Quick Links

ThingSpace
Global Asset Tracker
Device Guide
Important—Please Read
Verizon Confidential & Proprietary.
© 2022 Verizon. All rights reserved.
Restricted and Controlled Distribution. Not to be used, copied, reproduced in whole or in part, nor its contents revealed in any manner to others without the express
written permission of Verizon.
All information herein is subject to change without notice. The information provided was considered accurate at the time the document(s) were developed, and
Verizon disclaims and makes no guarantee or warranty, express or implied, as to the accuracy or completeness of any information contained or referenced herein.
VERIZON DISCLAIMS ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE.
Verizon does not guarantee or warrant the availability of the network nor the compatibility of a network with any device, service or product. Verizon disclaims liability
for any damages or losses of any nature whatsoever whether direct, indirect, special or consequential resulting from the use of or reliance on any information
contained or referenced herein.
Technical data contained in this document may be subject to U.S. and international export, re-export, or transfer ("export") laws. Diversion contrary to U.S. and
international law is strictly prohibited.
Verizon and Verizon logos are trademarks of Verizon. Other product and brand names may be trademarks or registered trademarks of their respective owners.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ThingSpace and is the answer not in the manual?

Questions and answers

Summary of Contents for Verizon ThingSpace

  • Page 1 VERIZON DISCLAIMS ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE. Verizon does not guarantee or warrant the availability of the network nor the compatibility of a network with any device, service or product. Verizon disclaims liability for any damages or losses of any nature whatsoever whether direct, indirect, special or consequential resulting from the use of or reliance on any information contained or referenced herein.
  • Page 2: Table Of Contents

    Global Asset Tracker Contents Contents ........................................................2 Welcome ......................................................... 3 Device overview ....................................................4 LED Display Summary..................................................6 Off (Mode 0)....................................................6 Power Save Mode or PSM (Mode 1) ..........................................7 On (Mode 2) ....................................................8 Sensor information ................................................... 9 Unpacking your device ................................................. 10 Setting Up .......................................................
  • Page 3: Welcome

    Welcome The Verizon Global Asset Tracker is an IoT plug and play solution for quick deployment across multiple IoT use cases. It packages a device, ThingSpace Services and a Verizon data connectivity plan. It includes the following sensors: GPS, temperature, humidity, 3 axis accelerometer (shock and vibration), gyroscope (tilt), pressure, humidity, and light.
  • Page 4: Device Overview

    Global Asset Tracker Device overview Capability Description Network CAT-M1 Bands: 1, 2, 3, 4, 5, 8, 12, 13, 18, 19, 20, 26, 28 GPRS Bands: GSM850, EGSM900, DCS1800, and PCS1900 Battery Capacity: 4000 mAh Operating Voltage: >3.8 V Chemistry: Li-ion (rechargeable) Runtime: Up to 1-year battery life on a single charge Charging: Micro USB 2.0 (type B receptacle) Max Charge Rate: 1.2 A...
  • Page 5 Global Asset Tracker Status Button Short press of Status button : Pressing the button for 2 seconds toggles radio power. Allow several seconds after button is recognized for the radio to complete its power cycle. Long press of STATUS button Pressing the button for 10 seconds performs a system reset, after which the radio powers on and performs sensor reporting as necessary.
  • Page 6: Led Display Summary

    Global Asset Tracker LED Display Summary Below are tables showing what the “Power” and “Status” LEDs will display in the 3 modes of operation. Off (Mode 0) NOTE: There is no way to shut the device off. Mode 0 is when the battery has become fully discharged. Operational state Power LED Status LED...
  • Page 7: Power Save Mode Or Psm (Mode 1)

    Global Asset Tracker Power Save Mode or PSM (Mode 1) NOTE: The only difference between LED displays for “On” and “PSM” is that status in PSM will only be displayed for 60 seconds after a short press of the status button Operational state Power LED Status LED...
  • Page 8: On (Mode 2)

    Global Asset Tracker On (Mode 2) Operational state Power LED Status LED Standby Any color (Red, Green or Yellow), any speed blinking Ready (Normal) – PSM active Any color (Red, Green or Yellow), any Any color (Red, Green or Yellow), any speed blinking speed blinking Ready (Normal) –...
  • Page 9: Sensor Information

    Global Asset Tracker Sensor information  Temperature Sensor temperature range: (-20C to 65C +/- 0.5C),-20 to 75 degrees Celsius.  Pressure: (300 – 1100 hPA)  Humidity (0% to 95% RH)  Light: 0k - 64k lux  Accelerometer: 3-axis: scalable up to +/- 16g ...
  • Page 10: Unpacking Your Device

    Global Asset Tracker Unpacking your device The package contains: Global Asset Tracker (Note, the battery is inside the unit) Dimensions: 119.5 x 62.5 x 22 mm Weight: 153g USB Cable USB Power Plug...
  • Page 11: Setting Up

    Global Asset Tracker Setting Up For best results follow the set-up order below. Charging the device Connect the AC adapter and USB cable. Connect the micro USB cable to the charger. Device: Attach the micro USB end to the charging port on the end of the device: 3.
  • Page 12: Device Placement

    Global Asset Tracker Device placement Considerations for the best GPS performance:  The device has an Omni-directional antenna for GPS and receives GPS signals from all 6 sides.  Connection to a satellite receiving longitude and latitude coordinates is required to receive GPS location data. ...
  • Page 13 Global Asset Tracker Location: Tracking GPS location of a pallet shipment on a truck or ground based transportation  For best reception, place device closest to the end of the truck/transport, near the door.  Do not enclose in a metal based package or material, as this can interfere with cellular and GPS signals. ...
