Philips Consumer Lifestyle
Service Manual
PRODUCT INFORMATION
Fast & powerful crease removal
- Soleplate: SteamGlide
- OptimalTemp
- Continuous steam output
- Continuous steam output: 120 g/min
- Steam boost: 220 g
- Vertical steam
- Steam pressure: Up to 5 bar
- Steam tip
- Power: 2400 W
Easy to use
- Water tank capacity: 2200 ml
- Filling and emptying water: Extra large filling hole
- Refill any time
- Heat-up time: 2 min
- Safety auto off
- Storage solution: Carry lock
- Hose storage: Hose storage compartment
- Power cord length: 1.8 m
- Hose length: 1.6 m
- Safe for all fabrics: Even for delicates like silks
- Low water alarm
Calc management
- Suitable for tap water
- Calc clean solution: Easy De-calc
- Calc clean reminder
Safety Information
This product meets the requirements regarding interference suppression on
-
radio and TV.
- After the product has been repaired, it should function properly and has
to meet the safety requirements and legal regulations as officially laid
down at this moment.
TECHNICAL INFORMATION
Voltage
: 220 - 240 V
Frequency
: 50 - 60 Hz
Power
: 2400 W
Dimension (F-box)
: 362 (D) x 270 (W) x 263 (H) mm
Weight of iron
: 1 kg
Weight of iron + base
: 4.5 kg
Water Advice
Suitable for tap water use. Advice to mix with equal portion of distilled
water or use only distilled water if the tap water is very hard.
Soleplate: Steam Glide
New SteamGlide soleplate is the best Philips soleplate. It has great scratch
resistancy, glides excellent and is easy to clean.
OptimalTemp Technology
-
Always deliver 1 perfect setting for all your clothes thanks to:
1.
Cylonic steam chamber
2.
Advance Smart control processor
-
100% easy to use, no adjustment required.
-
100% safe on all delicate fabrics.
-
100% fast on the toughest fabrics.
Tested and approved by experts
Tested and approved by independent textile experts institutes.
Steam pressure: Up to 5 bar
Double your ironing speed with pressurized steam.
2.2L fully visible water tank
Large water tank ensures long hours of ironing without refill of water
tank.
Lock your iron securely
Lock your iron securely and carry your steam generator easily
Easy De-Calc
Easy De-Calc, hassle free & effective scale removal to extend the life of your
steam generator.
PerfectCare Aqua
GC8651
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Philips PerfectCare Aqua GC8651
Summary of Contents for Philips PerfectCare Aqua GC8651
- Page 1 Fast & powerful crease removal - Soleplate: SteamGlide Soleplate: Steam Glide - OptimalTemp New SteamGlide soleplate is the best Philips soleplate. It has great scratch - Continuous steam output resistancy, glides excellent and is easy to clean. - Continuous steam output: 120 g/min...
- Page 2 GC8651 DISASSEMBLY ADVICE - IRON Light strip cap assy 1 Ryton ring 10 Inlay and light strip assy 2 Deviator housing molded 11 Reflector molded 3 Iron thermistor assy 12 LED microswitch holder assy 4 Plstic washer (2x) 8 (Rear) Trigger spring 5 Hose cord mounted assy 14 Trigger molded 6...
- Page 3 GC8651 PART LISTS - IRON & ELECTRICAL DIAGRAM Service Code Description Light strip cap assy 423902170734 Inlay and light strip assy 423902170723 Reflector molded 423902649561 LED microswitch holder assy 423902171942 Trigger spring 423901454961 Trigger molded 423902649752 Mica plate 423901012911 Plastic washer 423902649501 Decoration cap printed 423902170741...
- Page 4 GC8651 EXPLODED VIEW - IRON...
- Page 5 GC8651 DISASSEMBLY ADVICE - STAND Filling door molded 17 Rear lock rubber 18 Power button printed 37 Button frame printed 38 Tray rubber cap 19 Power board PCB-Pump service kit 39 Tray cap molded 20 Tray printed 21 Power Cord EU 40 Front lock assy 22 Stand bottom molded 41 Remove...
- Page 6 GC8651 PARTS LIST – STAND Service Code Description 423902649714 Filling door molded 423901559741 Rear lock rubber 423901559731 Tray rubber cap 423902651831 Tray cap molded 423902170802 Tray printed 423902170783 Front lock assy 423902170812 Water tank assy 423902171672 Rinse cap assy 423901559791 Safety cap 423901010261 Inox clamp 423901559771 Braided rubber hose Boiler 423901712802 Electrovalve...
- Page 7 GC8651 EXPLODED VIEW - STAND...
-
Page 8: Wiring Diagram
GC8651 WIRING DIAGRAM... -
Page 9: Repair Instructions
GC8651 REPAIR INSTRUCTIONS Due to the high wattage of the iron, only the specified cord set must be used. • Should damage be observed on the HOSE-CORD ASSY or CORDSET 14, they must be replaced. Continued usage is not allowed. •...
Need help?
Do you have a question about the PerfectCare Aqua GC8651 and is the answer not in the manual?
Questions and answers
не идет пар,в корпусе что-то щелкает
The Philips PerfectCare Aqua GC8651 may produce no steam and a clicking sound due to the following reasons:
1. Water Tank is Empty – The steam generator needs water to produce steam. Ensure the water tank is filled.
2. Calc Cleaning Needed – If there is too much scale buildup, the steam may not be generated properly. Use the Easy De-calc function to clean the system.
3. Heat-Up Time Not Completed – The iron requires about 2 minutes to heat up. Wait until it reaches the required temperature.
4. Auto Safety Shut-Off Activated – If the iron has been left unused for some time, it may have switched off automatically. Turn it on again.
5. Pump Operating Normally – The clicking sound may be the pump drawing water into the steam chamber. If there is no steam despite this, check if the steam function is activated.
If the issue persists, further troubleshooting or professional servicing may be required.
This answer is automatically generated
