- Page 1 Rangehood & installation guide uM1170-9s Revision V4.2 HOME APPLIANCES www.schweigen.com.au...
-
Page 2: Table Of Contents
index 1. Welcome ____________________________________________________________________________________________________ 3 2. Your Safety safety advice ____________________________________________________________________________ 4 Before installation __________________________________________________________________________________________ 5 Product use ______________________________________________________________________________ 6 Maintenance and service ________________________________________________________________________________ 6 electrical Cord ______________________________________________________________________________________________ 6 3. Tips and Suggestions For users _________________________________________________________________________________ 7 For installers and users ____________________________________________________________________ 7 4. -
Page 3: Welcome
We trust that you will enjoy your new schweigen rangehood. Please always retain your proof of purchase to aid in any warranty queries. -
Page 4: Your Safety
2. Your safety WarnIng Please read this section thoroughly before attempting to operate the appliance. inspect your product upon receipt. any damage or defects MUST be reported within 48 hours, or no claim will be recognised. DO nOT InSTaLL THIS aPPLIanCE IF YOU FInD IT DaMagED. if this product is installed damaged, neither the supplier, nor the retailer, will be responsible for the costs associated with the repair, replacement, removal or re-installation of the appliances. -
Page 5: Before Installation
2. Your safety Before Installation We recommend this appliance be installed or repaired by a qualified schweigen home appliances technician. Please see our website www.schweigen.com.au for recommended installers. it is dangerous to modify any part of this appliance. Modification of any kind, will immediately void the warranty. -
Page 6: Product Use
2. Your safety Product Use this product is designed for household use and should not be used for commercial applications. after use, always ensure that all controls are in the “oFF” position. When frying with a gas flame, take particular care not to allow the oil or grease in the pan to catch fire. -
Page 7: Tips And Suggestions
3. tips & suggestions the Rangehood has one mode of operation: air extraction: the air is drawn in and cleaned by the grease filters and directed outside. Please check the cleaning and maintenance section for the filters’ cleaning periods. For Users 1. -
Page 8: Description
4. description Main rangehood For use with isodrive motor system Male Plug (Main Power 240V) single 200mm outlet Reducer (For isodrive 650 only) Filter lamp (For gu10 fittings, please twist to remove) nOTE: Filter and light quantity may vary from model to model. -
Page 9: Operation
5. operation schweigen silent rangehoods are recognised for their silent operation. although this holds true for all of our rangehoods with external motors, one must note that the rangehoods are silent when they are used for regular cooking on the lower fan setting. therefore, you will only hear the movement of air. -
Page 10: Cleaning And Maintenance
6. Cleaning & Maintenance WarnIng always switch off and disconnect power before cleaning. Surfaces Wash with warm soapy water and a soft sponge. never use abrasive detergent, scouring pads, steel wool or solvents on any part of this appliance, always make sure to dry the appliance after cleaning and never leave wet, as this will cause irreparable damage. -
Page 11: Cleaning The Interior
6. Cleaning & Maintenance WarnIng • if the grease filters are very dirty, the motor will extract only a small quantity of air, which reduces its efficiency; • the grease deposits that build up on the filter are highly flammable and Could easilY CatCh FiRe. -
Page 12: Cleaning The Exterior
6. Cleaning & Maintenance Cleaning the Exterior We recommended using a soft cloth, water and a liquid soap, rinsing it well and then drying it thoroughly. For better results, you can use high quality cleaning and protection products (eg. steel Kleen) to clean your rangehood. -
Page 13: Replacing The Light Bulb
6. Cleaning & Maintenance replacing the Light Bulb DangEr always switch off and disconnect power before replacing the lights. Failure to do so may cause serious injury. Please be aware that the light bulb will retain heat for a short period of time after being switched off. Step 1 Step 2 Step 3... -
Page 14: Installation
7. installation DangEr always switch off and disconnect power before installing the rangehood. Failure to do so may cause serious injury. Cabinet Cutout Size a cardboard template is supplied showing the cabinet cutout size. Please use this as a guide when designing your cabinet. -
Page 15: Mounting Points
FRONT VIEW 7. installation WarnIng if the user decides to install FRONT VIEW the rangehood at a distance of less than minimum height above the cooking surface, the Measurements are from company declines responsibility the top of the trivets to for damages suffered by the the lowest part of the rangehood due to excess heat... -
Page 16: Optional Install Example
7. installation TOP VIEW Optional Install Example WarnIng Please remove filters before installations. Failure to do so may damage the clips. BOTTOM VIEW FRONT VIEW Step 1 the support frame is not included. the requirement of a support frame is dependent on the type and location of installation. -
Page 17: Flexible Ducting
7. installation Flexible Ducting For the isodrive motor, please do not crush or kink flexi ducting, as it will reduce air flow and may cause noise to occur through the system. ducting needs to be kept taut at all times. Please refer to the Isodrive motor installation guide for more details on flexi ducting with the silent system. -
Page 18: Isodrive Motor Setup
7. installation Isodrive Motor Setup ExTrEMELY IMPOrTanT Please read the following instructions carefully before install. For technical support, please contact 1300 829 066. IMPOrTanT Please remove the clip when attaching isodrive 1600 / 3200 motor (single or twin) system. to remove the clip, hold down 1, 2 and 3 gently pull out to direction 4. -
Page 19: Overview
7. installation Overview WarnIng all electrical wiring should be kept inside the roof space. isodrive Motor Roof seal Kit (dektite)* support straps* attach Flexi duct to Bell-Mouth adaptor using duct tape and cable tie. Please DO nOT rip the ducting. Motor Power lead (Male Plug) Rangehood to Motor lead (Female Plug) -
Page 20: Maintenance Condensation Information
8. Maintenance Condensation Information the induction cooktop is designed to provide rapid heating, improved thermal efficiency and greater heat consistency. For some customers with an induction cooktop, condensation can form on their rangehood filters while using their cooktop. the induction cooktops’ heat source is contained in the conductive base of the pot. When compared with a gas, electric or wok burner, the heat is not isolated or contained to one area and therefore gradually rises up on all sides of the pot or frypan. - Page 21 8. Maintenance User advice to avoid condensation in the rangehood: • the rangehood should be switched on approx. 10 minutes prior to cooking and the delay shut down timer set after cooking has stopped in order to clear the fumes held in the flue. these steps will help clear the flue out fully.
-
Page 22: Troubleshooting
8. Maintenance Troubleshooting If the product does not work: Before you contact the technical service department, make sure that the product is plugged in, the electric fuse (on selected models) is in correctly and electric wiring is connected. (Fuses can be purchased from your local electrical dealer or hardware store). -
Page 23: Faulty Installation
—... -
