Summary of Contents for Yokota YZ-T950E
- Page 1 YZ-T950E MANUAL EN www.rami-yokota.com...
- Page 2 Brand : Yokota Safety standard : EN ISO 11148-6 Square Drive / Hexagon : 3/8" Sq.Dr. Bolt capacity (mm) : 10 : 2000 - 4800 Torque (Nm) : 40 - 60 Weight w/o battery (kg) : 1,25 mm A : 173...
-
Page 3: Electrical Safety
Torque adjustment The Yokota YZ-T series are battery hydraulic shut-off impulse wrenches with electronic controlled shut-off. The electronics measure the load on the motor of each impulse. The load on the motor is called “value”. The higher the value, the higher the torque in the joint. The number of impulses are counted also. - Page 4 Measured value Maximum value Cut value Start value Minimum number of impulses Maximum number of impulses Number of impulses Value too high Number of impulses too low Value too low Number of impulses too high Cycle OK The torque (reached in the joint) is depending on 3 settings: The motor speed: Output value Cut value...
- Page 5 The high speed setting of the motor should be increased Correlation between the motor speed & tool's output (example of the YT-T900 with relief valve positioned at shipping) YET Tester Displayed value Motor High Speed Setting (rpm) T he above shows the influence of the motor speed on the torque output, this is an example of the YZ-T900 tested on the static torque tester YET-1001C. ...
- Page 6 Pulse interval: longer Tool output : lower Pulse interval : shorter Never adjust fully at max or min, always at least 60 degrees from min and max. Using the Programming Console PC-1 C onnect the PC-1 with cable CC-1 to the tool. Programming Console PC-1 1 Mounting hole 2 Display screen...
- Page 7 Entering the value for each parameter: Press Ent to enter Parameter setting Press Ent to enter Start value Use the Left/Right arrow for the digit to be set, use the numeric keypad to enter the values, after entering the correctalue use ENT to confirm and to leave the parameter, or use CAN to cancel the input value.
- Page 8 R ES = total judgement T ightening judgement OK or NOK A: tightening OK N: tightening NOK V AL = Output Value O utput value at shut-off P LS = number of impulses N umber of impulses from Start value to value tool shut-off ...
- Page 9 Maintenance. S elect MAINTENACE with the up and down arrow keys and press ENT. Selecting SETTING INIT or DATA CLEAR with the up and down arrow and press ENT. 1: SETTING INIT = initializing the parameter setting back to default value. ...
-
Page 10: Maintenance
Changing the speed and or the cut value will have an influence on the number of impulses. F or Yokota impulse wrenches we advise to do a preventive oil change maintenance after 250.000 cycles. 1 cycle is 0.5 seconds impulsing (hard joint). Oil change is including replacing the service kit. - Page 11 Trouble Probable cause Action The tool does not operate. The motor is over-heated. Wait until the motor cools down and the LED switches The battery pack is over-discharged. The battery voltage falls below a certain level and protective function is activated. Charge the battery pack.
-
Page 12: Intended Use
temperature of 0 to 40 . When the battery pack reaches a temperature suitable for charging, the charging is automatically started. Error lamp (red) for the battery charger blinks The battery breaks down or is at the end of its life Replace the battery. -
Page 13: Warranty
• 3 months on spare parts of tools, which are repaired by us. Warranty covers material or construction mistakes of the manufacturer, which are clearly definable. Replacement of parts or repair by an official Yokota/Red Rooster service workshop is free of charge, when the tool is covered by warranty. - Page 14 www.rami-yokota.com...
