Summary of Contents for DigitalZone T7HDR
-
Page 2: Table Of Contents
Contents UHD Stream Generator User’s Manual Summary PLAY PLAYLIST Menu How to Playback Files How to Change Resolution UPDATE UPDATE Menu How to Update Contents by USB SETTINGS SETTINGS Menu How to Update Firmware Manually Getting Started Important Safety Instructions Guide to Parts and Controls How to Use Top Buttons Remote... - Page 3 Contents UHD Stream Generator User’s Manual Features PLAY Loop Play with One File Loop Play with Multiple Files Changing PLAYLIST Order and Selecting File(s) Selecting File(s) Managing PLAYLIST Number Deleting File(s) and Checking File Information UPDATE Contents Update by USB Automatically See Update Progress Status Sub Folder Deleting File(s) From System...
-
Page 4: Playlist Menu How To Playback Files How To Change Resolution
Summary PLAY PLAYLIST Menu How to Playback Files How to Change Resolution UPDATE UPDATE Menu How to Update Contents by USB SETTINGS SETTINGS Menu How to Update Firmware Manually... -
Page 5: Play
PLAY PLAYLIST Menu Press [LIST] button. PLAYLIST Playlist 9 Default Playlist 1 Number Digital-01.m2ts Image Preview Digital-02.m2ts Digital-03.m2ts Digital-04.m2ts Contents List Digital-05.m2ts Date 2015-01-24 Digital-06.m2ts Size 496MB Current Selected Video AVC/4K29.97p Digital-07.m2ts File Information Audio AC-3/2Ch Digital-08.m2ts Bitrate 80Mbps Digital-09.m2ts Digital-10.m2ts Current Video Resolution... -
Page 6: How To Playback Files
How to Playback Files PLAY Digital-01.m2ts Press [LIST] button. Digital-02.m2ts Digital-03.m2ts Digital-04.m2ts Playlist window Digital-01.m2ts Use [ ]buttons to move to Digital-02.m2ts desired file. Digital-03.m2ts Digital-04.m2ts Select a file Press [ENTER] after moving the cursor to the desired file. Playback the selected file... -
Page 7: How To Change Resolution
How to Change Resolution PLAY RESOLUTION 2160p60 MENU 2160p50 2160p30 CURRENT 2160p25 2160p60 2160p24 Press [RESOLUTION] to open Resolution menu while Playing back files or in PLAYLIST menu. Select desired sub-resolution with [ ] direction buttons. Press [ENTER] button to set the output resolution. -
Page 8: Update Menu
UPDATE UPDATE Menu Press [UPDATE] button. UPDATE Default Playlist 9 Playlist 1 NETWORK SYSTEM Digital-01.m2ts Digital-01.m2ts Digital-02.m2ts Digital-02.m2ts Digital-03.m2ts Digital-03.m2ts Digital-04.m2ts Digital-04.m2ts Digital-05.m2ts Digital-05.m2ts Digital-06.m2ts Digital-06.m2ts Digital-07.m2ts Digital-07.m2ts Digital-08.m2ts Digital-08.m2ts Digital-09.m2ts Digital-09.m2ts System Free Size Digital-10.m2ts Digital-10.m2ts 34 GB (88%) Page : 1 / 5 Page : 1 / 5 Help... - Page 9 UPDATE How to Update Contents by USB File(s) stored in USB Storage Device can be updated to UHD Stream Generator. Select Playlist Select USB Updating Check Select files number from media files Updated files How to Select PLAYLIST Number UPDATE Default Playlist 9 Playlist 1...
- Page 10 UPDATE How to Update Contents by USB How to Select Designated Files Select files one by one ※ Move the cursor using [ ] direction button. And then press [CHECK] button to select files. Select all files ※ Press [Number 1] button to select all files in the selected folder.
-
Page 11: Settings Menu
SETTINGS SETTINGS Menu Press [SETUP] button and use ]direction button to select sub-menu. SETTINGS NETWORK VIDEO SYSTEM UPDATE SHARE Interface Interface Wired Select type of network Configure Auto(DHCP) connection IP Address 192.168.XX.XX Subnet Mask 255.255.XX.XX DNS Server 211.63.XX.XX Gateway 192.168.XX.XX VIDEO NETWORK SETTINGS... -
Page 12: How To Update Firmware Manually
SETTINGS How to Update Firmware Manually Press [STOP] to stop playing files and then plug USB into UHD Stream Generator. UPDATE VIDEO SYSTEM SHARE NETWORK Press [SETUP] button to open settings menu New Version None and then move to ‘UPDATE’ menu using [ Software Version 1.XX direction button. -
Page 13: Getting Started
Getting Started Important Safety Instructions Guide to Parts and Controls How to Use Top Buttons Remote Package and Accessories / Cautions Connecting Cable... -
Page 14: Important Safety Instructions
Read these operating instructions carefully before using the product. Follow the safety instructions on the unit and the safety precautions listed in the manual. Keep this manual handy for future reference. * DIGITALZONE Logo is registered trade mark of DIGITALZONE Co., Ltd. -
Page 15: Guide To Parts And Controls
Guide to Parts and controls POWER MENU VIDEO PLAY/PAUSE ENTER DIRECTION Buttons 2 3 4 FRONT LEDs : Status Indicators 1 x USB REAR Adapter Power Input IR Extension Receiver Input DEBUG HDMI Output 1 x USB Kensington Lock... -
Page 16: How To Use Top Buttons
How to Use Top Buttons Top buttons have the ※ same functions as Remote. How to Open PLAYLIST Menu Press [MENU] Select PLAYLIST menu button using [ , ] button and press [ENTER] button How to Open UPDATE Menu Select UPDATE menu Press [MENU] using [ , ] button and button... -
Page 17: Remote
Remote Remote Buttons POWER Change Playing Order in PLAYLIST Menu Open RESOLUTION Menu (Available only when playing or in play list menu. ) Direction buttons Open PLAYLIST Menu Play & Pause Trick Mode Select or Deselect All Files (Applying Only for PLAYLIST & UPDATE Menu) Activate or Deactivate Files Delete file(s) in PLAYLIST and UPDATE Menu Open SETTINGS Menu... -
Page 18: Package And Accessories / Cautions
(Grade A), which acquired EMC (Electromagnetic Compatibility), and it is intended to be used in areas, except for a domestic purpose. - Digitalzone will not be responsible for any problems adapter cautions. Cautions 1. DO NOT pull plug out of outlet while the device is running. -
Page 19: Connecting Cable
“1” has the top priority and then the HDMI port which is connected in advance or adjacent from the number “1” port has the priority. - Use High speed HDMI cable or HDMI cable offered by Digitalzone. (Possible to use HDMI certified cable up to 10M. It is possible to have some problems longer than.) - Page 20 Features PLAY Loop Play with One File Loop Play with Multiple Files Changing PLAYLIST Order and Selecting File(s) Selecting File(s) Managing PLAYLIST Number Deleting File(s) and Checking File Information UPDATE Contents Update by USB Automatically See Update Progress Status Sub Folder Deleting File(s) From System SETTINGS VIDEO...
-
Page 21: Play
PLAY Loop Play with One File When playing only “Digital-01.m2ts” Digital-01.m2ts Press [LIST] button. Digital-02.m2ts (Startup status) Digital-03.m2ts Digital-04.m2ts Move cursor using [ ] direction button Digital-01.m2ts Digital-02.m2ts to “Digital-02.m2ts”. Digital-03.m2ts (Cursor moved into “Digital-02.m2ts”) Digital-04.m2ts Digital-01.m2ts Press Number [2] button to uncheck files. Digital-02.m2ts (Now “Digital-02.m2ts, Digital-03.m2ts, Digital-03.m2ts... -
Page 22: Loop Play With Multiple Files
PLAY Loop Play with Multiple Files When playing “Digital-01.m2ts”, “Digital-02.m2ts”, “Digital-03.m2ts” Digital-01.m2ts Press [LIST] button. Digital-02.m2ts (Startup status) Digital-03.m2ts Digital-04.m2ts Move cursor using [ ] direction button Digital-01.m2ts Digital-02.m2ts to “Digital-02.m2ts”. Digital-03.m2ts (Cursor moved into “Digital-02.m2ts”) Digital-04.m2ts Digital-01.m2ts Press Number [2] button the selected to Digital-02.m2ts check file. -
Page 23: Changing Playlist Order And Selecting File(S)
PLAY Changing PLAYLIST Order and Selecting File(s) Changing PLAYLIST Order and Selecting File(s) Digital-01.m2ts Digital-02.m2ts Press [LIST] button. Digital-03.m2ts Digital-04.m2ts Digital-02.m2ts Move selected file down using Digital-01.m2ts [MOVE DOWN] button. Digital-03.m2ts Digital-04.m2ts Digital-01.m2ts Move selected file up using Digital-02.m2ts [MOVE UP] button. Digital-03.m2ts Digital-04.m2ts Direct Play by Number Button... -
Page 24: Selecting File(S)
PLAY Selecting File(s) [1] Select All Multi-Select Possible to select multiple files to move. ※ Digital-01.m2ts Press [CHECK] button for selecting files. Digital-02.m2ts Digital-03.m2ts Digital-04.m2ts Press [MOVE Down] button. Digital-05.m2ts The selected files will move down. Digital-06.m2ts Digital-07.m2ts Digital-08.m2ts Press [MOVE UP] button. Digital-09.m2ts The selected files will move up. -
Page 25: Managing Playlist Number
PLAY Managing PLAYLIST Number You can utilize multi “PLAYLIST” and also orders for each “PLAYLIST” ※ Playlist 9EA Default 1EA PLAYLIST Playlist 9 Default Playlist 1 Number Digital-01.m2ts Digital-02.m2ts Digital-03.m2ts Digital-04.m2ts Digital-05.m2ts Date 2015-01-24 Digital-06.m2ts Size 496MB Video HEVC Digital-07.m2ts 2160P60 Digital-08.m2ts Audio... -
Page 26: Deleting File(S) And Checking File Information
PLAY Deleting File(s) and Checking File Information ENTER How to Delete Files from the PLAYLIST Digital-01.m2ts Digital-02.m2ts Press [LIST] button. Digital-03.m2ts Digital-04.m2ts Digital-01.m2ts Move to the desired file which you want Digital-02.m2ts to delete using [ ] button. Digital-03.m2ts Digital-04.m2ts Digital-01.m2ts Press [DELETE] button. -
Page 27: Update
UPDATE Contents Update by USB Automatically CONFIRMATION Pop-up menu will be appeared on the screen if USB device is connected during ※ playing files. Select ALL button to update contents automatically. Playing state. (USB is not connected) Connect USB device. Insert USB device which contains contents in the root folder CONFIRMATION... -
Page 28: See Update Progress Status
UPDATE See Update Progress Status In Playing State → To check update status while playing Press [ENTER] In Playing State → To check update status Only Press [UPDATE] In contents updating state → To go back to the playing files status Press [PLAY/PAUSE] 1. -
Page 29: Sub Folder
UPDATE Sub Folder You can update files from USB device’s sub folder ※ Press [UPDATE] button. Digital-01 Digital-02 Digital-01.m2ts Select USB media using [ ] button. Digital-02.m2ts Digital-03.m2ts Select folder or file using [ ] button. Digital-01 Digital-02 Digital-01.m2ts Digital-02.m2ts Digital-03.m2ts Folder Icon Press [ENTER] button and move to sub... -
Page 30: Deleting File(S) From System
UPDATE Deleting File(s) From System File(s) can be permanently removed from SYSTEM (HDD). ※ NETWORK SYSTEM Digital-01.m2ts Press [UPDATE] button. Digital-02.m2ts Digital-03.m2ts Digital-04.m2ts Move to desired file using [ ]button. NETWORK SYSTEM Digital-01.m2ts Digital-02.m2ts Digital-03.m2ts Press [DELETE] button. Digital-04.m2ts NETWORK SYSTEM Digital-01.m2ts Select ‘OK’... -
Page 31: Settings
SETTINGS VIDEO VIDEO menu in SETTINGS. (Do not change HDMI cables while setting up) ※ SETTINGS VIDEO S HAR E NETWOR K SYSTE M UPDAT E EDID Limit EDID Limit UHD Stream Generator gathers Refresh Rate Native information and describe TV capabilities. -
Page 32: Settings Video
SETTINGS Settings VIDEO EDID Limit EDID Limit : ON Refresh Rate Status Output most suitable resolution after reading TV EDID and File information. Native (Refresh Rate and Resolution is automatically changed) Output most suitable resolution after reading TV EDID and File information Auto (Only Refresh Rate is automatically changed, Resolution is changed depends on 4K/FHD setting) 50Hz, 60Hz,... - Page 33 SETTINGS Settings VIDEO Color Space Auto Color space menu can be set automatically by connected TV’s EDID information YCbCr Set to YCbCr Possible to select 0-255 or 16-235 Setting OSD Mode OSD Mode (OSD Display is selectable in three modes.) ALL MODE Every OSD will be displayed on default setting.
-
Page 34: System
Time Zone SETTINGS Press [SETUP] to open Settings menu. SYSTEM VIDEO NETWORK UPDATE SHARE Time Zone Seoul Date 2015/01/16 Time 00:00 Select SYSTEM menu, using [ Reservation Disable direction buttons. Power On Time 00:00 Power Off Time 00:00 Key Lock Select Time Zone option using [ SYSTEM VIDEO... -
Page 35: Setting Date & Time
Setting DATE & TIME SETTINGS Set Date, time function. ※ - To select sub-menu : Use Direction buttons to move to the sub-menu and press [ENTER] to complete the setting. Press [SETUP] to open Settings menu. SYSTEM VIDEO UPDATE SHARE NETWORK Time Zone Seoul... -
Page 36: How To Reserve Power On/Off Time
How to Reserve Power ON/OFF Time SETTINGS Possible to reserve Power ON/OFF time for UHD Stream Generator. ※ - To select menu or time setting : Use Direction buttons - To complete setting : Press [ENTER] Press [SETUP] to open Settings menu. SYSTEM VIDEO UPDATE... -
Page 37: Setting Key Lock
Setting Key Lock SETTINGS You can lock the top buttons of the UHD Stream Generator. ※ - Item Selection : Direction buttons on remote. - Selection & Setting : [ENTER] button on remote. Press [SETUP] to open Settings menu. SYSTEM VIDEO UPDATE SHARE... -
Page 38: Etc
Troubleshooting Specifications Safety Instruction... -
Page 39: Troubleshooting
Change battery for the remote. Precautions for the Installation of Generator 1. Use the enclosed adapter supplied by DIGITALZONE. 2. Check to see if the input/output HDMI cable is connected properly. 3. We do not recommend to connect FHD TVs with UHD TVs together. - Page 40 Troubleshooting S1~4 Notification LED LED OFF LED BLINKING LED ON Status Details Troubleshooting Contact to the customer Impossible to recognize No HDD Service center HDD or there is no HDD (E-mail to sales@dzonei.com) Error for disk partition Necessary to format HDD Damaged HDD partition number (E-mail to sales@dzonei.com)
-
Page 41: Specifications
Specifications(H/W) ITEM Spec Resolution: (Up to 2160p60) - 2160p50/60 (HEVC, H.265 only), 2160p30, 2160p24/25, 1080p50/60,1080p30, 1080p24/25, 1080i50/60 - When 2160p50/60 is selected RGB mode is not supported and fixed to YCbCr mode. - 8/10 bit support - HDR 10 Support (Static Metadata SMPTE ST 2084/2086) Video HDMI Output... - Page 42 Specifications(S/W) ITEM Spec MP4 (File extension: mp4), Format MPEG-TS, MPEG-2 TS (File extension: ts, tp, m2ts) HEVC(H.265), Main10@L5.1, 8/10bit, 80Mbps, 60Hz(4:2:0) Video Codec MPEG4.10(H.264), MP@L5.1, 8bit, 50Mbps, 30Hz MPEG2, MP@HL, 8bit, 40Mbps, 30Hz MPEG 4 AAC-LC Stereo & 5.1 Audio Codec MPEG 1 layer I, II &...
-
Page 43: Safety Instruction
Safety Instruction Important Safety Instructions 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings, Install in accordance with the manufacturer’s instructions. 8. - Page 44 Safety Instruction WARNING To reduce the risk of fire or electric shock, do not expose this product to rain or moisture. Do not insert any metallic object through the ventilation grills or other opennings on the equipment. Apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus CAUTION EXPLANATION OF GRAPHICAL SYMBOLS...
- Page 45 Safety Instruction Disconnection Device Disconnect the main plug from the apparatus, if it’s defected. And please call a repair man in your location. When used outside of the U.S., it may be used HAR code with fittings of an approved agency is employed.
