PIVOT cycles SHUTTLE SL Original Operation Instructions page 4

7. Third Party Compatibility
- Compatible Devices
- Garmin Pairing
8. Warnings
- Bicycle Safety
- Improper Use Hazards
- Health Hazards
- Potential Damage Hazards
9. Additional Information
- FAZUA Ride 60 Drive System
- Pivot Shuttle SL
- Conformity
- Sources
TECHNICAL DATA ON THE DRIVE UNIT
Article Number
Continuous rated power
(Mechanical) power, max.
Nominal voltage
Support torque, max.
Pedaling cadence (range)
Protection type
Weight, approx.
Operating temperature
TECHNICAL DATA ON THE BATTERY
Model Designation
Weight, approx.
Operating temperature
Storage temperature (< 1 month)
Storage temperature (> 1 month)
TECHNICAL DATA ON THE CHARGER
Model designation
Nominal input voltage
Frequency
Charging current
Charging time, approx.
Protection class
Protection type
Weight, approx.
Operating temperature
Storage temperature
www.pivotcycles.com
TABLE OF CONTENTS (Cont')
10A101000A/10A101100A
250W
450W
43.2 V
60 Nm
55-125 rpm
IP54
4.3 lbs (1.95 kg)
23 ˚F to 113 ˚F (-5 ˚C to +45 ˚C) ambient temperature
FAZUA ENERGY 430 fix
4.85 lbs (2.2kg)
23 ˚F to 104 ˚F (-5 ˚C to +40 ˚C) ambient temperature
5 ˚F to 140 ˚F (-15 ˚C to +60 ˚C)
5 ˚F to 77 ˚F (-15 ˚C to +25 ˚C)
CHARGER 3A (Model STC-8207LD)
100-240 V AC
47-63 Hz
3 A
3.5 h
2 [ symbol:
IP54 (when plugged in)
1.32 lbs (0.6 kg)
32 ˚F to 95 ˚F (0 ˚C to +35 ˚C)
32 ˚F to 113 ˚F (0 ˚C to +45 ˚C)
info@pivotcycles.com www.pivotcycles.com
PAGE
18
18
18
19
19
19
20
20
21
21
21
21
21
]
1.877.857.4868
4
