- Page 1 Telemetry Interface Installation Guide Model covered Rx100 Dome interface Rx100 Building Block Video Ltd., 17 Apex Park, Dome Interface Diplocks Industrial Estate, Hailsham, East Sussex, BN27 3JU, UK. Tel:+44 (0)1323 842727 Fax:+44 (0)1323 842728 Support:+44(0)1323 444600 www.bbvcctv.com...
-
Page 2: Table Of Contents
Fig. 3 Launch amplifier 5. System schematic diagrams Fig. 4 Integration of dome into conventional system Fig. 5 Simple single camera system Appendix A - Dome Connection Details Appendix B - Troubleshooting Installation Manual – Rx100 Interface Edition 1.5 March 2001 Page 2... -
Page 3: Pre-Installation Checks And Safety Procedures
Servicing - Servicing of the unit should only be undertaken by qualified service personnel, as opening or removing covers may expose you to dangerous voltages or other hazards. Installation Manual – Rx100 Interface Edition 1.5 March 2001 Page 3... - Page 4 Safety During Installation or Servicing - Particular care should be taken to isolate the dome in order to prevent operation while engineering work is being carried out on the Rx100. Adhere to Safety Standards - All normal safety precautions as laid down by British Standards and the Health and Safety at Work Act should be observed.
-
Page 5: Rx100 Technical Specification
BBV’s range of up-the-coax telemetry transmitters. See appendix A for a complete list of supported domes. The Rx100 interface is supplied in an IP 67 rated enclosure. It will be necessary to make suitable holes in the enclosure to permit cable entry and exit. Adequately rated cable glands and or flexible conduit should be used at all times to avoid compromising the protection afforded by the enclosure as supplied. -
Page 6: Transmitter Compatibility Chart
Pan/Tilt speed fixed at 18º/second and 90º/second whilst moving to pre-set position. May 1998 The Panasonic WV-CSR600B dome now fully supported allowing smooth variable speed control along with access to the dome's camera setup menu. Installation Manual – Rx100 Interface Edition 1.5 March 2001 Page 6... -
Page 7: Cable Connection Method
CABLING RECOMMENDATIONS FOR THE Rx100 INTERFACE. Although BBV do not specify any particular type, manufacturer or supplier of cables, the following ESD Electronic Services (01279 626777) cables have been used successfully for production and testing:... -
Page 8: Operating Voltage
3. INSTALLATION OPERATING VOLTAGE The Rx100 requires all connections to the PCB to be made by the installer, and via terminal blocks or by plug and socket. These connections are: power in, video in, video out, serial data to dome. In addition connections for alarm in, alarm out and lights if required are provided. -
Page 9: Diagnostic Aids
Both LEDs No power or major PCB fault. All BBV equipment is designed to auto-tune and compensate for any discrepancies in the transmitted telemetry signal, there are no further adjustments that need to be made. VIDEO LAUNCH AMPLIFIER AND CABLE LENGTH COMPENSATION The interface features a video launch amplifier with two variable controls situated close to the BNC connectors: Lift and Gain. -
Page 10: Diagrams
KEYBOARD 1 OPTIONAL 2ND KEYBOARD Fig. 5 SIMPLE SINGLE CAMERA SYSTEM Video Data Alarm contact Rx100 Interface B B V PROGRAM AUTOPAN MONITOR IRIS FOCUS ZOOM PRESETS LENS TILT Tx400DC Installation Manual – Rx100 Interface Edition 1.5 March 2001 Page 10... - Page 11 Appendix A - Dome connection details Alltec Apollo JVC TK-C675E Mark Mercer D250MPT Panasonic WV-CSR400/B Panasonic WV-CSR600/B Now Fully supported Pelco SD-5 ‘Spectra’ Star MD-100 Rx100 manual Appendix A – Dome connections Page A-1...
- Page 12 AUTOPAN & & The Camera menu can only be accessed when the OPTION LINK on J6 of the Rx100 is removed. To prevent the camera from hanging please ensure that you EXIT after using end option in the camera menu.
- Page 13 Ensure that switch on base plate set to RS-422A and that Switches 4 & 5 of DIP switch set as shown. COMMISIONING Connect dome and Rx100 as shown. Link Rx100 video out to telemetry transmitter using coaxial cable. Power up Rx100 first, cable LED should blink.
- Page 14 Mark Mercer D250MPT The dome must be powered from a 120Vac supply. Data connection via 2 wire RS422 using terminal block from slip rings and J3 on the Rx100. Video connection from terminal block to ‘CAMERA’ BNC socket on the Rx100.
- Page 15 Dome cable Direct into J7 COMMISSIONING Connect dome and Rx100 as shown. Link Rx100 video out to telemetry transmitter using coaxial cable. Power up Rx100 first, cable LED should blink. Next, dome can be powered up and is immediately ready for use.
- Page 16 Dome cable Direct into J7 COMMISSIONING Connect dome and Rx100 as shown. Link Rx100 video out to telemetry transmitter using coaxial cable. Power up Rx100 first, cable LED should blink. Next, dome can be powered up at which point a self test operation is performed. The dome is ready for use when test is completed.
- Page 17 The dome must be powered from a 24Vac supply. Data connection via 2 wire RS422 using screw terminals on dome back box and J3 on the Rx100. Video connection from BNC socket on dome back box to ‘CAMERA’ BNC socket on the Rx100.
- Page 18 Note: Very high speed, ‘Turbo mode’ can be enabled when joystick moved to limits by fitting the OPTION LINK to J6 of Rx100. If the link is removed then standard speeds will be used. Turbo mode speed is used when responding to an alarm activation.
- Page 19 The dome must be powered from a 12Vdc supply. Data connection via 3 wire RS422 using DB9 female to supplied dome cable and J3 on the Rx100. Video connection from BNC socket on dome base to ‘CAMERA’ BNC socket on the Rx100.
- Page 20 See SETUP section earlier in this manual for correct indication. If the problem persists having followed the above steps, technical assistance can be received from Building Block Video. Tel: +44 (0)1323 444600 Rx100 manual Appendix B – Trouble Shooting Page B-1...
