- Page 1 RANGEHOOD & INSTALLATION GUIDE UM-12UMS www.schweigen.co.nz...
-
Page 2: Table Of Contents
Flexible Ducting __________________________________________________________________________ 17 Isodrive Motor Setup ______________________________________________________________________ 18 Overview ________________________________________________________________________________ 19 8. Maintenance Condensation Information ________________________________________________________________ 20 Troubleshooting _____________________________________________________________________________________________ 22 Technical Specifications __________________________________________________________________ 22 Faulty Installation _________________________________________________________________________ 23 9. Specification UM-12UMS ___________________________________________________________________________________________________ 24 10. Disclaimer ___________________________________________________________________________________________________ 25 Page 2... -
Page 3: Welcome
The guide contains important information on the use and maintenance of the unit, as well as important safety notes. This will ensure your personal safety and the lasting value of your rangehood. We trust that you will enjoy your new Schweigen rangehood. Please always retain your proof of purchase to aid in any warranty queries. -
Page 4: Your Safety
2. Your Safety WARNING Please read this section thoroughly before attempting to operate the appliance. Inspect your product upon receipt. Any damage or defects MUST be reported within 48 hours, or no claim will be recognised. DO NOT INSTALL THIS APPLIANCE IF YOU FIND IT DAMAGED. If this product is installed damaged, neither the supplier, nor the retailer, will be responsible for the costs associated with the repair, replacement, removal or re-installation of the appliances. -
Page 5: Before Installation
2. Your Safety Before Installation We recommend this appliance be installed or repaired by a qualified Schweigen Home Appliances technician. Please see our website www.schweigen.co.nz for recommended installers. It is dangerous to modify any part of this appliance. Modification of any kind, will immediately void the warranty. -
Page 6: Product Use
2. Your Safety Product Use This product is designed for household use and should not be used for commercial applications. After use, always ensure that all controls are in the “OFF” position. When frying with a gas flame, take particular care not to allow the oil or grease in the pan to catch fire. -
Page 7: Tips And Suggestions
3. Tips & Suggestions The Rangehood has one mode of operation: Air extraction: The air is drawn in and cleaned by the grease filters and directed outside. Please check the cleaning and maintenance section for the filters’ cleaning periods. For Users 1. -
Page 8: Description
4. Description Main Rangehood For use with Isodrive motor system Male Plug (Main Power 240V) Single 200mm Outlet Reducer (For Isodrive 650 only) Filters Lamp (For GU10 fittings, please twist to remove) NOTE: Filter and light quantity may vary from model to model. -
Page 9: Operation
5. Operation Schweigen silent rangehoods are recognised for their silent operation. Although this holds true for all of our rangehoods with external motors, one must note that the rangehoods are silent when they are used for regular cooking on the lower fan setting. Therefore, you will only hear the movement of air. -
Page 10: Cleaning And Maintenance
6. Cleaning & Maintenance WARNING Always switch off and disconnect power before cleaning. Surfaces Wash with warm soapy water and a soft sponge. Never use abrasive detergent, scouring pads, steel wool or solvents on any part of this appliance, Always make sure to dry the appliance after cleaning and never leave wet, as this will cause irreparable damage. -
Page 11: Cleaning The Interior
6. Cleaning & Maintenance WARNING • If the grease filters are very dirty, the motor will extract only a small quantity of air, which reduces its efficiency; • The grease deposits that build up on the filter are highly flammable and COULD EASILY CATCH FIRE. -
Page 12: Cleaning The Exterior
6. Cleaning & Maintenance Cleaning the Exterior We recommended using a soft cloth, warm water and a liquid soap to clean the exterior. Rinse with clean water and ensure that the appliance is completely dry after cleaning. For better results, you can use high quality cleaning and protection products (eg. -
Page 13: Replacing The Light Bulb
6. Cleaning & Maintenance Replacing the Light Bulb DANGER Always switch off and disconnect the power cord before replacing any light bulbs. Failure to do so may cause serious injury. Please be aware that the light bulb will retain heat for a short period of time after being switched off. Step 1 Step 2 Step 3... -
Page 14: Installation
7. Installation DANGER Always switch off and disconnect power before installing the rangehood. Failure to do so may cause serious injury. Cabinet Cutout Size Present the rangehood to your cabinet maker so that they may take their own measurements and check that the rangehood fits in the cabinet correctly. -
Page 15: Mounting Points
7. Installation WARNING If the user decides to install the rangehood at a distance of less than minimum height above the cooking surface, the Measurements are from company declines responsibility the top of the trivets to for damages suffered by the the lowest part of the rangehood due to excess heat rangehood, including... -
Page 16: Optional Install Example
7. Installation TOP VIEW Optional Install Example WARNING Please remove filters before installation. Failure to do so may damage the clips. BOTTOM VIEW FRONT VIEW Step 1 Insert support frame into cabinet. The support will only be needed in certain circumstances. NOTE: The support frame is not included. -
Page 17: Flexible Ducting
7. Installation Flexible Ducting For the Isodrive motors, please do not crush or kink any of the flexi ducting, this will reduce the air flow and may cause noise throughout the system. Ducting needs to be kept taut at all times. Please refer to the Isodrive motor installation guide for more details on flexi ducting with the silent system. -
Page 18: Isodrive Motor Setup
7. Installation Isodrive Motor Setup IMPORTANT Please remove the clip when attaching Isodrive 1600 / 3200 motor (Single or Twin) system. To remove the clip, hold down 1, 2 and 3 gently pull out to direction 4. NOTE: DO NOT REMOVE the clip at the end of the white cord when installing an Isodrive 650 / 900 motor (Single or Twin) system. -
Page 19: Overview
7. Installation Overview WARNING All electrical wiring should be kept inside the roof space. Isodrive Motor Roof Seal Kit (Dektite)* Support Straps* Attach Flexi Duct to Bell-Mouth Adaptor using duct tape and cable tie. Please DO NOT rip the ducting. Motor Power Lead (Male Plug) Rangehood to Motor Lead (Female Plug) -
Page 20: Maintenance
8. Maintenance Condensation Information The induction cooktop is designed to provide rapid heating, improved thermal efficiency and greater heat consistency. For some customers with an induction cooktop, condensation can form on their rangehood filters while using their cooktop. The induction cooktops’ heat source is contained in the conductive base of the pot. When compared with a gas, electric or wok burner, the heat is not isolated or contained to one area and therefore gradually rises up on all sides of the pot or frypan. - Page 21 8. Maintenance User advice to avoid condensation in the rangehood: • The rangehood should be switched on approx. 10 minutes prior to cooking and the delay shut down timer set after cooking has stopped in order to clear the fumes held in the flue. These steps will help clear the flue out fully.
-
Page 22: Troubleshooting
Rangehood air suction is weak Rangehood does not direct air out (through chimney) Loud noise from the rangehood Technical Specifications Model UM-12UMS Feeding Voltage 220-240V 50Hz Lamp Power — Halogen (W) 2 x 35W (optional) Lamp Power — LED (W) 2 x 3.8W (supplied) -
Page 23: Faulty Installation
It is not the responsibility of Schweigen Home Appliances to rectify any incorrect installations. A service call out fee will be charged for any Schweigen technician that attends a call, whereby it’s established that the fault is due to an incorrect installation or non-manufacturing fault. Should the appliance be installed in such a way that the service agent is unable to gain access to the appliance, the person/s who own the premises or the appliance where the appliance resides —... -
Page 24: Specification
9. Specification 1160 358.5 1200 Page 24... -
Page 25: Disclaimer
In no event will Schweigen Home Appliances be responsible for damages of any nature whatsoever resulting from the use of, or reliance upon, information from their website or the products to which the information refers. - Page 26 Notes Page 26...
- Page 27 Page 27...
- Page 28 Australia 8/3-4 Anzed Court, Mulgrave 3170 Victoria. Phone 1300 881 693 Email sales@schweigen.com.au Web www.schweigen.com.au New Zealand 5 Tolich Place, Henderson, Auckland 0610. Phone 0800 200 510 Email info.parex@emerson.com Web www.parex.co.nz Distributed by Axis Group International Pty Ltd. ACN 124 141 322...
