- Page 1 M121系列 使用说明书 INSTRUCTION MANUAL INSTRUCTION MANUAL No:M121A01 No:M121A01 Read safety Instructions carefully and understand them before using. Retain this Instruction Manual for future reference. 为了安全地使用，请您在使用之前仔细阅读本使用说明书。 另外，请您注意保管本使用说明书，以便随时查阅。...
- Page 2 GOLDEN WHEEL M121 系列使用說明書 啓翔股份有限公司 M121 SERIES INSTRUCTION MANUAL CHEE SIANG INDUSTRIAL CO., LTD 台灣新北市 24248 五股區五股工業區 目次 CONTENTS 五權七號 32 號 1．安全注意事項 Tel：886-2-22999518 Fax：886-2-22999519 1．Safety Precaution 2．安裝與調整 2．Installationand Adjustment ※本說明書內容及規格如有變更不另行通知。 3．插孔配置 3．Connector Diagram No.32, Wu Chuan 7th Road, Wu Ku Industrial Area, 4．面板・按鍵功能...
- Page 3 ・Don’t operate in direct sun light, outdoors area and the room temperature is 40°C above or 5°C under. ・Don’t operate near the heater, dew area and the humidity is 20 % less or 80% more. ・Don’t operate in dusty, evaporate, combustible gas area, and stay away from corrosive material. ・Avoid power cord being applied by heavy objects or excessive force, or over bend.
- Page 4 2. 安裝與調整 2. Installation and Adjustment ２.１. M121 安裝 2.1. M121 Installation a)．M121 控制箱請安裝於機桌下。 c)．踏板開關、馬達出力、馬達編碼器的電線請確實 b)．踏板開關請安裝於台板下的踏板上方位置。 a). Install the M121 controller under 連接至 M121 控制箱背面。 b) Install the pedal to the speed the table. ※詳細資料請參考 3．插頭配置。 controlunit of M121 controller. c).
- Page 5 ２.３. 調整踏板 2.3. Speed Control Unit Adjustment 警告： 為了安全起見，進行各調整前請關閉電源開關， 並拔下電源插頭。 Caution : For person safety, turn off the power switch and remove the power plug from outlet before any adjustment. decrease increase ３．插孔配置 輕 重 Ｂ 3. Connector Diagram 踏板的各部位名稱 Components of speed control unit : see figure 馬達出力...
- Page 6 ４．面板・按鍵功能 4. PanelKey Function 各操作按鍵的功能 The function of each key 馬達回轉 F 鍵 參數設定模式切換／ 針位置上停止 方向表示 Needle up Motor rotation "F" Key 參數代碼增加／ direction icon 參數値增加／ 針位置下停止 Needle down 回復正常模式 Change to the parameter F 鍵 SET 鍵 setting mode/ Function key Needle down Increment "Parameter code"/...
- Page 7 Parameter Parameter function Range / Selection Unit Remarks code Maximum sewing speed The value of [B.1] is a maximum. The value of [A.2] is a minimum. 2 ～ [B.1] 100r/min (Digit of 10 of the low-speed setting is not displayed)※1,※2 Low speed 20 ～...
- Page 8 ６．錯誤代碼 6. Error Code /Alarm Code ６.１. 錯誤代碼表（須強制停止運轉的錯誤） 要檢查錯誤時，須先將馬達強制停止。 顯示表示部的錯誤代碼。 6.1.Error Code List (The error which forced stop of the operation) When the control box detects an error, forced stop of the motor is carried out. "Errorcode" is displayed on the panel display. 錯誤代碼...
- Page 9 Error Error name Cause of the problem Status and Measurement code Motor Wiring on the motor short-circuited. Please check wiring on the motor. over-current The load torque of the sewing machine istoo Please check the sewing machine. large. Wiring of the motor has disconnected one or two. Motor control IC Motor control IC detects Motor over-current.
- Page 10 ６.２. 警報代碼表（可以解除的警報） 檢測警報時，所顯示的警報代碼。 繼續運作時，必須注意警報的發生原因。 6.2.Alarm Code list(Alarm Release is possible.) When the control box detects an alarm, "Alarmcode" is displayed on the panel display. If you want to continue to operate, you need to pay attention to the cause of the alarm. 錯誤代碼...
- Page 11 启 翔 股 份 有 限 公 司 CHEE SIANG INDUSTRIAL CO., LTD. No.32, Wu Chuan 7th Road, Wu Ku, Wu Ku District 24890, New Taipei City, Taiwan.
