Harol VR150 Installation And User Manual

Multifunctional surface mounted roller shutter

Advertisement

MULTIFUNCTIONAL
SURFACE MOUNTED
ROLLER SHUTTER
VR150
Art. 061715
POORTEN
ROLLUIKEN
GATES
ROLLER SHUTTERS
AND USER GUIDE
ZONWERING
SUN PROTECTION
INSTALLATION

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VR150 and is the answer not in the manual?

Questions and answers

Summary of Contents for Harol VR150

  • Page 1 INSTALLATION AND USER GUIDE MULTIFUNCTIONAL SURFACE MOUNTED ROLLER SHUTTER VR150 Art. 061715 POORTEN ROLLUIKEN ZONWERING GATES ROLLER SHUTTERS SUN PROTECTION...
  • Page 2: Table Of Contents

    INSTALLATION MANUAL MULTIFUNCTIONAL SURFACE MOUNTED ROLLER SHUTTER VR150 TABLE OF CONTENTS 1. INTRODUCTION 2. GENERAL WARNINGS 3. GUARANTEE, TERMS AND CONDITIONS 4. REQUIREMENTS 5. ASSEMBLY IN 10 STEPS 5.1. Unpacking and checking 5.2. The wall cardan joint 5.3. Making attachment holes in the guide rails 5.4.
  • Page 3: Introduction

    INSTALLATION MANUAL MULTIFUNCTIONAL SURFACE MOUNTED ROLLER SHUTTER VR150 INTRODUCTION The Harol surface mounted roller shutter is an ideal shutter for renovations. It offers the possibility to have shutters installed even if there was no space provided for shutters during the construction of the house.
  • Page 4: Guarantee, Terms And Conditions

    • Make sure the shutter box can always be opened so the mechanical parts inside can be reached easily. If this rule is not respected, Harol cannot be held responsible for the cost of demolition work, among other things. Harol NV Industriepark 3 –...
  • Page 5: Assembly In 10 Steps

    INSTALLATION MANUAL MULTIFUNCTIONAL SURFACE MOUNTED ROLLER SHUTTER VR150 ASSEMBLY IN 10 STEPS 5.1. Unpacking and checking a. Check the package Check the package for any damage before removing the complete packaging from around the box and guide rails. Be careful when cutting the straps with a knife. Opening the cardboard box carelessly may result in damage to the paint.
  • Page 6: The Wall Cardan Joint

    INSTALLATION MANUAL MULTIFUNCTIONAL SURFACE MOUNTED ROLLER SHUTTER VR150 5.2. The wall cardan joint − The cable duct or tape guide is usually found in the shutter unless otherwise requested. It is important, however, to ensure there is a cardan joint before starting the installation.
  • Page 7: Making Attachment Holes In The Guide Rails

    INSTALLATION MANUAL MULTIFUNCTIONAL SURFACE MOUNTED ROLLER SHUTTER VR150 5.3. Making attachment holes in the guide rails Determine where you want the attachment holes in the guide rail (3 for each metre of height). If the guide rail needs to be drilled from the side, then first drill a 6.5 mm hole sideways through the hollow box and then drill a 9.5 mm hole in the front (after securing the...
  • Page 8: Placing The Guide Rails On The Consoles

    INSTALLATION MANUAL MULTIFUNCTIONAL SURFACE MOUNTED ROLLER SHUTTER VR150 5.4. Placing the guide rails on the consoles Remeasure the height and if necessary saw the guide rails to size. Cut away the joint at the top of the guide rail, where you find the entry guide of the guide rail.
  • Page 9: Marking The Drill Holes

    INSTALLATION MANUAL MULTIFUNCTIONAL SURFACE MOUNTED ROLLER SHUTTER VR150 Turn everything around. Do this with at least two people so that both the guide rails and the box are supported! If the box is not supported the pivots for the console may break off! Then place everything against the wall or in the opening.
  • Page 10: Drilling The Attachment Holes

    INSTALLATION MANUAL MULTIFUNCTIONAL SURFACE MOUNTED ROLLER SHUTTER VR150 5.6. Drilling the attachment holes Remove the shutter from the wall and with at least two people place it carefully on a flat surface on a piece of cardboard. Be careful not to damage the paint! Next, drill the screw holes and insert the correct rawlplugs.
  • Page 11: Connections

    INSTALLATION MANUAL MULTIFUNCTIONAL SURFACE MOUNTED ROLLER SHUTTER VR150 Secure the fastening bolts of the guide rails and if possible also screw the consoles tightly into the wall (and for larger dimensions also the box). 5.8. Connections A (1 : 2) Motor: •...
  • Page 12 INSTALLATION MANUAL MULTIFUNCTIONAL SURFACE MOUNTED ROLLER SHUTTER VR150 Crank: Push the square rod of the universal joint on the crank handle supplied into the previously drilled bushing, until the bar stock is pushed far enough through the opening to engage with the gear box.
  • Page 13: Testing

    INSTALLATION MANUAL MULTIFUNCTIONAL SURFACE MOUNTED ROLLER SHUTTER VR150 Tape: Attaching the tape to the tape box a. Roll down the shutter curtain all the way. b. Make a slip in the tape. c. Lead the tape through the covering plate to the roll-up mechanism.
  • Page 14: Finish

    INSTALLATION MANUAL MULTIFUNCTIONAL SURFACE MOUNTED ROLLER SHUTTER VR150 5.10. Finish Place the PVC caps on the holes of the guide rail and use mastic to finish off the box and the guide rails. 10/20 | 14...
  • Page 15: Replacing The Mesh Netting In 12 Steps

    INSTALLATION MANUAL MULTIFUNCTIONAL SURFACE MOUNTED ROLLER SHUTTER VR150 REPLACING THE MESH NETTING IN 12 STEPS Number of persons: 2 1. Remove the inspection cover. Keep the shutter curtain rolled up. Pull the mesh netting down halfway. 2. Hold the bottom lath askew and remove it from the guide rails.
  • Page 16 INSTALLATION MANUAL MULTIFUNCTIONAL SURFACE MOUNTED ROLLER SHUTTER VR150 4. Completely release the shutter, and allow the mesh netting to carefully wind around the axle. 5. Disconnect the shutter curtain from the axle. Remove the little roller tube of the insect screen from its holders by pressing one of the "buttons"...
  • Page 17 INSTALLATION MANUAL MULTIFUNCTIONAL SURFACE MOUNTED ROLLER SHUTTER VR150 7. Insert this into the new axle with netting. B (1 : 2) 8. Tighten the spring using a key. In most cases this is after 18 to 19 rotations. Remove the key carefully so that the spring is not released (it is released when A (1 : 3) the spring fitting is pressed).
  • Page 18 INSTALLATION MANUAL MULTIFUNCTIONAL SURFACE MOUNTED ROLLER SHUTTER VR150 9. Insert the spring ends back into the mesh netting holders. Attention! First the spring side. When the spring is in place it will automatically release. Take care to block the axle to prevent it from unwinding.
  • Page 19 12. Replace the bottom lath and netting in the correct position in the guide rail and entry guide. Harol reserves the right to make any changes to the construction at all times without having to inform the client beforehand and therefore without having to adapt existing installations.
