TV Bedstore PARIS OTTOMAN TV BED Assembly Instructions Manual

(3)
An instructional video of the Operation of the Ottoman Lift Up system is available via YouTube
using the following address: https://youtu.be/hyq4zm7h_yU
To turn system on, press this On/Off button for 3 seconds.
At end of watching TV, lower the TV to it's resting position and TV
will switch off automatically. Music can still be heard so to switch
system off, press On/Off again for 3 seconds.
RED
Lights when System is
switched on and ready to Use
Please note that the headboard speakers
are linked to the soundbar so the
whole system is controlled by the
adjustments to the audio remote.
USB CHARGER IS FITTED TO
EACH SIDE OF HEADBOARD
USB CHARGING SOCKET
PLUG A STANDARD USB INTO THIS
SOCKET TO CHARGE ANY DEVICE
5V 2.1A in Total
NOTE THIS USB IS FOR CHARGING
ONLY, CANNOT PLAY MUSIC OR
VIDEOS THROUGH THE SYSTEM.
200727
PARIS OTTOMAN TV BED
ASSEMBLY INSTRUCTIONS
If Media Tray is wanted on
the left side, fit side rail (3)
to left and (4) to right.
(3)
SOUND SYSTEM CONTROL
ADJUST VOLUME
ADJUST BASS - THIS BUTTON LIMITS LOWER FREQUENCIES OF THE SOUND
ADJUST TREBLE - THIS BUTTON LIMITS HIGH FREQUENCIES OF THE SOUND
SELECT BT (BLUETOOTH) - DEVICE INPUT - TO PAIR LOOK FOR "BT SPEAKER"
SELECT OPT (OPTICAL) SOUND OUTPUT TO TV
(4)
REMOTE CONTROL FOR AUDIO & TV LIFT
BLUE
Lights when Bluetooth is Selected.
PRESS BUTTON ON REMOTE CONTROL (RC) IN EITHER MODE.
i) SELECT BT; PLEASE RAISE VOLUME ON DEVICE TO HIGH LEVEL THEN ADJUST RC.
ii) SELECT OPTICAL; PLEASE MUTE TV SPEAKERS FOR BEST RESULTS.
ONE MAY OCCASIONALLY NEED TO ADJUST TV SETTINGS FOR EXTERNAL SPEAKERS,
THIS DEPENDS ON THE MAKE OF TV, PLEASE CHECK THE TV USER GUIDE.
ADJUST BASS ATTENTUATION TO SUIT THE SOUND EFFECT YOU LIKE
ADJUST TREBLE ATTENTUATION TO SUIT THE SOUND EFFECT YOU LIKE.
NOTE IF YOU REDUCE LEVEL OF THE HIGHER FREQUENCIES, SOUND VOLUME IS
REDUCED - THIS IS NORMAL.
NOTE THAT IF TV IS IN THE UP POSITION AND SWITCHED ON, TV PICTURE IS
SHOWING, IT IS NOT SWITCHED OFF WHEN BLUETOOTH IS SELECTED.
TO REMOVE PICTURE, TURN OFF TV OR PRESS THE DOWN BUTTON TO LOWER
TV TO THE REST POSITION WHERE FOR SAFETY, POWER TO TV IS
DISCONNECTED AUTOMATICALLY - BT MUSIC CAN STILL PLAY THOUGH.
WHEN FINISHED WATCHING TV, PRESS RC DOWN BUTTON TO SEND TV BACK
DOWN TO REST POSITION, TV SWITCHES OFF AUTOMATICALLY.
PRESS ON/OFF FOR THREE SECONDS TO SWITCH WHOLE SYSTEM OFF.
2 Hrs
If Media Tray is wanted on
the right side, fit side rail (3)
to right and (4) to left.
(4)
TV Lift Controls
Audio Controls - see below
