Mechanical Drawing - THORLABS DET100A User Manual

Si Biased Detector

7.2. Mechanical Drawing

Visit the web for a more detailed mechanical drawing.
26.2 mm
1.03 in
Power Switch
Battery Position
Indicator
19.1 mm
0.75 in
See Specs
Table for
Distance
Detector
Surface
DETAIL A
SCALE 2 : 1
Page 15
16.2 mm
0.64 in
SM05 (0.535-40)
Internal Thread
1.035-40 External Thread
Mates with SM1 Line
21.1 mm
0.83 in
Battery Cap
48.0 mm
1.89 in
43.2 mm
1.70 in
DETxxxx
YyYyYy
A
Rev F, December 8, 2014
#8-32 x 0.25" Thread
(M4 x 6.35mm for -EC)
53.3 mm 70.1 mm
2.10 in 2.76 in
12.7 mm
0.50 in
Output BNC
