- Page 1 User's Manual SYS8F600VGGA-8265U Ver 1.0...
-
Page 2: Table Of Contents
Contents 1. Models and Attentions ....................2 1.1 Models ............................2 1.2 Attentions ............................2 2. Specification ........................3 3. Functional Block Diagram ....................5 4. Mechanical Drawing ...................... 6 5. Jumpers / Headers and Connectors ................7 6. Definition of Jumpers /Headers and Connectors ............10 SYSRST1 (System Reset Header 2*1 Pin 1.25mm) .............. -
Page 3: Models And Attentions
1. Models and Attentions 1.1 Models This manual is applied to following models: LVDS SATA Model HDMI /eDP Key-B Key-M/B Key-E WIFI+ 8F600-4205U 4205U LVDS 5G/4G SATA SSD PCIE/ SATA WIFI+ 8F600-8145U LVDS 5G/4G 8145U PCIE/ SATA WIFI+ 8F600-8265U LVDS 5G/4G 8265U PCIE/ SATA... -
Page 4: Specification
2. Specification 8F600-8565U 8F600-8265U 8F600-8145U 8F600-4205U Model Celeron® Core (Premium-U) (Base-U) CPU Model i7-8565U i5-8265U i3-8145U 4205U 1.8GHz, up to 1.6GHz, up to 2.1GHz, up to 1.80GHz Clock Speed 4.6GHz 3.9GHz 3.9GHz Quad Quad Dual Dual Multi-Core 15W Base, 25W Max 1 * LVDS/eDP (Header): LVDS up to 1920x1200@60Hz (default) or eDP up to 3840x2160@60Hz Display... - Page 5 DC 12V 1 * DC 12V Power Input Thread Connector Power Supply 1 * DC 12V Power Input Header 3.5-inch Standard (146mm * 105mm) Factor Notes: [1]: Up to three independent displays can be activated at the same time. [2]: Supported memory frequency is determined by the CPU, supports up to 2400MHz [3]: Only SATA for Base-U or NVMe/ SATA Auto detected for Premium-U.
-
Page 6: Functional Block Diagram
3. Functional Block Diagram USB2.0*1 USB2.0*2 CH A DDR4 Dual USB2.0 TYPE-A(or RJ45) SO-DIMM*1 USB2.0*1 DDI*2 HDMI USB2.0 TYPE-A*2 Wafer*2 USB2.0*2 USB2.0 Dual USB2.0 eDP/LVDS Converter Wafer USB2.0*1 USB2.0*1 Lout,MIC Audio USB2.0 ALC897 USB2.0 Wafer Wafer*2 USB2.0(4G) PCIE*1 RS232/RS485 GbE LAN COM1 Enternet RJ45... -
Page 7: Mechanical Drawing
4. Mechanical Drawing... -
Page 8: Jumpers / Headers And Connectors
5. Jumpers / Headers and Connectors... - Page 9 Jumpers / Headers and Connectors SYSRST1 System Reset Header HDD_LED1 HDD LED Header PWR_LED1 Power LED Header PANSW1 Power Button Header J_AUDIO1 Front Audio Header (Line-Out + MIC) F_USB1 Front USB2.0 Header1 F_USB2 Front USB2.0 Header2 F_USB3 Front USB2.0 Header3 Front USB2.0 Header4 F_USB4 (Colay with M.2_B1_5G1, Default not on board)
- Page 10 DIMM1 DDR4 SO-DIMM Slot M.2_KEYE_WLAN1 M.2 (NGFF) Key-E Slot (PCIE+USB2.0, WIFI+BT, 2230) DC 12V Power Input Thread Connector DC_IN2 (DC_IN1) (DC 12V Power Input Φ2.5mm Jack Optional) COM1 COM1 DB9/M Connector R_USB2 Dual USB3.0 TYPE-A Connector2 R_USB1 Dual USB3.0 TYPE-A Connector1 HDMI2 HDMI Upright TYPE-A Connector2 HDMI1...
-
Page 11: Definition Of Jumpers /Headers And Connectors
6. Definition of Jumpers /Headers and Connectors 1) SYSRST1 (System Reset Header 2*1 Pin 1.25mm) Graphic Definition Definition RESET+ RESET- 2) HDD_LED1 (HDD LED Header 2*1 Pin 1.25mm) Graphic Definition Definition HDD 3.3V LED+ HDD 3.3V LED- 3) PWR_LED1 (Power LED Header 2*1 Pin 1.25mm) Graphic Definition Definition... -
Page 12: F_Usb1 (Front Usb2.0 Header1 4*1 Pin 2.00Mm)
6) F_USB1 (Front USB2.0 Header1 4*1 Pin 2.00mm) Graphic Definition Definition + 5V USB2_5+ USB2_5- Notes: [1]: USB2_5 Signal of F_USB1 colay with R_USB3, default support F_USB1. (resistor selectable) 7) F_USB2 (Front USB2.0 Header2 4*1 Pin 2.00mm) Graphic Definition Definition + 5V HUB_USB2_1+ HUB_USB2_1-... -
Page 13: F_Usb6* (Front Usb2.0 Header6 5*2 Pin 2.00Mm)
11) F_USB6* (Front USB2.0 Header6 5*2 Pin 2.00mm) Graphic Definition Definition + 5V + 5V USB2_8- USB2_9- USB2_8+ USB2_9+ Notes: [*]: F_USB6 only support by Premium U. 12) SIM1 (SIM Card Header 6*1 Pin 2.00mm) Graphic Definition Definition UIM_PWR UIM_CLK UIM_RST UIM_DAT UIM_VPP... -
Page 14: J_Com2 (Com2 Header 9*1 Pin 1.25Mm)
15) J_COM2 (COM2 Header 9*1 Pin 1.25mm) Graphic Definition Definition COM2_PIN1 COM2_CTS# COM2_DSR# COM2_DTR# COM2_RXD COM2_PIN9 COM2_RTS# COM2_TXD Notes: [1]: Pin1 of COM2 is DCD# by default, 5V/12V is available if specified. (resistor selectable) [2]: Pin9 of COM2 is RI# by default, 5V is available if specified. (resistor selectable) 16) LVDS_P1 (eDP/LVDS Backlight Control Header 6*1 Pin 2.00mm) Graphic Definition... -
Page 15: J_Com3 (Com3 Header 9*1 Pin 1.25Mm)
18) J_COM3 (COM3 Header 9*1 Pin 1.25mm) Graphic Definition Definition COM3_PIN1 COM3_CTS# COM3_DSR# COM3_DTR# COM3_RXD COM3_PIN9 COM3_RTS# COM3_TXD Notes: [1]: Pin1 of COM3 is DCD# by default, 5V/12V is available if specified. (resistor selectable) [2]: Pin9 of COM3 is RI# by default, 5V is available if specified. (resistor selectable) 19) LVDS1 (eDP/LVDS Signal Header 20*2 Pin 1.25mm) Graphic Definition... -
Page 16: J_Com6_485* (Com6 Rs485 Header 3*1 Pin 2.00Mm)
LVDS_B_DATA3-/ LVDS_A_DATA3-/ EDP_AUX- LVDS_B_DATA3+/ LVDS_A_DATA3+/ EDP_AUX+ Notes: [1]: Panel Power VDD is 3.3V by default, 5V/12V is selectable by “eDP/LVDS VDD Select Jumper” (JC_LVDS1, Table 13). [2]: It supports LVDS by default and can supports eDP if specified. (resistor selectable) 20) J_COM6_485* (COM6 RS485 Header 3*1 Pin 2.00mm) Graphic Definition... -
Page 17: J_Gpio1 (Gpio Header 5*2 Pin 2.00Mm)
23) J_GPIO1 (GPIO Header 5*2 Pin 2.00mm) Graphic Definition Definition SIO_GPI70 SIO_GPI71 (0xA06 Bit0, H (0xA06 Bit1, H) SIO_GPI72 SIO_GPI73 (0xA06 Bit2, H) (0xA06 Bit3, H) SIO_GPO74 SIO_GPO75 (0xA06 Bit4, H) (0xA06 Bit5, H) SIO_GPO76 SIO_GPO77 (0xA06 Bit6, H) (0xA06 Bit7, H) + 3.3V Notes: [1]: “H”... -
Page 18: Clrcmos1 (Cmos Clear Jumper 3*1 Pin 2.54Mm)
27) CLRCMOS1 (CMOS Clear Jumper 3*1 Pin 2.54mm) Graphic Setting Function 1-2(Default) Normal Clear CMOS 34) COM1 (COM1 DB9/M Connector) Graphic Definition Definition COM1_PIN1 COM1_DSR# COM1_PIN2 COM1_RTS# COM1_TXD COM1_CTS# COM1_DTR# COM1_PIN9 Notes: [1]: COM1 can be RS232 / RS485 by selecting JSEL1 Jumper, check Table26 for detail. When COM1 support RS232, Pin1 of COM1 is DCD# by default, 5V/12V is available if specified. -
Page 19: Lan1 (Gbe Lan Rj45 Connector1 8Pin)
40) LAN1 (GBE LAN RJ45 Connector1 8Pin) Graphic Definition Definition MDI0_1+ MDI2_1- MDI0_1- MDI1_1- MDI1_1+ MDI3_1+ MDI2_1+ MDI3_1- ACT: Twinkling Yellow 1000M: Turn Yellow Active Speed Only LINK: Lights On 100M: Turn Green Stop: Lights Off 10M: Lights Off... -
Page 20: Bios Setup
7. BIOS setup See “BIOS Spec for SYS8F400VGGA-8265U Series” for detail information of BIOS setup. 【End】...
