Hatco 3CS2-3 Replacement Parts List Manual page 3

ITEM DESCRIPTION
1 Temperature Probe
2 Probe, Low Water Cut Off
3 Ball Valve, Threaded
4 Ball Valve Handle
5 Ball Valve, Hex Extension
6 Ball Valve, Stop Plate
7 3" (8 cm) Valve Extension
8 3/4" x 3/4" Brass Hex Nipple
9 O-Ring
10 Hose Clamp, S.S. with Liner
11 Inlet Hose
12 Outlet Hose
13 Rubber Gasket
14 Keps Nut
15 Rod, Threaded
16 Low Water Cut Off, 24 Volt
17 Contactor - 3 Pole
18 Fuse, 2 Amp (2 per pack)
19 Fuse Block
20 Transformer, 208/240 - 24 Volt 02.17.044.00
21 On/Off Switch
Note: S.S. is an abbreviation for stainless steel.
! Includes all gaskets for both strainers.
Form No. 3CS-2RP-0801
PARTS COMMON TO ALL 3CS-2 MODELS
PART NO. QTY. ITEM
02.01.166.00 1 22
02.40.015.00 1
03.02.001.00 1 23
03.02.001B.00 1
03.02.029.00 1 24
25
03.02.030.00 1
03.02.031.00 1
03.05.057.00 1 26
27
03.40.059.00 2-6
03.40.061.00 4 28
03.40.062F.00 1 29
30
03.40.062R.00 1
05.06.006.00 1 31
05.04.205.00 4 32
05.04.419.00 2 33
02.01.148.00 1 34
02.01.167.00 1 35
R02.03.014.02 1 36
02.03.022.00 1 37
38
1
02.19.081.00 1 39
3
DESCRIPTION PART NO.
Electronic Temperature
Controller 02.01.165S.00
Strainer Assembly with
Gaskets R05.30.009.00
Terminal Block with Pins R02.15.035.00
Brass Hose Connector
with Shoulder 03.05.058.00
Cleaning Brush 03.40.060.00
Flush Hose Assembly 05.06.010.00
1-3/8" (4 cm) Rubber Stopper 05.06.026.00
Union Gasket 05.06.009.00
Strainer Gasket Kit! R00.05.0002.00
Brass Locknut 05.30.009A.00
Jacket, Black 04.06.220.00
Front Head Strap 04.06.223.00
Rear Head Strap 04.06.224.00
Side Panel, Black 04.06.222.00
Bottom Access Panel, Black 04.06.228.00
Front Control Panel 04.06.221.00
Top Assembly, S.S. 04.06.225.00
Drain Switch Kit R02.19.162.00
QTY.
1
2
1
1
1
1
1
1
1
2
1
2
2
2
1
1
1
1
Printed in U.S.A.
