Before Use; Appliance Use - Unit USP-1070D Instruction Manual

ENGLISH
Установка Time setting/Postponed
времени start timer setting
Multi-Mode Cooking different dishes
has no post-
poned start
function. Put
the valve to the
"выпуск пара"
position.
Can set yourself
time and cook
any dishes in
this mode.
Пароварка Steam-cooking

BEFORE USE

•
Remove the packing materials from the inside and outside of the appliance and from the acces-
sories.
•
Place the cooker on a flat dry surface.
•
Wash all the parts, which may contact with the food including the Inner pot, the Measuring Cup,
the Ladle and the Steamer in warm soap water, rinse and dry.
•
Wipe inside and outside of the appliance, and the Lid with the wet sponge and than with a clean
dry cloth.
•
Before connecting the cooker to the supply, check the applicable voltage indicated on the appli-
ance to see whether it corresponds to that of the main supply (220-240 V, 50-60 Hz).
•
Don't dip the appliance into water or other liquid!

APPLIANCE USE

1. Open the Lid turning it counter-clockwise to the clamping position and then lift it.
2. Take out the Inner Pot and fill in with the kitchen-stuff and water. Make sure the cooker must
never be filled more than 4/5 full or less than 1/5 full.
When cooking the kitchen-stuff that enlarge, do not fill in the pot more than 3/5 full.
6
Cooking time set- If you press it before any
ting: the gap is 1 other button – you will set
min; Postponed the postponed start timer; if
start timer setting you press it after choosing
– the gap is 30 any cooking program – you
mins will set the time of cooking
18 Can set yourself time and
cook any dishes in this
mode.
15 Pour the water and put the
steamer inside
Note: to cook the stuff evenly it's necessary to dip it into the water.
3. Clean the Inner Coating and the Heating Plate with a slightly wet cloth before cooking: be sure
there are no foreign particles left in the Inner Coating or on the surface of the Heating Plate.
4. Take the Pot with kitchen-stuff and water inside carefully and put it into the appliance. Then turn
the Inner Pot slightly to fit it well with the Heating Plate.
5. Close the Lid: for this put the Sealing Gasket on the Inner Steel Ring. Make sure they are fitting
well (see the sketch on page 2)
Then close the Lid turning it clockwise till a sound of clamping is heard.
6. Fix the pressure Relief Valve in the position ("герметично") as the picture shows.
Note: the Valve has two positions – "герметично" and "выпуск пара".
7. Switch the power on - the display shows "00:00". Now you should preset cooking parameters on
the panel.
Timer setting (skip this step if you don't need to postpone the time of starting cooking).
In case you want to postpone the time of cooking then before choosing any program press the
Button "Таймер отложенного старта" as many times as needed. The figures show the time of the
delay, for example, if you see "00:30" - it means that cooking will start in 30 minutes. The maximum
time setting is 24 hours.
Choose the menu according to different recipes
Press one of the Menu Buttons in relation to the kitchen-stuff you're cooking (press "Рис" Button for
rice cooking, for example) and the indicator of this button lights up.
If necessary you can change the time of cooking with "Установка времени приготовления» button
after choosing the appropriate program button.
Note: you should remember that the programmed time is approximate and you can specify it ac-
cording to your preferences.
Note: in case the kitchen-stuff don't belong to any group in the menu you should choose a similar
group.
The time of cooking (programmed)
This time is indicated after you chose the exact type of food button and means the time of cooking
after the pressure inside achieves working state. It doesn't include the time until achieving working
pressure.
After time setting wait for some seconds and the process will start.
•
Pressure holding process begins when pressure inside is high enough.
•
When pressurizing is over, you'll hear 3 sound signals, they indicate the end of cooking and the
start of keeping warm process.
•
Press Отмена/Поддержание тепла Button to cancel parameter setting or current working sta-
tus.
8. Take out the food in the following steps:
Turn the Relief Valve to "выпуск пара" position to release steam.
Note: When cooking fluid food, such as porridge, to avoid squirting up remember not to release the
steam immediately after 3 sound signals. Let the pressure cooker cool down naturally or use the
cooling system. Otherwise the fluid food may squirt and result in damage.
•
Remove the plug form the socket.
•
Turn the Handle counter clockwise; open it and take the food out.
ENGLISH
7
