- Page 1 VISIRUN Installation Manual...
- Page 2 V I S I R U N Installation Manual v1.16 Installation Manual v1.16...
-
Page 3: Table Of Contents
Table of Contents Table of Contents ..........................2 Security warnings ..........................3 Package contents ..........................4 Important notes for the installer ......................5 GPS tracker configuration ........................5 GPS tracker positioning ........................5 GPS tracker installation ........................6 GPS/GSM combined Antenna connection and positioning ..............7 GPS tracker fastening ........................... -
Page 4: Security Warnings
Security warnings Consider these security warnings when you install, use and maintain the B1N / B2 / R1N-T products. A. Electronic medical devices In hospitals or in other medical infrastructures, follow the local instructions regarding cellular mobile devices. Radiofrequency waves emitted by the product could interfere with electronic medical devices, pacemakers o other devices used by patients. -
Page 5: Package Contents
Package contents The Visirun GPS tracker kit is composed by: 1. Visirun GPS tracker (B1N / B2 or R1N-T model, see page 17) 2. GPS/GSM combined Antenna with black cable (3m length) 3. Power cable (2m length) with 16-pin MOLEX connector ready for connection to a permanent power source of 12/24V, ignition connection, digital inputs, digital outputs and analog inputs, primary CAN-BUS interface for B2 model. -
Page 6: Important Notes For The Installer
Important notes for the installer IMPORTANT NOTE The product installation must be performed by a qualified technician who must follow the instructions reported in the manual. GPS tracker configuration The Visirun GPS tracker is fully configured and ready to use. It is identified by a SERIAL NUMBER reported on a label on the top side. -
Page 7: Gps Tracker Installation
GPS tracker installation 1. Plug the 16-pin MOLEX into the CN1 socket on the back of the GPS tracker (in B2 model CN1 socket is the farthest socket from the BLUE PURPLE FAKRA sockets) 2. Connect the and BLACK wires to the vehicle's power supply of 12 or 24V DC. The GPS tracker power cable already includes a FUSE. -
Page 8: Gps/Gsm Combined Antenna Connection And Positioning
GPS/GSM combined Antenna connection and positioning The supplied GPS/GSM Antenna consists of: • GPS / GSM signal reception rounded element • 3m dual wire connection cable • 2 FAKRA connectors: o BLUE FAKRA for GPS signal PURPLE FAKRA for GSM signal To connect the GPS/GSM Antenna to the Visirun tracker: 1. -
Page 9: Installation Check
Installation check You can use the diagnostic LEDs to verify if the device is properly installed and working. • LEFT LED (GPS): if the GPS satellites signal is properly acquired • CENTRAL LED (BATTERY): ORANGE while charging the internal battery, GREEN when battery is fully charged... -
Page 10: Gps Tracker Activation
GPS tracker activation The GPS tracker is already fully configured and ready to use. Go to www.visirun.com to pair the Visirun GPS tracker with the vehicle on which it is installed. 1. Click on [LOGIN] and enter your E-MAIL and PASSWORD. 2. - Page 11 If you want to pair the just installed tracker with an existing vehicle 6. Click on the vehicle's name 7. Click on [Pencil] on the right of the [gps device] field and select the SERIAL NUMBER of the Visirun GPS tracker you have just installed 8.
-
Page 12: Optional Connections
Optional connections The Visirun GPS tracker allows the following optional connections: DESCRIPTION CASES OF USE CONNECTION Driver Recognition, K-Line Interface (B2 model only) CN2, pin 20 and 15. Reading real-time data from See circuit diagram on page 15 digital tachograph RECOMMENDED OPTION Primary CAN-BUS interface (B2 model Reading real-time data from CAN-... - Page 13 Additional accessories are available and can be easily connected through the quick lock circular connector or MOLEX connector: On board Terminal/ GPS Navigator Security Kit with Numeric Keypad Operators' recognition and attendance management Kit Tachograph Remote Download Kit Mobile Document Scanner B2 model only B2 model only The keypad and Operator’s recognition and attendance...
-
Page 14: General Connection Schemes
General connection schemes For detailed information about accessories installation, refer to the provided additional documentation. Installation Manual v1.16... -
Page 15: Real-Time Data From Digital Tachograph Via K-Line
Real-time data from digital tachograph via K-Line Direct connection via K-Line allows Visirun GPS tracker to read real-time data from digital tachographs, including driver recognition and state. The direct connection is available only for the B2 model: 1. Connect pin 15 of the CN2 connector (BLUE / BLACK wire) to pin 8 of the D connector on the back of the tachograph. -
Page 16: Tachograph Remote Download Kit
Tachograph Remote Download Kit The Tachograph Remote Download Kit allows the Visirun GPS tracker to remotely download data from digital tachographs, both Vehicle Unit and Driver Card, without the need to go on board of each vehicles. This kit is available only for the B2 model. Connect the Remote Download cable according to the following scheme: plug the red AMP connector into the C connector on the back of the Tachograph and connect the two wires to pin 9 and 10 of the GPS tracker:... -
Page 17: Ip67 Outdoor Kit
IP67 Outdoor Kit The IP67 Outdoor Kit is designed to install the GPS tracker onto trailers, containers, swap bodies, and construction site equipment with no cab or no permanent power supply. The kit includes an IP67 waterproof enclosure for outdoor use and a long-life battery guaranteed to run 45 days. The device is configured to minimize power consumption when external power is not present (e.g.: trailer detached from tractor). -
Page 18: Ip67 Outdoor Kit For Containers
IP67 Outdoor kit for Containers IP67 Outdoor kit for Containers is a special version of the IP67 Outdoor kit with additional features: • Internal GPS/GSM Antenna • Extended internal battery for tracking without external power • Powerful internal magnets to temporarily install the tracker on metal (ferromagnetic) surface IMPORTANT NOTE IP67 Outdoor kit for Containers embeds powerful internal magnets: do not bring this tracker closer to devices and systems that can be damaged by magnetic field, e.g.: credit cards and... -
Page 19: Mobile Document Scanner
Mobile Document Scanner Mobile Document Scanner allows the driver to acquire paper documents that will be available as a digital copy in the Document section of Visirun. The kit is available only for the B2 model and it is composed by: 1. -
Page 20: Mobile Document Scanner Installation
Mobile Document Scanner installation To complete the installation of the Mobile Document Scanner : • Connect the 5-pin MOLEX to USB cable (3) to the 5-pin MOLEX socket of the GPS tracker. • Connect the USB Scanner cable (2), plug the mini-USB connector to the scanner (1) and the other end to the 5-pin MOLEX to USB cable (3). -
Page 21: Gnu Licenses For B2/B1N/R1N-T Tracker
GNU Licenses for B2/B1N/R1N-T tracker The software included in this product contains copyrighted software that is licensed under: GNU General Public License version 2 (GPLv2), find a copy of the licese at https://www.gnu.org/licenses/gpl-2.0.html GNU Lesser General Public License version 2.1 (LGPLv2.1), find a copy of the licese at https://www.gnu.org/licenses/lgpl-2.1.html You may obtain the complete Corresponding Source code from us for a period of three years after our last shipment of this product, by sending a written request to:... - Page 22 Installation Manual v1.16...
- Page 23 Installation Manual v1.16...
- Page 24 Installation Manual v1.16...
- Page 25 Installation Manual v1.16...
- Page 26 Installation Manual v1.16...
- Page 27 Installation Manual v1.16...
- Page 28 Installation Manual v1.16...
- Page 29 Installation Manual v1.16...
- Page 30 Installation Manual v1.16...
- Page 31 [Page intentionally left blank] Installation Manual v1.16...
- Page 32 [Page intentionally left blank] Installation Manual v1.16...
- Page 33 [Page intentionally left blank] Installation Manual v1.16...
- Page 34 Customer Care helpdesk@visirun.com +39 (0)532 52570 Monday-Friday 9-18 +39 (0)532 1920231 www.visirun.com Installation Manual v1.16...
