configuration Item Options Description Enable Root Port Enabled[Default] , Enable or Disable the Root Port Disabled Max Link Speed Auto[Default] , Configure PEG 0:X:X Max Speed Gen1, Gen3, Gen3, PEG0 Hotplug...
Page 137: Pch-Io Configuration
Chapter 4: BIOS Setup VCO-6000-CFL Series 4.4.2 PCH-IO Configuration Item Options Description PCH LAN Controller Enabled [Default] , Enable/Disable onboard NIC. Disabled Wake on LAN Enabled, Enable/Disable integrated LAN to wake the Enable Disabled [Default] system. Restore AC Power Power On, Specify what state to go to when power is ■...
Page 138 Chapter 4: BIOS Setup VCO-6000-CFL Series ◼ PCI Express Configuration...
Page 139 Chapter 4: BIOS Setup VCO-6000-CFL Series ◼ PCI Express Root Port 8 / 9 / 16 Item Options Description PCI Express Root Disabled [Default] , Control the PCI Express Root Port. Port Enabled 5 /10 /14/15/16/19/21 ASPM Disabled [Default] ,...
Page 140 Chapter 4: BIOS Setup VCO-6000-CFL Series ◼ USB Configuration Item Options Description XHCI Disable Disabled [Default] , Option to enable Compliance Mode. Compliance mode Enabled Default is to disable Compliance Mode. Change to enabled for Compliance Mode testing.
Page 141 Chapter 4: BIOS Setup VCO-6000-CFL Series ◼ HD Audio Configuration Item Options Description HD Audio Disabled, Control Detection of the HD-Audio device. Enabled [Default] Disabled = HDA will be unconditionally disabled Enabled = HDA will be unconditionally enabled.
Page 142: Security
Chapter 4: BIOS Setup VCO-6000-CFL Series 4.5 Security Security menu allow users to change administrator password and user password settings. ◼ Administrator Password This item allows you to set Administrator Password. ◼ User Password This item allows you to set User Password.
Page 143 Chapter 4: BIOS Setup VCO-6000-CFL Series ◼ Security Boot Item Options Description Secure Boot Disabled [Default] , Secure Boot feature is Active if Secure Boot Enabled is Enabled,Platform Key(PK) is enrolled and the System is in User mode. The mode change requires platform reset...
Page 144 Chapter 4: BIOS Setup VCO-6000-CFL Series ◼ Key Management Item Options Description Factory Key Provision Disabled [Default] , Install factory default Secure Boot keys Enabled after the platform reset and while the System is in Setup mode...
Page 145: Boot
Chapter 4: BIOS Setup VCO-6000-CFL Series 4.6 Boot This menu allows you to setup the system boot options. Item Options Description Setup Prompt 1[Default] Number of seconds to wait for setup Timeout activation key. 65535(0xFFFF) means indefinite waiting. Bootup NumLock On[Default] , Select the Keyboard NumLock state.
Page 146: Save & Exit
Chapter 4: BIOS Setup VCO-6000-CFL Series 4.7 Save & Exit This setting allows users to configure the boot settings. ◼ Save Changes and Reset This item allows user to reset the system after saving the changes. This item allows user to reset the system after saving the changes.
Page 147: Appendix Wdt & Gpio
Appendix WDT & GPIO This appendix provides the sample codes of WDT (Watch Dog Timer) and GPIO (General Purpose Input/ Output).
Page 148: Wdt Sample Code
Appendix – WDT & GPIO VCO-6000-CFL Series WDT Sample Code WDT Setting Psuedo Code #define AddrPort 0x2e #define DataPort 0x2f #define SIO_UnLock_Value 0x87 #define SIO_Lock_Value 0xaa #define WATCHDOG_LDN 0x08 #define GPIO_Port 0xF1 //Enter_Config WriteByte (AddrPort, SIO_UnLock_Value); WriteByte (AddrPort, SIO_UnLock_Value); //Enter WATCHDOG LDN WriteByte (AddrPort, 0x07);...
Page 149: Gpio Sample Code
Appendix – WDT & GPIO VCO-6000-CFL Series GPIO Sample Code GPIO Setting PIN# GPIO# Default Configuration XCOM- XCOM+ OUT8 DIO Output8 DIO Input8 OUT7 DIO Output7 DIO Input7 OUT6 DIO Output6 DIO Input6 OUT5 DIO Output5 DIO Input5 OUT4 DIO Output4...

This manual is also suitable for:

Vco-6000-cflVco-6000-cfl-2 Vco-6000-cfl-3 Vco-6000-cfl-3-2pwr Vco-6000-cfl-4 Vco-6000-cfl-5 ... Show all

Premio VCO-6000-CFL Series User Manual

Prefaces

Chapter 1 Product Introductions

Chapter 2 Switches and Connectors

Chapter 3 System Setup

Chapter 4 BIOS Setup

Appendix Wdt & GPIO

Quick Links

Need help?

Questions and answers

Related Manuals for Premio VCO-6000-CFL Series

Summary of Contents for Premio VCO-6000-CFL Series

This manual is also suitable for:

Table of Contents
