DigitalZone MHP-4011NS How To Use Manual

Multi hd player
Hide thumbs Also See for MHP-4011NS:

Advertisement

Quick Links

Download this manual
MHP-4011NS
for Multi HD Player
How to install Video Wall

Advertisement

loading
Need help?

Need help?

Do you have a question about the MHP-4011NS and is the answer not in the manual?

Questions and answers

Related Manuals for DigitalZone MHP-4011NS

Summary of Contents for DigitalZone MHP-4011NS

  • Page 1 MHP-4011NS for Multi HD Player How to install Video Wall...
  • Page 2 Components Description...
  • Page 3 MHP-4011NS  MHP-4011NS POWER MENU DELETE VIDEO ENTER Video • HDMI x 1ea • Component (YPbPr) x 1ea Audio • Optical x 1ea • Coaxial x 1ea • RCA(L+R) x 1ea PLAY/PAUS DIRECTION KEYS US Adapter Extension power Audio receiver •...
  • Page 4 What kind of materials do you need for installation? Multi HD Player (MHP-4011NS) Network Cable(Direct Cable) M Sync. Cable IR Extension receiver User Manual Remote control Adaptor & Power cord HDMI cable(Option) HUB(Option)
  • Page 5 How to Use MHP (Multi HD Player)

  • Page 6: How To Update Firmware

    How to update firmware ※ The latest firmware version is 3.040 and it will be possible to save the setting for by-pass mode from firmwaree version 3.040 or higher version. 1. Plug USB in the Front. Move to “Firmware menu” 2.
  • Page 7 How to update new contents 1. Plug USB in the front page. 2. USB media menu will only appear when USB storage is connected. Move to “Update menu” Check Update Being updated. 1. Press UPDATE on remote control to open Update menu.
  • Page 8 How to make Contents for MHP...
  • Page 9 Check the file names before setting display mode The policy & rules for making files & names. Pre-condition (Contents should be made with below option) • File Name - Extension should be “0X_filename.udg” - For Example, 01_SS.udg / 02_SS.udg / 03_SS.udg / 04_SS.udg 01_SS.udg 03_SS.udg 02_SS.udg...
  • Page 10 Check the file names before setting display mode The policy & rules for making files & names. Example of AVC (H.264) File Example of MPEG2 TS File...
  • Page 11 How to set display mode following contents.
  • Page 12 Check the file names before setting display mode The policy & rules for making files & names. Pre-condition (Contents should be made with below option) • Bit rate - 1:1 matching mode (up to 35Mbps) - Scale Up mode (up to 35Mbps - 3D multi formatting mode (up to 30Mbps) •...

  • Page 13: File Naming

    1:1 Matching mode (Contents are pre-divided for each screen) File naming  Pre-divided contents should be named by numerical number for each position. Contents Update 01_xx.tp (Master) 02_xx.tp (Slave 1) 03_xx.tp (Slave 2) 04_xx.tp (Slave 3) 05_xx.tp (Slave 4) USB Media menu will appear when USB Storage Device is connected. 1.
  • Page 14 Scale up mode ( One Single content will be scaled up for whole screen) File naming  Any name is fine without numerical number at the beginning of the file name. xx.tp USB Media menu will appear when USB Storage Device is connected. 1.
  • Page 15 Multi Formatting function for 3D (L & R separated contents case) File naming  Add “L_” for the left contents & “R_” for right contents.  Except “L” &”R”, the file name should be same. Master Left L_xx.tp Left R_xx.tp Left Right Left...
  • Page 16 Multi Formatting function for 3D (L & R separated contents case) File naming  Add “S_” for the file name.  i.e) if the file name is animal.tp for side by side, the file name should be “S_animal.tp” Master S_xx.tp Side by Side Side by Side USB Media menu will appear when USB Storage Device is connected.
  • Page 17 How to set the display mode with undivided contents. ※ Please use this function for scale up mode, multi formatting mode for 3D. (For undivided contents for each TV) Press “Setup” button and move to “Network” page. Go to Connection Units & move to XxY section. Activate the number by pressing “Enter”...
  • Page 18 How to set “multi formatting function” with 3D Contents L contents & R contents are separated 1. Make sure the file name is correct. (i.e.- L_xxx.tip, R_xxx.tp) 2. Make “R”, right contents deactivated by pressing “check” button. 3. The activation can be made by pressing “check” button on remote control. 4.
  • Page 19 Dual play and Automatic 3D Video wall formatter.
  • Page 20 3D video wall formatter : Left & Right 3D image (separated). Master Left Right Left Left Right Left Right Right Left Right 1. Cropping relevant area from each player, then converted 3D format selected. 2. No need to split contents for Multi 3D LCD Display 3.
  • Page 21 3D video wall formatter : Side by Side contents Master Side by Side Side by Side 1. Cropping relevant area from each player, then converted 3D format selected. 2. No need to split contents for Multi 3D LCD Display 3. Possible to consider bezel size in all up, down, left & right. 4.
  • Page 22 How to set the display mode...
  • Page 23 How to set the display mode with undivided contents. ※ Please use this function for scale up mode, multi formatting mode for 3D. (For undivided contents for each TV) Press “Setup” button and move to “Network” page. Go to Connection Units & move to XxY section. Activate the number by pressing “Enter”...
  • Page 24 How to set the display mode 1. Press “List “ button and see the icons in front of file name. Possible to see “S1” or “S2” 2. If you have single one files and want to divide as many as you want, then select “S1” 3.
  • Page 25 Adjustment of bezel size...
  • Page 26 How to change bezel size for scale up mode. Adjustment of bezel size (2x2, 1:1matching mode image) • NX: X coordinate of the starting point of output screen • NY: Y coordinate of the starting point of output screen • NW: Area of the output screen •...
  • Page 27 EXAMPLE (2X2) ▶ ▶ 1. Press ‘Pause’ button. In “slave 3” “ 4. Move to slave 3 screen by PosX: adjust X value, PosY: adjust Y ▶ ▶ pressing ’Slave’ button value, Width: adjust Width/Height, Height: adjust Height“ and figure 4 button. ▶...

  • Page 28: Contact Address

    Contact Address...
