Please read these instructions carefully to familiarize
yourself with the required tools, materials, and installation
sequences. Follow the sections that pertain to your
particular installation. This will help you avoid costly
mistakes. In addition to proper installation, read all
operating and safety instructions.
·
All information in these instructions is based upon the
latest product information available at the time of
publication. Kohler China reserves the right to make
changes in product characteristics, packaging, or
availability at any time without notice.
·
These instructions contain important care, cleaning, and
warranty information -
please leave instructions for the
consumer
.
ORDERING INFORMATION
REACH Skirted 2PC Toilet 305mm (HC)..............K-3991T-HC
Includes REACH Skirted Bowl
305mm(HC)......................................K-3836T-MHC
Includes REACH Tank
305mm(HC).......................................K-4979T-HC3
REACH Skirted 2PC Toilet 400mm (HC)..... K-4153T-HC
Includes REACH Skirted Bowl
400mm(HC)......................................K-4074T-MHC
Includes REACH Tank
400mm(HC).......................................K-4979T-HC4
NOTES
·
Observe all local plumbing and building codes.
·
Shut off the water supply.
·
Seat post holes are on 140mm centers.
·
Ensure that the new drain has the correct roughing-in
dimension. This toilet has a 305/400mm roughing-in
dimension.
See Roughing-in
·
Closet flange must be 305/400mm on-center from wall.
·
Carefully inspect the new fixture for any sign of damage.
No.2 KOHLER ROAD, SANSHUI CENTRAL INDUSTRIAL PARK, LEPING TOWN, SANSHUI DIST., FOSHAN, GUANGDONG, PRC POST CODE 528137
8# MENGSHAN RD, ECONOMIC DEVELOPMENT ZONE OF HUANTAI, ZIBO, SHANDONG, CHINA
NO.1 KOHLER STREET, ECONOMIC DEVELOPMENT ZONE OF FAKU COUNTY, SHENYANG LIAONING PROVINCE, PRC
1388677-T01-A
.
·
·
·
·
305mm
305mm
.............................................K-3836T-MHC
...................................
305mm
400mm
.................................
400mm
400mm
·
·
·
140mm
·
305/400mm(
·
·
2
528137
8
256410
1
110400
©
Copyright Kohler China Investment Co., Ltd. 2019
-1-
©
REACH
Installation INSTRUCTIONS
SKIRTED 2PC TOILET(HC)
(
S-TRAP 305mm K-3991T-HC
S-TRAP 400mm K-4153T-HC
(
)......K-3991T-HC
K-4979T-HC3
(
)..K-4153T-HC
K-4074T-MHC
..................
.
K-4979T-HC4
)
305/400mm
POST CODE:
256410
POST CODE:
)
-
:
110400
