This manual contains important safety information
concerning the maintenance, use and operation of this
product. Failure to follow the instructions contained in this
manual may result in serious injury. If you're unable to
understand the contents of this manual, please bring it to
the attention of your supervisor. Do not operate this
equipment unless you have read and understood the
contents of this manual.
Ultra-Glo
UGMW-1 Series
Installation &
Operating Manual
I&W #07.05.174.00
™
Este manual contiene importante información sobre
seguridad concerniente al mantenimiento, uso y
operación de este producto. Cualquier falla en el
seguimiento de las instrucciones contenidas en este
manual puede resultar en un serio daño. Si usted no
puede entender el contenido de este manual por
favor pregunte a su supervisor. No opere este
equipo al menos que haya leído y comprendido el
contenido de este manual.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hatco Ultra-Glo UGMW-1
Summary of Contents for Hatco Ultra-Glo UGMW-1
- Page 1 Do not operate this equipment unless you have read and understood the contents of this manual. Ultra-Glo ™ UGMW-1 Series Installation & I&W #07.05.174.00 Este manual contiene importante información sobre seguridad concerniente al mantenimiento, uso y operación de este producto.
-
Page 2: Table Of Contents
(identification decal located on the unit), voltage and purchase date of your Merchandising Warmer in the spaces below. Please have this information available when calling Hatco for service assistance. Model No. ________________________________ Serial No. ________________________________ Voltage __________________________________ Date of Purchase __________________________... -
Page 3: Important Safety Information
Some aftermarket or generic replacement parts do not have the characteristics that will allow them to operate safely in Hatco equipment. It is essential to use Hatco Replacement Parts when repairing Hatco equipment. Failure to... -
Page 4: Model Description
Damage to countertop material such as Corian and similar products caused by heat generated from Hatco equipment is not covered under the Hatco warranty. Contact the manufacturer of the base material for application information. MODEL DESCRIPTION ULTRA-GLO™... -
Page 5: Specifications
NEMA 5-15P Plug unit into a properly grounded electrical outlet of the correct voltage, size and plug Receptacle not supplied by Hatco. configuration. If the plug and receptacle do not match, contact a qualified electrician to Figure 2. Plug Configuration determine the proper voltage and size and install the proper electrical outlet. -
Page 6: Installation
70°F (21°C). NOTICE Damage to countertop material such as Corian and similar products caused by heat generated from Hatco equipment is not covered under the Hatco warranty. Contact the manufacturer of the base material for application information. ®... -
Page 7: Assembly
ASSEMBLY OF BREATH PROTECTORS Breath protectors are standard equipment on the UGMW-1. Refer to Figure 5 and follow these steps for installation. 1. Remove protective paper from the three breath protectors. 2. To install a side, loosen and remove the four screws from underside of the top housing. -
Page 8: Operation
OPERATION GENERAL The main power of the Merchandising Warmer is controlled by the ON/OFF rocker switch. The switch must be in the ON position for the unit to function. Allow 20-30 minutes temperature. NOTE: Upper heating elements are controlled by an infinite switch located at the rear base. -
Page 9: Maintenance
Some aftermarket or generic replacement characteristics that will allow them to operate safely in Hatco equipment. It is essential to use Hatco Replacement Parts when repairing Hatco equipment. Failure to use Hatco Replacement Parts may subject operators of the equipment to... -
Page 10: Accessories
ACCESSORIES 4-ROW RISER AND FRONT TRIVET RACKS 4-row riser trivet rack is available for conveniently displaying any food item on the front and sides of the Merchandising Warmer. Part Number 04.19.1126.00 Part Number 04.19.1127.00 Figure 7. 4-Row Riser and Front Trivet Form No. -
Page 11: Hatco Limited Warranty
Hatco reserves the right to accept or reject any such claim in whole or in part. Hatco will not accept the return of any Product without prior written approval from Hatco, and all such approved returns shall be made at Buyer’s sole expense. -
Page 12: Authorized Parts Distributors
Flanders GCS Service Indianapolis 317-545-9655 P.O. Box 340500, Milwaukee, WI 53234-0500 U.S.A. Parts & Service Fax (800) 690-2966 Printed in U.S.A. March 2007 HATCO AUTHORIZED PARTS DISTRIBUTORS NEW YORK Acme American Repairs, Inc. 319-323-1823 Brooklyn Alpro Service Co. 515-262-9308 Brooklyn...
