Summary of Contents for DOREMIDI UTD-10
- Page 2 Windows, Mac, Linux, etc. 4. Steps for usage 1. Connection: Connect the USB-A plug of UTD-10 to the PC, and the XLR plug to the RDM/DMX device. 2. Install the driver: Generally, Win8/Win10 will automatically discover the USB-DMX device. If it is not found, you need to install the driver manually.
- Page 3 3. Software settings: Take FreeStyle X2 as an example Install FreeStyle X2 software: FreeStyle software download link: www.freestylerdmx.be Set FreeStyle to connect to UTD-10: Open "Setup→FreeStyle Setup", select "JMS USB2DMX" and "FT232R USB UART", and then select "Save" to save the settings.
- Page 4 Add/remove DMX/RDM equipment: Open "Setup→Add/Remove fixtures" and add/remove RDM/DMX devices according to the picture. 5. Precautions 1. This product contains a circuit board 2. Rain or immersion in water may cause the product to malfunction 3. Do not heat, press, or damage internal components 4.
- Page 5 Question: After opening the software, the interface fails to open, or the software does not recognize the UTD-10 cable. Answer: Re-plug the UTD-10 cable, or use another USB interface, or restart the application software. If the problem is not resolved, please contact customer service.
