Product Overview
No.
Item
1
Terminal
2
Guide-Pins
3
Elevator Foot
4
Protect-Pins
5
VGA Port
6
USB ports
7
HDMI port
8
LAN (RJ-45) port
9
Serial port (RS-232)
10
DC-in jack *
*Please contact dealer for appropriate adapter.
Docking the SA14S Notebook
1. Align the SA14S Notebook by the guide-pins and terminal contact and then place the SA14S Notebook
onto the docking cradle.
Be sure to insert the handle side first as shown the illustration.
2. Push the SA14S Notebook down firmly until it clicks into place.
OD-SA14S – Office Docking
Docking
62+009666+00
Advertisement
Table of Contents
Related Manuals for Durabook OD-SA14S
Summary of Contents for Durabook OD-SA14S
- Page 1 OD-SA14S – Office Docking Docking Product Overview Item Terminal Guide-Pins Elevator Foot Protect-Pins VGA Port USB ports HDMI port LAN (RJ-45) port Serial port (RS-232) DC-in jack * *Please contact dealer for appropriate adapter. Docking the SA14S Notebook 1. Align the SA14S Notebook by the guide-pins and terminal contact and then place the SA14S Notebook onto the docking cradle.
- Page 2 OD-SA14S – Office Docking Docking Undocking the SA14S Notebook 1. Push the bottom side of the SA14S Notebook upwards to disengage the connection. Be sure the device is properly turned off. 2. Lift to remove the SA14S Notebook. Note: ...
