TV Bedstore MONACO Assembly Instructions Manual

If Media Tray is wanted on
the left side, fit side rail (3)
to left and (4) to right.
(3)
An instructional video of the Operation of the Ottoman Lift Up system is available via YouTube using
the following addre ss: https://youtu.be/hyq4zm7h_yU
BT
OPT
MODE
MIN MAX
OFF/- VOL. +/ON
+
BASS
+
TREB.
L
R
TORCH
V1 210424
MONACO OTTOMAN TV BED
ASSEMBLY INSTRUCTIONS
(3)
LH - PLATFORM LED LIGHT --- RH - UNDERBED LED LIGHT (IF FITTED).
TV LIFT UP - TV WILL WORK NORMALLY
TV LIFT STOP
TV LIFT DOWN - TV WILL SWITCH OFF FOR SAFETY
NOTE: BLUETOOTH WILL WORK NORMALLY WHEN TV IS UP OR DOWN.
MIN MAX
1) PRESS ON BUTTON FOR 3 SECONDS TO START UP THE SYSTEM. RED
LIGHT ON SOUNDBAR IS LIT AND SYSTEM VOICE WILL TELL YOU
OFF/ VOL. ON
- +/
POWER IS ON, YOU CAN THEN OPERATE THE CONTROLS.
PRESS OFF BUTTON FOR 3 SECONDS TO CLOSE DOWN THE SYSTEM.
SYSTEM WILL ALWAYS START CONNECTED TO TV BY THE OPTICAL
BT OPT
CABLE SO YOUR OWN TV MUST HAVE AN OPTICAL PORT.
TOGGLE TO BT MODE, BLUE LIGHT ON SOUNDBAR LIGHTS UP. SYSTEM
MODE
VOICE WILL ANNOUNCE --- 'PAIRED' --- IF CONNECTED TO SAME DEVICE
PREVIOUSLY or IF NOT WILL SAY --- 'PAIRING' AS CONNECTION TAKES
PLACE. CONNECT DEVICE IN THE NORMAL WAY TO -- 'MY BT'
MIN MAX
-
ONCE SYSTEM IS ON, USE --- + or - --- BUTTON TO INCREASE or
+
VOL. /
OFF/ DECREASE THE VOLUME -- NOTE THIS CONTROL OPERATES STEP BY
ON
STEP IN EACH DIRECTION - PRESS / RELEASE / PRESS / RELEASE ETC.
IT IS BETTER IF THE VOLUME IS REDUCED PRIOR TO SWITCHING OFF
THE SYSTEM.
+
BASS
ADJUST BASS ATTENUATION - THESE BUTTONS INCREASE or
DECREASE THE LOWER FREQUENCIES OF THE SOUND.
THESE BUTTONS INCREASE or DECREASE THE HIGHER FREQUENCIES
+
TREB.
OF THE SOUND UNTIL THE PREFERRED SOUND EFFECT IS ACHIEVED.
NOTE: IF YOU REDUCE LEVEL OF THE HIGHER FREQUENCIES THE
VOLUME OF THE SOUND SEEMS TO BE REDUCED - THIS IS NORMAL.
PRESS LEFT BUTTON FOR SOUND TO COME MORE FROM SPEAKERS ON
L
R
LEFT SIDE. PRESS RIGHT BUTTON FOR SOUND TO COME MORE FROM
SPEAKERS ON RIGHT SIDE.
CENTRAL BUTTON IS TO RESET BACK TO NORMAL STEREO SOUND.
If Media Tray is wanted on
the right side, fit side rail (4)
to left and (3) to right.
(4)
SYSTEM ON / OFF.
MODE SELECTOR - BT or OPT (BLUETOOTH or OPTICAL).
AUDIO VOLUME.
BASS.
TREBLE.
STEREO BALANCE.
2 Hrs
(4)
