Harman Kardon AVR 3600 Worksheet

PERSONAL SETTINGS WORKSHEETS
Default settings and worksheets
Table A1 – Recommended Source Component Connections
Device Type AVR 3600 Source
Cable TV, satellite TV, HDTV Cable/SAT
or other device that delivers
television programs
DVD Audio/Video, SACD, DVD
Blu-ray Disc, HD-DVD player
Media Server, including Media Server
Harman Kardon DMC 1000
TV TV
Video-game console Game
Any audio or video device, AUX
e.g., CD player, camcorder,
cassette deck
Recorder Any
iPod or iPhone The Bridge III
*
Make this connection only when using the TV source for a non-display device. Do not connect your television's or video display's video output to the AVR at any time.
Table A2 – Source Setting Defaults
Cable/Sat
Surround Modes (Auto Select) Logic 7 Movie Logic 7 Movie Logic 7 Music
Video Input HDMI 2
Audio Input HDMI 2
* *
Resolution to Display 480i
Audio Auto Polling Off
Zone 2 Audio Analog 1
Dolby Volume Medium
* Video output resolution may vary for HDMI connections.
Digital Audio Connection Analog Audio Connection Video Connections
HDMI 2
HDMI 1
HDMI 4
Optical 1
HDMI 3
Coax Front
Coaxial 2 Input and
Coaxial Output
None
DVD Media Server Radio
Logic 7 Movie Logic 7 Movie Logic 7 Movie Logic 7 Music
HDMI 1 HDMI 4 N/A
HDMI 1 HDMI 4 N/A
480i 480i 480i
Off Off N/A
Analog 2 Analog 5 Radio
Low Medium Medium
1
Analog 1 HDMI 2
Analog 2 HDMI 1
Analog 5 HDMI 4
Analog 3 Component 1
Analog 4 HDMI 3
Analog Front Composite Front (not used for
audio-only devices)
Analog 4 Inputs and Outputs Composite Video 2 Input
and Output
The Bridge III The Bridge III for photo- and
video-capable iPod and iPhone
models
TV Game AUX
Component 1 HDMI 3 Composite Front The Bridge III
Optical 1 HDMI 3 Analog Front
480i 480i 480i
Off Off Off
Analog 3 Analog 4 Analog Front
Medium Medium Low
*
The Bridge
Logic 7 Music
The Bridge III
480i
N/A
The Bridge III
Medium
