USE AND MAINTENANCE MANUAL
TRAD 300 AO GT
THOMAS
10/2004
THOMAS S.p.A. - Via Pasubio, 32 - 36033 Isola Vicentina (VI) - Telephone 0444 / 97.61.05 - Fax 0444 / 97.69.34

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TRAD 300 AO GT and is the answer not in the manual?

Questions and answers

Related Manuals for Thomas TRAD 300 AO GT

Summary of Contents for Thomas TRAD 300 AO GT

  • Page 1 USE AND MAINTENANCE MANUAL TRAD 300 AO GT THOMAS 10/2004 THOMAS S.p.A. - Via Pasubio, 32 - 36033 Isola Vicentina (VI) - Telephone 0444 / 97.61.05 - Fax 0444 / 97.69.34...

  • Page 2: Table Of Contents

    TRAD 300 TRAD 300 TRAD 300 A A A A A O GT O GT O GT TRAD 300 TRAD 300 O GT O GT Contents Contents ................ " CHAPTER 7 Ordering spare parts ............ " Regulating the machine .........." 10 7.1 - Blade tension assembly .........

  • Page 3: Machine Certification And Identification Marking

    TRAD 300 O GT Machine certification and identification marking MACHINE LABEL via Pasubio, 32 36033 ISOLA VIC. - ITALIA TRAD 300 AO GT MODEL SERIAL NUMBER YEAR OF MANUFACTURE (Space reserved for the NAME and STAMP of the DEALER and/or IMPORTER)

  • Page 4: Reference To Accident-Prevention Regulations

    TRAD 300 TRAD 300 TRAD 300 A A A A A O GT O GT O GT TRAD 300 TRAD 300 O GT O GT REFERENCE TO ACCIDENT - PREVENTION REGULATIONS This machine has been built to comply with the national and community accident-prevention regulations in force. Improper use and/or tampering with the safety devices will relieve the manufacturer of all responsibility.

  • Page 5: Electrical Equipment According To European Standard "Cenelec En 60 204-1

    If they are, replace tool. - Check saw frame return spring to ensure proper balancing. - Before carrying out any repairs on the machine, consult the dealer or apply to THOMAS.

  • Page 6: Technical Characteristics

    TRAD 300 TRAD 300 TRAD 300 A A A A A O GT O GT O GT TRAD 300 TRAD 300 O GT O GT TECHNICAL MACHINE DIMENSIONS CHARACTERISTICS TRANSPORT INSTALLATION 3.1 - Table of cutting capacity and technical details DISMANTLING 4.1 - Machine dimensions 1850...

  • Page 7: Transport And Handling Of The Machine

    TRAD 300 TRAD 300 A A A A A O GT TRAD 300 O GT O GT O GT TRAD 300 TRAD 300 O GT 4.2 - Transport and handling of the machine If the machine has to be shifted in its own packing, use a fork-lift truck or sling it with straps through the special attachments as indicated by the arrow.

  • Page 8: Instructions For Assembly Of The Loose Parts And Accessories

    TRAD 300 TRAD 300 TRAD 300 A A A A A O GT O GT O GT TRAD 300 TRAD 300 O GT O GT 4.6 - Instructions for assembly of the loose parts MACHINE FUNCTIONAL and accessories PARTS 5.1 - Operating head or saw frame Fit the components supplied as indicated in the photo: - Part of the machine consisting of drive members (gearmotor - Mount the guard protecting the bar feed cylinder.

  • Page 9: Bed

    TRAD 300 TRAD 300 A A A A A O GT TRAD 300 O GT O GT O GT TRAD 300 TRAD 300 O GT - Check that the pressure gauge, located on the hydraulic unit reads 28 BAR, if it doesn’t attempt to swap one of the electric power supply wires (only during installation).

  • Page 10: Regulating The Machine

    TRAD 300 TRAD 300 TRAD 300 A A A A A O GT O GT O GT TRAD 300 TRAD 300 O GT O GT The band saw is now ready to start work, bearing in mind that CUTTING SPEED VARIATOR ( OPTION ) the CUTTING SPEED and the TYPE of BLADE - combined with a suitable lowering of saw frame - are of decisive importance - To adjust the blade speed rotation at the requested rate...

  • Page 11: Blade Guide Blocks

    TRAD 300 TRAD 300 A A A A A O GT TRAD 300 O GT O GT O GT TRAD 300 TRAD 300 O GT - This device does not require any special maintenance; keep 7.2 - Blade guide blocks vice adjustment screw well greased and perfectly clean.

  • Page 12: Sawframe Return

    TRAD 300 TRAD 300 TRAD 300 A A A A A O GT O GT O GT TRAD 300 TRAD 300 O GT O GT 7.5 - Sawframe return AUTOMATICO PGR: 01/50 _____ P = _____/ ____ This system reduces the passive phases of the operating cycle, in other words to eliminate the idle stroke that takes place when Battuta L = _____mm...

  • Page 13: Routine And Special Maintenance

    - Cleaning and greasing of the stock feed carriage guide rods. Special maintenance operations must be carried out by skilled personnel. However, we advise contacting THOMAS or their 8.3 - Monthly maintenance dealer and/or importer. Also the reset of protective and safety equipment and devices, of the reducer, the motor, the motor - Check the tightening of the motor flywheel screws.

  • Page 14: Material Classification And Choice Of Tool

    TRAD 300 TRAD 300 TRAD 300 A A A A A O GT O GT O GT TRAD 300 TRAD 300 O GT O GT words, the number of teeth per inch (25,4 mm) suitable for the MATERIAL material to be cut, according to these criteria: - parts with a thin and/or variable section such as profiles, pipes CLASSIFICATION AND and plate, need close toothing, so that the number of teeth...

  • Page 15: Cutting And Advance Speed

    TRAD 300 TRAD 300 A A A A A O GT TRAD 300 O GT O GT O GT TRAD 300 TRAD 300 O GT 9.7 - Blade type Z CONTINUOUS Z COMBO SOLID Ø OR L MM TOOTH DESIGN TOOTH DESIGN TILL 30 They differ essentially in their constructive characteristics, such...

  • Page 16: Set

    TRAD 300 TRAD 300 TRAD 300 A A A A A O GT O GT O GT TRAD 300 TRAD 300 O GT O GT This set is associated with very fine teeth and it is mainly used for the cutting of pipes and thin section bars (from 1 to 3 mm). Saw teeth bent out of the plane of the saw body, resulting in a wide cut in the workpiece.

  • Page 17: Machine Components

    TRAD 300 TRAD 300 A A A A A O GT TRAD 300 O GT O GT O GT TRAD 300 TRAD 300 O GT MACHINE COMPONENTS 10.1 - List of spare parts REFERENCE N° DESCRIPTION REFERENCE N° DESCRIPTION BEDPLATE UNIT 80 ........
  • Page 18 TRAD 300 TRAD 300 TRAD 300 A A A A A O GT O GT O GT TRAD 300 TRAD 300 O GT O GT REFERENCE N° DESCRIPTION REFERENCE N° DESCRIPTION 254 ........Washer FEEDING SYSTEM 255 ........Bearing 6002 2RS 201 ........
  • Page 19 TRAD 300 TRAD 300 A A A A A O GT TRAD 300 O GT O GT O GT TRAD 300 TRAD 300 O GT BEDPLATE UNIT...
  • Page 20 TRAD 300 TRAD 300 TRAD 300 A A A A A O GT O GT O GT TRAD 300 TRAD 300 O GT O GT SAW FRAME UNIT...
  • Page 21 TRAD 300 TRAD 300 A A A A A O GT TRAD 300 O GT O GT O GT TRAD 300 TRAD 300 O GT AVANCE UNIT...
  • Page 22 TRAD 300 TRAD 300 TRAD 300 A A A A A O GT O GT O GT TRAD 300 TRAD 300 O GT O GT ELECTRIC WIRING 451 Fuse holder cartridge 452 Fuse holder cartridge 453 Fuse holder cartridge 454 Fuse holder cartridge 455 Fuse holder cartridge 456 Transformer TC1 457 Remote switch KM...

  • Page 23: Three-Phase Electric Diagram

    TRAD 300 TRAD 300 A A A A A O GT TRAD 300 O GT O GT O GT TRAD 300 TRAD 300 O GT WIRING DIAGRAMS 11.1 - Three-phase electric diagram...
  • Page 24 TRAD 300 TRAD 300 TRAD 300 A A A A A O GT O GT O GT TRAD 300 TRAD 300 O GT O GT...
  • Page 25 TRAD 300 TRAD 300 A A A A A O GT TRAD 300 O GT O GT O GT TRAD 300 TRAD 300 O GT...
  • Page 26 TRAD 300 TRAD 300 TRAD 300 A A A A A O GT O GT O GT TRAD 300 TRAD 300 O GT O GT...
  • Page 27 TRAD 300 TRAD 300 A A A A A O GT TRAD 300 O GT O GT O GT TRAD 300 TRAD 300 O GT...

  • Page 28: Hydraulic Electric Diagram

    TRAD 300 TRAD 300 TRAD 300 A A A A A O GT O GT O GT TRAD 300 TRAD 300 O GT O GT 11.2 - Hydraulic electric diagram HYDRAULIC DIAGRAM KEY Filter Hydraulic unit tank Hydraulic unit pump Hy draulic pump motor Pressure control valve Regulator...

  • Page 29: Troubleshooting

    TRAD 300 TRAD 300 A A A A A O GT TRAD 300 O GT O GT O GT TRAD 300 TRAD 300 O GT TROUBLESHOOTING This chapter lists the probable faults and malfunctions that could occur while the machine is being used and suggests possible remedies for solving them.
  • Page 30 TRAD 300 TRAD 300 TRAD 300 A A A A A O GT O GT O GT TRAD 300 TRAD 300 O GT O GT FAULT PROBABLE CAUSE REMEDY PREMATURE BLADE WEAR Faulty running-in of blade See Chapter “Material classification and blade selection”...
  • Page 31 TRAD 300 TRAD 300 A A A A A O GT TRAD 300 O GT O GT O GT TRAD 300 TRAD 300 O GT FAULT PROBABLE CAUSE REMEDY Blade guide pads not regulated or dirty Check distance between pads (see because of lack of maintenance Chapter “Machine adjustments”...
  • Page 32 TRAD 300 TRAD 300 TRAD 300 A A A A A O GT O GT O GT TRAD 300 TRAD 300 O GT O GT FAULT PROBABLE CAUSE REMEDY Insufficient lubricating refrigerant or Check level of liquid in the tank. Increase wrong emulsion the flow of lubricating refrigerant, check- ing that the hole and the liquid outlet pipe...

  • Page 33: Electrical Components Diagnosis

    TRAD 300 TRAD 300 A A A A A O GT TRAD 300 O GT O GT O GT TRAD 300 TRAD 300 O GT 12.2 - Electrical components diagnosis FAULT PROBABLE CAUSE REMEDY THE GREEN LIGHT DOES NOT Light burnt Replace light.
  • Page 34 TRAD 300 TRAD 300 TRAD 300 A A A A A O GT O GT O GT TRAD 300 TRAD 300 O GT O GT FAULT PROBABLE CAUSE REMEDY CARRIAGE VICE DOES NOT OPEN Instrument Check if the relative functional key ena- bles the Y1 output.
  • Page 35 TRAD 300 TRAD 300 A A A A A O GT TRAD 300 O GT O GT O GT TRAD 300 TRAD 300 O GT FAULT PROBABLE CAUSE REMEDY Pump temperature probe The pump protection has stepped in. Remove the protections of the box con- taining the electric parts and mechanically detach the protections.

  • Page 36: Noise Tests

    TRAD 300 TRAD 300 TRAD 300 A A A A A O GT O GT O GT TRAD 300 TRAD 300 O GT O GT FAULT PROBABLE CAUSE REMEDY THE SAWING MACHINE DOES NOT Saw frame limit switch microswitch up Check that it is pressed and check effi- OPERATE IN AUTOMATIC ciency.

  • Page 37: Plates And Labels
