Heartland Classic 3115 Installation And Operating Instructions Manual

30" / 36" bottom mount fridges
Hide thumbs Also See for Classic 3115:

Advertisement

Bus. (519) 650-5501 Fax (519) 650-3773 Toll Free Phone 1-800-361-1517 Toll Free Fax 1-800-327-5609
Installation and Operating Instructions
Heartland Bottom Mount Fridges
30" Classic Bottom Mount Fridge
30" Legacy Bottom Mount Fridge
30" Metro Bottom Mount Fridge
36" Classic Bottom Mount Fridge
36" Legacy Bottom Mount Fridge
36" Metro Bottom Mount Fridge
30"/36" Ten50 Design
Bottom Mount Fridge
Save these instructions
for future use
Keep sales receipt and/or cancelled check as proof of purchase. If service is required, have complete model and serial
number identification of your refrigerator. This is located on a data plate inside the refrigerator compartment, on the
upper left side. Record these numbers below for easy access :
Model Number ________________________________ Serial Number_________________________________
Date of Purchase______________________________
In our continuing effort to improve the quality and performance of
our appliances, it may be necessary to make changes to the
appliance without revising this guide.
Note: Please read these instructions thoroughly before attempting to install this unit.
#37309.081905
1050 Fountain Street North Cambridge, Ontario, Canada N3H 4R7
Models:
3015
3065
3225
3115
3165
3325
Ten50
ATTENTION INSTALLER: Leave this manual with appliance
Model #3115 shown
V E R IF IE D
F O R E N E R G Y
P E R F O R M A N C E
R E N D E M E N T
É N E R G É T IQ U E
C
V É R IF IE R
L
US
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Classic 3115 and is the answer not in the manual?

Questions and answers

Summary of Contents for Heartland Classic 3115

  • Page 1 Keep sales receipt and/or cancelled check as proof of purchase. If service is required, have complete model and serial number identification of your refrigerator. This is located on a data plate inside the refrigerator compartment, on the upper left side. Record these numbers below for easy access :...
  • Page 2: Table Of Contents

    Measuring the Opening 36” Legacy ... 6 Measuring the Opening 30” Metro ... 7 Measuring the Opening 36” Metro ... 7 Leveling (all models) ... 8 Transporting Your Refrigerator ... 9 Connecting the Water Supply ... 16 Materials Needed ... 16 Touch Temperature Controls ... 17 Fresh Food Features ...
  • Page 3: Important Safety Instructions

    Junked or abandoned refrigerators are still dangerous – even if they sit out for “just a few days”. If you are getting rid of your old refrigerator, please follow the instructions below to help prevent accidents. Before you throw away your old refrigerator or freezer: •...
  • Page 4 Use & Care Guide Important Safety Instructions To reduce risk of fire, electric shock, serious injury or death when using your refrigerator, follow these 1) Read all instructions before using the refrigerator. 2) Observe all local codes and ordinances. 3) Be sure to follow grounding instructions.
  • Page 5: Installation

    Option 2) With 6” high optional cowl: 73 1/4 (186 cm) - provides enough space for optional 6” cowl assembly 2.) Cut out width for refrigerator’s main body: 30” (77 cm) 3.) Max. cut-out depth: 27 1/2” (70 cm) 4.) When installing your refrigerator, measure carefully.
  • Page 6: Measuring The Opening 30" Legacy

    Measuring the Opening 30” Legacy (see page 12 #3065 diagram) If refrigerator is to be installed into a recess verify and use the following dimensions 1.) Cut out height for refrigerator, where the top of the refrigerator is completely covered: 67” (171...
  • Page 7: Measuring The Opening 30" Metro

    Measuring the Opening 30” Metro (see page 15 #3225 diagram) If refrigerator is to be installed into a recess verify and use the following dimensions: 1.) Cut out height for refrigerator, where the top of the refrigerator is completely covered: 67 1/4” (171...
  • Page 8: Leveling (All Models)

    6. Turn stabilizing legs (C) clockwise until firmly against floor. 7. Turn adjustment screws (A) counter clock wise to allow the full weight of the refrigerator to rest on the stabilizing legs. 8. Replace bracket cover(s): • Position cover into the outer edge of the hinge.
  • Page 9: Transporting Your Refrigerator

    • NEVER transport refrigerator on its side. If an upright position is not possible, lay refrigerator on its back. Allow refrigerator to sit upright for approximately 30 minutes before plugging it in to assure oil returns to the compressor. Plugging the refrigerator in immediately may cause damage to internal parts.
  • Page 10 Use & Care Guide B o dy W id th 29 5/8” (76 cm ) 3/8” fro nt leg adjusters fro nt sta bilize rs Electrical W ater ½ ” (1.3 cm ) air gap 24” (61 cm ) cabinet depth 25”...
  • Page 11 36” (91.4 cm ) door w idth 3/8” back leg adjusters (typical of tw o) 3/8” front leg adjusters (typical of tw o) 35-5/8” (90.5 cm ) cabinet E lectrica l W a te r 1 ” (2 .5 cm ) a ir g ap 2 4”...
  • Page 12 Use & Care Guide 3/8” front leg adjusters E lectrica l W a te r ½ ” (1 .3 cm ) a ir g ap 2 4” (61 cm ) cab in et de pth 2 5” (63 .5 cm ) cou nter de pth 3 ”...
  • Page 13 36” (91.4 cm ) door w idth 3/8” back leg adjusters (typical of tw o) 3/8” front leg adjusters (typical of tw o) 35-5/8” (90.5 cm ) cabinet E lectrical W a ter 1 ” (2 .5 cm ) a ir g ap 2 4”...
  • Page 14 Use & Care Guide 3/8” front leg adjusters E lec trical W ater ½ ” (1 .3 cm ) air g ap 24” (61 cm ) cab in et depth 25” (63 .5 cm ) cou nter depth 3” (7.6 cm ) ga p requ ired for prop er door sw ing Top View...
  • Page 15 36” (91.4 cm ) door w idth 3/8” back leg adjusters (typical of tw o) 3/8” front leg adjusters (typical of tw o) 35-5/8” (90.5 cm ) cabinet E lectrical W a ter 1 ” (2 .5 cm ) a ir g ap 2 4”...
  • Page 16: Connecting The Water Supply

    • Tighten nuts by hand to prevent cross threading. Finish tightening nuts with pliers and wrenches. Do not overtighten. • Wait 2-3 hours before placing refrigerator into final position to check and correct any water leaks. Recheck for leaks after 24 hours.
  • Page 17: Touch Temperature Controls

    1 through 7 (coldest). • Set the freezer control on 4. • Set the refrigerator control on 4. • Let the refrigerator run at least 8 to 12 hours before adding food. Warm Cabinet Surfaces At times, the front of the refrigerator cabinet may be warm to the touch.
  • Page 18: Fresh Food Features

    • Handle tempered glass shelves carefully. Shelves may break suddenly if nicked, scratched, or exposed to sudden temperature change. Your refrigerator has either Spillsaver™ or nonsealed shelves. The Spillsaver™ shelves have a spill retainer edge which allows for easier clean up and some are equipped with the EasyGlide™...
  • Page 19: Beverage Chiller

    Note •Cold air diverted into the Beverage Chiller™ can decrease the main refrigerator temperature Refrigerator control may need to be adjusted. Crisper Drawers The Crisper Drawers provide a higher humidity environment for fresh fruit and vegetable storage. Controls The Crisper Controls regulate the amount of humidity in the crisper drawer.
  • Page 20: Temperature-Controlled Drawer

    On the 30” the control is on the front of the drawer on the right hand side. Set the control to cold or refrigerator temperature. Set the drawer on the coldest or setting when a temperature colder than the main refrigerator compartment is desired.
  • Page 21: Freezer Features

    Only 36” models come equipped with an auto- matic ice maker. Icemaker kit for 30” is # 31105, call your dealer or contact Heartland to order. Connect the ice maker to the water supply as instructed on page 7. Proper water flow and a level refrigerator are essential for optimal ice maker performance.
  • Page 22: Water Dispenser

    • Do not place fingers or hands on the automatic ice making mechanism while the refrigerator is plugged in. This will help protect you from possible injury. It will also prevent interference with moving parts of the ejector mechanism and the heating element that releases the cubes.
  • Page 23: Water Filter

    Water Filter 36” Models only WARNING To avoid serious illness or death, do not use refrigerator where water is unsafe or of unknown quality without adequate disinfection before or after use of filter. CAUTIO N After installing a new water filter, always dispense water for two minutes before removing the filter for any reason.
  • Page 24 USE ONLY WITH COLD WATER SUPPLY. CHECK FOR COMPLIANCE WITH THE STATE AND LOCAL LAWS AND REGULATIONS. System Specification and Performance Data Sheet Refrigerator Water Filter Cartridge Model Influent Average 2.0 m g/L ± 10% 1.88 m g / L <0.05136364 m g /L...
  • Page 25 Trademark /Model Designation UKF8001AXX750 469006-750 67003523-750 Manufacturer: PentaPure Inc. The water treatment device(s) listed on this certificate have met the testing requirements pursuant to Section 116830 of the Health and Safety Code for the following health related contaminants: Microbiological Contaminants and Turbidity Cysts Turbidity Organic Contaminants...
  • Page 26: State Of California Water Certificate

    To check the temperature, place an appliance thermometer in a glass of water and place in the centre of the refrigerator. Check after 24 hours. If the temperature is above 40° F (4° C) adjust the controls as explained on page 8.
  • Page 27: Food Storage Chart

    Leftover yolks or whites FRUITS Apples Bananas Pears, plums, avocados Berries, cherries, apricots Grapes Citrus fruits Pineapples, cut REFRIGERATOR FREEZER 1 month 6 to 9 months 1 week Not recommended 1 to 2 weeks Not recommended 3 to 5 days...
  • Page 28 Sausage, ground Sausage, smoked Veal Frankfurters Sources: United States Department of Agriculture; Food Marketing Institute; Cooperative Extension Service, Iowa State University. REFRIGERATOR FREEZER 1 to 2 days 8 to 10 months 3 to 5 days 8 to 10 months 1 to 2 weeks...
  • Page 29: Care And Cleaning

    Door Gaskets Condenser Coil Remove base grille to access. Condenser Fan Outlet Grille See back of refrigerator. Accessories Shelves, buckets, drawers, etc. To avoid personal injury or property damage, observe the following: • Read and follow manufacturer’s directions for all cleaning products.
  • Page 30: Cleaning The Outside

    If any acid based food or liquid, such as lemon juice or tomato juice, is spilled on the refrigerator, wipe it at once to prevent staining. Stainless Steel – Metro Series...
  • Page 31: Removing Odors From

    Removing Odors From Refrigerator 1. Remove all food and turn the refrigerator OFF. 2. Disconnect power to the refrigerator. 3. Clean the walls, floor, ceiling of cabinet interior, drawers, shelves and gaskets according to the instructions on page 20 and 21.
  • Page 32: Replacing Light Bulbs

    4. Replace light bulb cover by inserting tabs on light shield into liner holes on each side of light assembly. Slide shield toward front of refrigerator until it locks into place. Do not force shield beyond locking point. Doing so may damage light shield.
  • Page 33: Preparing For Vacation

    For short vacations or absences (three months or less): 1. Remove all perishables. 2. If no one will be checking in on the refrigerator during your absence, remove all frozen items also. 3. Automatic ice maker: • Shut off the water supply to the ice maker at least one day ahead of time.
  • Page 34: Operating Sounds

    Improvements in refrigeration design may produce sounds in your new refrigerator that are different or were not present in an older model. These improvements were made to create a refrigerator that is better at preserving food, is more energy efficient, and is quieter overall. Because new refrigerators run quieter, sounds may be detected that were present in older refrigerators, but were masked by higher sound levels.
  • Page 35 Clean according to the instructions on page 20. See pages 8, 10 or 11 to adjust your controls. Refrigerator is not level. See page 5/6 for details on how to level your refrigerator. Check gaskets for proper seal. Clean, if necessary, according to the instructions on page 20.
  • Page 36 Normal operation. Allow time for recently added food to reach refrigerator or freezer temperature. Evaluate your refrigerator’s environment. Refrigerator may need to be moved to run more efficiently. Clean, if necessary, according to the instructions on page 22. See pages 8, 10 or 11 to adjust your controls.
  • Page 37: Ice Maker

    PROBLEM Refrigerator is Plastic tubing was used to complete water connection. leaking water Improper water valve was installed. Ice forms in inlet Water pressure is low. tube to ice maker Freezer temperature is too high. Water pressure is low. Water flow is slower than normal Improper water valve was installed.
  • Page 38: Warranty

    Entire Product – Limited One Year Warranty Heartland warrants that it will supply all necessary parts and labour to repair or replace in your home, any component which proves to be defective in material or workmanship, with the exception of painted or porcelain enamel finish, or plated surfaces.
  • Page 39: Troubleshooting

    If You Need Service • Call the dealer from whom your appliance was purchased or call Heartland Appliances Customer Assistance at 1-877-650-5775 ext 2362 to locate an authorized servicer. • Be sure to retain proof of purchase to verify warranty status.
  • Page 40 2600 (SweetHeart)- Wood burning cookstove- same as the Oval, in a smaller version! For more information please call your dealer, or call Heartland Appliances: Phone 1-800-361-1517 or Fax 1-800-327-5609 in a 30"...
