BEFORE YOU CALL FOR SERVICE

If the oven fails to operate:
A) Check to ensure that the oven is plugged
in securely. If it is not, remove the plug
from the outlet, wait 10 seconds and plug
it in again securely.
B) Check for a blown circuit fuse or a tripped
main circuit breaker. If these seem to be
operating properly, test the outlet with
another appliance.
IF NONE OF THE ABOVE RECTIFIES THE SITUATION, THEN CONTACT A QUALIFIED
TECHNICIAN. DO NOT TRY TO ADJUST OR REPAIR THE OVEN YOURSELF.
Power Consu
Operation Frequency:
Outside Dimensions(H×W×D):
Oven Capacity:
Net Weight:
Note: The above data may be further confirmed or updated.

SPECIFICATIONS

mption:
Output:

PART NAMES

VENT COVER THAT IS INSIDE THE MICROWAVE!
C) Check to ensure that the control panel is
programmed correctly and the timer is
set.
D) Check to ensure that the door is securely
closed engaging the door safety lock
system. Otherwise, the microwave
energy will not flow into the oven.
120V~60Hz, 1500W (MICROWAVE)
11 13/16 21 1/4 15 11/16
Door Safety Lock System
1.
Oven Window
2.
Roller Ring
3.
Shaft
4.
5. Door release button
6. Control Panel
Wave Guide(Please do not remove the
7.
mica plate covering the wave guide).
Glass Tray
8.
DO NOT REMOVE THE CARDBOARD OVEN AIR
7
1000W
2450MHz
1.1cu.ft
Approx. 35.3lbs
in.
