- Page 1 Z506-B User Manual Realtimes Beijing Technology Co., LTD. Fax：+86 010-84284669 / 84280996 Email: info@realtimes.cn Web Page: http://www.realtimesai.com Address: 11th Floor, Block B, 20th Heping Xiyuan, Pingxi Street, Chaoyang District, Beijing 100013,P.R.China...
- Page 2 Revision History Applicable hardware Revision Date Reason for change Modified by version V1.0 2020.2 Initial release V1.0 V2.0 2020.9 Add line package configuration V1.0...
- Page 3 Realtimes Beijing Technology Co.,LTD www.realtimesai.com Electronic components and circuits are very sensitive to electrostatic discharge. Although our company designs anti-static protection for the main interfaces on the card when designing circuit board products, it is difficult to achieve anti-static safety protection for all components and circuits. Therefore, it is recommended to observe anti-static safety precautions when handling any circuit board component (including Z506-B).
- Page 4 Realtimes Beijing Technology Co.,LTD www.realtimesai.com ⚫ Do not modify or use unauthorized accessories by yourself, and the damage caused will not be warranted; After sales maintenance 1) Warranty period ⚫ Base plate, core plate : 3 year (non-human damage) ⚫ Other peripherals sold by the company:1year(non-human damage) 2) Warranty description ⚫...
- Page 5 Realtimes Beijing Technology Co.,LTD www.realtimesai.com Due to the wide range of embedded system knowledge and various types of involvement, we can not guarantee that all kinds of questions can be answered one by one. The following content is not available for technical support, only suggestions can be provided.
-
Page 6: Table Of Contents
Realtimes Beijing Technology Co.,LTD www.realtimesai.com Table of Contents 1 COMPANY PROFILE AND PRODUCT INTRODUCTION................7 ................................7 1.1 F EATURE ............................ 8 1.2 O RDERING NFORMATION ...........................8 1.3 C ABLE ITS AND CCESSORIES 2 EXTERNAL INTERFACE FUNCTION AND LOCATION................9 3 INSTALLATION AND USE..........................10 .......................... -
Page 7: Company Profile And Product Introduction
One Mini-PCIe (expandable: PAL / HD-SDI video capture, GPS / Beidou module, AD / DA module, 4G module, storage module, etc.) interface One FPD-LINK III and one MIPI camera port（Z506-S） One Mini HDMI 2.0 Size: 109.1mm×77mm ×46mm ... -
Page 8: Ordering Information
(HDMI, serial port, SPI, I2C); Includes power adapter, provides Ruitai new Era RTSO-6001B Linux4Tegra software support package, passed THE 3C and CE certification Z506-S NANO Fly cloud intelligence box guide cold version, built-in NANO B01 module, pre-installed Ubuntu 18.04, built-in 16GB eMMC;... -
Page 9: External Interface Function And Location
Realtimes Beijing Technology Co.,LTD www.realtimesai.com 2 External interface function and location Z506-B FRONT Z506-B BACK Z506-B Reference Manual V1.0... -
Page 10: Installation And Use
Realtimes Beijing Technology Co.,LTD www.realtimesai.com 3 Installation and use 3.1 How to use Smart Box Ensure that the voltage of all external systems is turned off Install necessary external cables. (Such as: the display cable connected to the HDMI display, the power input cable to power the system, the USB cable connecting the keyboard and mouse ...) Connect the power cord to a power source. -
Page 11: Connectors Description
Realtimes Beijing Technology Co.,LTD www.realtimesai.com 4 Connectors Description 4.1 Mini HDMI connector Function HDMI output interface marking HDMI Type Mini HDMI connector 4.2 Ethernet connector Gigabit Ethernet connector Function Ethernet marking RJ45 Type 4.3 USB3.0 connector Function USB3.0 connectors marking USB3.0 Type UBS3.0 Type-A... -
Page 12: Power Input Port
Realtimes Beijing Technology Co.,LTD www.realtimesai.com 4.5 Power input port Function Power input port marking Power Input Type 2Pin interface Pin define Input voltage: +5V 4.6 OTG-USB2.0 connector USB2.0 connectors Function USB-OTG marking UBS3.0 Micro Type-B Type 4.7 FDP-LINK III connector Function FDP-LINK III camera input connectors marking... -
Page 13: Wifi Antenna Connector
Realtimes Beijing Technology Co.,LTD www.realtimesai.com Multi-function interface Function Button marking Type Pin define Signal Signal DEV_3V3 BUTTON_PWR_O DEV_3V3 FORCE_RECOV WiFi antenna connector WiFi antenna interface Function AT1 AT2 marking ipex to sma female Type 5 Hardware update history Z506-B hardware update history edition Updata description V1.0... -
Page 14: Product Size Diagram
Realtimes Beijing Technology Co.,LTD www.realtimesai.com 6 Product size diagram 7 Software/BSP Details The Z506-B board works on systems that burn using the official original NVIDIA Linux For Tegra (L4T) ,HDMI, gigabit Ethernet, USB2.0, serial port, GPIO, SD card, I2C bus, fan interface, can be supported. But Mini-PCIe, USB3.0, can't work normally. -
Page 15: Terms Of Warranty
Realtimes Beijing Technology Co.,LTD www.realtimesai.com Terms of Warranty Important note Each embedded product provided by Realtimes Technology is free from any defects in material and process,fully in line with the specifications officially issued by the original factory. Realtimes Technology warranty covers the original products,If the parts configured by the dealer are out of order, please consult with the dealer to solve the problem.
